Catalog / Mazda / Atenza / 2 generation
Mazda Atenza Engines and Transmissions
Mazda Atenza engine options in this generation include gasoline powertrains with a front-wheel-drive drivetrain. Liftback examples such as the 1.8 MT and 2.0 MT use a manual transmission, while the 2.0 AT adds an automatic. Treat those pairings as selected samples, not the complete lineup.
Liftback — Mazda Atenza Engines and Transmissions
Liftback Mazda Atenza Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.8 MT Gasoline 1798 cm³ 120 hp 88 kW 165 N⋅m Manual FWD 2.0 AT Gasoline 1999 cm³ 147 hp 108 kW 184 N⋅m Automatic FWD 2.0 MT Gasoline 1999 cm³ 147 hp 108 kW 184 N⋅m Manual FWD 2.5 MT Gasoline 2488 cm³ 170 hp 125 kW 226 N⋅m Manual FWD
Sedan — Mazda Atenza Engines and Transmissions
Sedan Mazda Atenza Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.8 MT Gasoline 1798 cm³ 120 hp 88 kW 165 N⋅m Manual FWD 2.0 AT Gasoline 1999 cm³ 147 hp 108 kW 184 N⋅m Automatic FWD 2.0 MT Gasoline 1999 cm³ 147 hp 108 kW 184 N⋅m Manual FWD 2.5 MT Gasoline 2488 cm³ 170 hp 125 kW 226 N⋅m Manual FWD
Estate 5-door — Mazda Atenza Engines and Transmissions
Estate 5-door Mazda Atenza Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.8 MT Gasoline 1798 cm³ 120 hp 88 kW 165 N⋅m Manual FWD 2.0 AT Gasoline 1999 cm³ 147 hp 108 kW 184 N⋅m Automatic FWD 2.0 MT Gasoline 1999 cm³ 147 hp 108 kW 184 N⋅m Manual FWD
Mazda Atenza Dimensions
Liftback — Mazda Atenza Dimensions
Liftback Mazda Atenza Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.8 MT 4755 mm 1795 mm 1440 mm 2725 mm 1395 kg 1925 kg 165 mm 2.0 AT 4755 mm 1795 mm 1440 mm 2725 mm 1430 kg 1975 kg 165 mm 2.0 MT 4755 mm 1795 mm 1440 mm 2725 mm 1410 kg 1950 kg 165 mm 2.5 MT 4755 mm 1795 mm 1440 mm 2725 mm 1430 kg 1970 kg 165 mm
Sedan — Mazda Atenza Dimensions
Sedan Mazda Atenza Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.8 MT 4755 mm 1795 mm 1440 mm 2725 mm 1355 kg 1850 kg 165 mm 2.0 AT 4755 mm 1795 mm 1440 mm 2725 mm 1395 kg 1935 kg 165 mm 2.0 MT 4755 mm 1795 mm 1440 mm 2725 mm 1370 kg 1905 kg 165 mm 2.5 MT 4755 mm 1795 mm 1440 mm 2725 mm 1395 kg 1930 kg 165 mm
Estate 5-door — Mazda Atenza Dimensions
Estate 5-door Mazda Atenza Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.8 MT 4785 mm 1795 mm 1490 mm 2725 mm 1420 kg 1965 kg 165 mm 2.0 AT 4785 mm 1795 mm 1490 mm 2725 mm 1455 kg 2020 kg 165 mm 2.0 MT 4785 mm 1795 mm 1490 mm 2725 mm 1430 kg 1970 kg 165 mm
Mazda Atenza Cargo Space
Liftback — Mazda Atenza Cargo Space
Liftback Mazda Atenza Cargo Space Modification Trunk volume min Trunk volume max
1.8 MT 510 l 1702 l 2.0 AT 510 l 1702 l 2.0 MT 510 l 1702 l 2.5 MT 510 l 1702 l
Sedan — Mazda Atenza Cargo Space
Estate 5-door — Mazda Atenza Cargo Space
Estate 5-door Mazda Atenza Cargo Space Modification Trunk volume min Trunk volume max
1.8 MT 519 l 1751 l 2.0 AT 519 l 1751 l 2.0 MT 519 l 1751 l
