Catalog / Mazda / 626 / 2 generation
Mazda 626 Engines and Transmissions
Mazda 626 engine choices include the gasoline 2.0 AT Coupe, whose automatic transmission saves you changing gears in traffic. Selected Sedan examples combine a manual gearbox with a diesel engine in the 2.0 MT or gasoline power in the 1.6 MT. All three use front-wheel drive.
Coupe — Mazda 626 Engines and Transmissions
Coupe Mazda 626 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.6 MT Gasoline 1587 cm³ 80 hp 59 kW 121 N⋅m Manual FWD 1.6 MT Gasoline 1587 cm³ 82 hp 60 kW 120 N⋅m Manual FWD 2.0 MT Gasoline 1998 cm³ 92 hp 68 kW 153 N⋅m Manual FWD 2.0 MT Gasoline 1998 cm³ 95 hp 70 kW 158 N⋅m Manual FWD 2.0 MT Gasoline 1998 cm³ 101 hp 74 kW 156 N⋅m Manual FWD 2.0 AT Gasoline 1998 cm³ 101 hp 74 kW 156 N⋅m Automatic FWD 2.0 MT Gasoline 1998 cm³ 120 hp 88 kW 171 N⋅m Manual FWD
Sedan — Mazda 626 Engines and Transmissions
Sedan Mazda 626 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.6 MT Gasoline 1600 cm³ 80 hp 59 kW Not provided Manual FWD 1.6 AT Gasoline 1600 cm³ 80 hp 59 kW Not provided Automatic FWD 2.0 MT Gasoline 1998 cm³ 101 hp 74 kW 156 N⋅m Manual FWD 2.0 AT Gasoline 1998 cm³ 101 hp 74 kW 156 N⋅m Automatic FWD 2.0 MT Gasoline 1998 cm³ 120 hp 88 kW Not provided Manual FWD 2.0 AT Gasoline 2000 cm³ 120 hp 88 kW Not provided Automatic FWD 2.0 MT Diesel 1998 cm³ 63 hp 46 kW 128 N⋅m Manual FWD 2.0 AT Diesel 1998 cm³ 63 hp 46 kW 128 N⋅m Automatic FWD
Hatchback 5-door — Mazda 626 Engines and Transmissions
Hatchback 5-door Mazda 626 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 AT Gasoline 2000 cm³ 120 hp 88 kW Not provided Automatic FWD 1.6 MT Gasoline 1597 cm³ 75 hp 55 kW 122 N⋅m Manual FWD 1.6 AT Gasoline 1597 cm³ 75 hp 55 kW 122 N⋅m Automatic FWD 1.6 MT Gasoline 1600 cm³ 80 hp 59 kW Not provided Manual FWD 1.6 AT Gasoline 1600 cm³ 80 hp 59 kW Not provided Automatic FWD 2.0 MT Gasoline 2000 cm³ 93 hp 68 kW Not provided Manual FWD 2.0 MT Gasoline 2000 cm³ 101 hp 74 kW Not provided Manual FWD 2.0 AT Gasoline 2000 cm³ 101 hp 74 kW Not provided Automatic FWD 2.0 MT Gasoline 2000 cm³ 120 hp 88 kW Not provided Manual FWD 2.0 MT Diesel 1998 cm³ 63 hp 46 kW 128 N⋅m Manual FWD
Mazda 626 Dimensions
Coupe — Mazda 626 Dimensions
Coupe Mazda 626 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.6 MT 4430 mm 1690 mm 1365 mm 2509 mm 995 kg 1650 kg 150 mm 1.6 MT 4430 mm 1690 mm 1365 mm 2509 mm 970 kg 1650 kg 150 mm 2.0 MT 4430 mm 1690 mm 1365 mm 2509 mm 1070 kg 1720 kg 165 mm 2.0 MT 4430 mm 1690 mm 1365 mm 2509 mm 1025 kg 1650 kg 165 mm 2.0 MT 4430 mm 1690 mm 1365 mm 2509 mm 1025 kg 1650 kg 165 mm 2.0 AT 4430 mm 1690 mm 1365 mm 2509 mm 1035 kg 1650 kg 165 mm 2.0 MT 4430 mm 1690 mm 1365 mm 2509 mm 1080 kg 1720 kg 165 mm
Sedan — Mazda 626 Dimensions
Sedan Mazda 626 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.6 MT 4520 mm 1590 mm 1410 mm 2510 mm 995 kg Not provided 165 mm 1.6 AT 4520 mm 1590 mm 1410 mm 2510 mm Not provided Not provided 165 mm 2.0 MT 4520 mm 1590 mm 1410 mm 2510 mm 1035 kg 1650 kg 165 mm 2.0 AT 4520 mm 1590 mm 1410 mm 2510 mm 1045 kg 1650 kg 165 mm 2.0 MT 4520 mm 1590 mm 1410 mm 2510 mm 1080 kg 1650 kg 165 mm 2.0 AT 4520 mm 1590 mm 1410 mm 2510 mm Not provided Not provided 165 mm 2.0 MT 4520 mm 1590 mm 1410 mm 2510 mm 1035 kg Not provided 165 mm 2.0 AT 4520 mm 1590 mm 1410 mm 2510 mm Not provided Not provided 165 mm
Hatchback 5-door — Mazda 626 Dimensions
Hatchback 5-door Mazda 626 Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum
2.0 AT 4520 mm 1590 mm 1410 mm 2510 mm Not provided 165 mm 1.6 MT 4520 mm 1590 mm 1410 mm 2510 mm Not provided 165 mm 1.6 AT 4520 mm 1590 mm 1410 mm 2510 mm Not provided 165 mm 1.6 MT 4520 mm 1590 mm 1410 mm 2510 mm 970 kg 165 mm 1.6 AT 4520 mm 1590 mm 1410 mm 2510 mm Not provided 165 mm 2.0 MT 4520 mm 1590 mm 1410 mm 2510 mm Not provided 165 mm 2.0 MT 4520 mm 1590 mm 1410 mm 2510 mm 1028 kg 165 mm 2.0 AT 4520 mm 1590 mm 1410 mm 2510 mm Not provided 165 mm 2.0 MT 4520 mm 1590 mm 1410 mm 2510 mm 1065 kg 165 mm 2.0 MT 4520 mm 1590 mm 1410 mm 2510 mm Not provided 165 mm
Mazda 626 Cargo Space
Coupe — Mazda 626 Cargo Space
