Catalog / Mazda / Atenza / 3 generation
Mazda Atenza Engines and Transmissions
A Mazda Atenza engine in this generation is usually a petrol automatic or a diesel you shift yourself. Front-wheel-drive sedan examples include the 2.0 AT and 2.5 AT petrol automatics, plus the 2.2 MT diesel with a manual transmission. Those powertrains keep commuting and longer trips straightforward.
Sedan — Mazda Atenza Engines and Transmissions
Sedan Mazda Atenza Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 AT Gasoline 1997 cm³ 155 hp 114 kW 196 N⋅m Automatic FWD 2.5 AT Gasoline 2488 cm³ 188 hp 138 kW 250 N⋅m Automatic FWD 2.2 MT Diesel 2188 cm³ 175 hp 129 kW 420 N⋅m Manual FWD 2.2 AT Diesel 2188 cm³ 175 hp 129 kW 420 N⋅m Automatic FWD
Estate 5-door — Mazda Atenza Engines and Transmissions
Estate 5-door Mazda Atenza Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 AT Gasoline 1997 cm³ 155 hp 114 kW 196 N⋅m Automatic FWD 2.5 AT Gasoline 2488 cm³ 188 hp 138 kW 250 N⋅m Automatic FWD 2.2 AT Diesel 2188 cm³ 175 hp 129 kW 420 N⋅m Automatic FWD 2.2 MT Diesel 2188 cm³ 175 hp 129 kW 420 N⋅m Manual FWD
Mazda Atenza Dimensions
Sedan — Mazda Atenza Dimensions
Sedan Mazda Atenza Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum
2.0 AT 4860 mm 1840 mm 1450 mm 2830 mm 1430 kg 160 mm 2.5 AT 4860 mm 1840 mm 1450 mm 2830 mm 1450 kg 160 mm 2.2 MT 4860 mm 1840 mm 1450 mm 2830 mm 1490 kg 160 mm 2.2 AT 4860 mm 1840 mm 1450 mm 2830 mm 1490 kg 160 mm
Estate 5-door — Mazda Atenza Dimensions
Estate 5-door Mazda Atenza Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum
2.0 AT 4800 mm 1840 mm 1480 mm 2830 mm 1430 kg 160 mm 2.5 AT 4800 mm 1840 mm 1480 mm 2830 mm 1450 kg 160 mm 2.2 AT 4800 mm 1840 mm 1480 mm 2830 mm 1490 kg 160 mm 2.2 MT 4800 mm 1840 mm 1480 mm 2830 mm 1490 kg 160 mm
