Mazda AZ-Offroad Specs, Engines & Dimensions (2002–2014)

Mazda AZ-Offroad Engines and Transmissions

Selected Mazda AZ-Offroad powertrains combine a gasoline engine with an automatic or manual transmission. The 0.7 AT example has all-wheel drive, while 0.7 MT examples include rear-wheel and all-wheel drive. An automatic makes stop-start traffic easier; a manual gives you direct control over gear selection. All-wheel drive can help with traction on loose or slippery surfaces.

SUV 3-doors — Mazda AZ-Offroad Engines and Transmissions

SUV 3-doors Mazda AZ-Offroad Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
0.7 AT	Gasoline	658 cm³	64 hp	47 kW	106 N⋅m	Automatic	AWD
0.7 MT	Gasoline	658 cm³	64 hp	47 kW	106 N⋅m	Manual	AWD
0.7 AT	Gasoline	658 cm³	64 hp	47 kW	106 N⋅m	Automatic	RWD
0.7 MT	Gasoline	658 cm³	64 hp	47 kW	106 N⋅m	Manual	RWD

Mazda AZ-Offroad Dimensions

SUV 3-doors — Mazda AZ-Offroad Dimensions

SUV 3-doors Mazda AZ-Offroad Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
0.7 AT	3395 mm	1475 mm	1210 mm	2250 mm	990 kg	200 mm
0.7 MT	3395 mm	1475 mm	1210 mm	2250 mm	980 kg	200 mm
0.7 AT	3395 mm	1475 mm	1210 mm	2250 mm	Not provided	200 mm
0.7 MT	3395 mm	1475 mm	1210 mm	2250 mm	960 kg	200 mm

Mazda AZ-Offroad Specs, Engines & Dimensions (2002–2014) — First Generation

Mazda AZ-Offroad

Mazda AZ-Offroad

Mazda AZ-Offroad

Mazda AZ-Offroad

Mazda AZ-Offroad Engines and Transmissions

SUV 3-doors — Mazda AZ-Offroad Engines and Transmissions

Mazda AZ-Offroad Dimensions

SUV 3-doors — Mazda AZ-Offroad Dimensions
