Catalog / Mazda / CX-5 / 1 generation
Mazda CX-5 Engines and Transmissions
The Mazda CX-5 engine lineup offers a balance of efficiency and responsiveness. A 2.0-liter gasoline unit pairs with a manual gearbox and available all-wheel drive for confident traction. Those preferring diesel can choose a 2.2-liter with front-wheel drive and manual shift. A 2.5-liter gasoline with automatic transmission suits effortless commuting.
SUV 5-doors — Mazda CX-5 Engines and Transmissions
SUV 5-doors Mazda CX-5 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 AT Gasoline 1997 cm³ 150 hp 110 kW 210 N⋅m Automatic FWD 2.0 AT Gasoline 1997 cm³ 150 hp 110 kW 210 N⋅m Automatic AWD 2.0 MT Gasoline 1997 cm³ 150 hp 110 kW 210 N⋅m Manual FWD 2.5 AT Gasoline 2488 cm³ 192 hp 141 kW 256 N⋅m Automatic AWD 2.0 MT Gasoline 1998 cm³ 155 hp 114 kW 210 N⋅m Manual FWD 2.0 AT Gasoline 1998 cm³ 155 hp 114 kW 210 N⋅m Automatic AWD 2.0 MT Gasoline 1998 cm³ 160 hp 118 kW 208 N⋅m Manual AWD 2.0 AT Gasoline 1998 cm³ 160 hp 118 kW 208 N⋅m Automatic AWD 2.0 MT Gasoline 1998 cm³ 165 hp 121 kW 210 N⋅m Manual FWD 2.5 AT Gasoline 2488 cm³ 184 hp 135 kW 256 N⋅m Automatic FWD 2.2 AT Diesel 2191 cm³ 175 hp 129 kW 420 N⋅m Automatic AWD 2.2 MT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Manual FWD 2.2 MT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Manual AWD 2.2 AT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Automatic AWD 2.2 AT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Automatic FWD 2.2 AT Diesel 2191 cm³ 175 hp 129 kW 420 N⋅m Automatic FWD 2.2 MT Diesel 2191 cm³ 175 hp 129 kW 420 N⋅m Manual AWD 2.0 AT Gasoline 1998 cm³ 165 hp 121 kW 210 N⋅m Automatic FWD 2.5 AT Gasoline 2488 cm³ 184 hp 135 kW 256 N⋅m Automatic AWD 2.0 AT Gasoline 1998 cm³ 155 hp 114 kW 210 N⋅m Automatic FWD 2.5 AT Gasoline 2488 cm³ 188 hp 138 kW 254 N⋅m Automatic AWD
Mazda CX-5 Dimensions
SUV 5-doors — Mazda CX-5 Dimensions
SUV 5-doors Mazda CX-5 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.0 AT 4555 mm 1840 mm 1670 mm 2700 mm 1400 kg 1980 kg 215 mm 2.0 AT 4555 mm 1840 mm 1670 mm 2700 mm 1400 kg 2050 kg 215 mm 2.0 MT 4555 mm 1840 mm 1670 mm 2700 mm 1365 kg 1945 kg 215 mm 2.5 AT 4555 mm 1840 mm 1670 mm 2700 mm 1495 kg 2075 kg 210 mm 2.0 MT 4555 mm 1840 mm 1670 mm 2700 mm 1365 kg 1945 kg 215 mm 2.0 AT 4555 mm 1840 mm 1670 mm 2700 mm 1455 kg 2045 kg 210 mm 2.0 MT 4555 mm 1840 mm 1670 mm 2700 mm 1425 kg 2000 kg 210 mm 2.0 AT 4555 mm 1840 mm 1670 mm 2700 mm 1455 kg 2030 kg 210 mm 2.0 MT 4555 mm 1840 mm 1670 mm 2700 mm 1345 kg 1930 kg 215 mm 2.5 AT 4555 mm 1840 mm 1670 mm 2700 mm Not provided 2045 kg 210 mm 2.2 AT 4555 mm 1840 mm 1670 mm 2700 mm 1649 kg 2140 kg 210 mm 2.2 MT 4555 mm 1840 mm 1670 mm 2700 mm 1445 kg 2035 kg 215 mm 2.2 MT 4555 mm 1840 mm 1670 mm 2700 mm 1530 kg 2105 kg 210 mm 2.2 AT 4555 mm 1840 mm 1670 mm 2700 mm 1540 kg 2120 kg 210 mm 2.2 AT 4555 mm 1840 mm 1670 mm 2700 mm 1573 kg 2140 kg 210 mm 2.2 AT 4555 mm 1840 mm 1670 mm 2700 mm 1480 kg 2050 kg 215 mm 2.2 MT 4555 mm 1840 mm 1670 mm 2700 mm 1530 kg 2105 kg 210 mm 2.0 AT 4555 mm 1840 mm 1670 mm 2700 mm 1345 kg 1930 kg 215 mm 2.5 AT 4555 mm 1840 mm 1670 mm 2700 mm Not provided 2058 kg 210 mm 2.0 AT 4555 mm 1840 mm 1670 mm 2700 mm 1400 kg 1980 kg 215 mm 2.5 AT 4555 mm 1840 mm 1670 mm 2700 mm 1495 kg 2075 kg 210 mm
Mazda CX-5 Cargo Space
SUV 5-doors — Mazda CX-5 Cargo Space
Mazda CX-5 Trims and Equipment
