Mazda 323F Specs, Engines & Dimensions (1996–1998)

Mazda 323F Engines and Transmissions

Mazda 323F engine choices include gasoline and diesel options. Among the Liftback examples, the gasoline 1.5i MT and diesel 2.0D MT pair front-wheel drive with a manual transmission, giving you direct control over gear selection. The gasoline 2.0i AT also drives the front wheels and offers automatic shifting for less work in traffic.

Liftback — Mazda 323F Engines and Transmissions

Liftback Mazda 323F Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.5i MT	Gasoline	1489 cm³	88 hp	64 kW	108 N⋅m	Manual	FWD
1.8i MT	Gasoline	1839 cm³	114 hp	83 kW	157 N⋅m	Manual	FWD
2.0i MT	Gasoline	1995 cm³	144 hp	105 kW	180 N⋅m	Manual	FWD
2.0i AT	Gasoline	1995 cm³	144 hp	105 kW	180 N⋅m	Automatic	FWD
2.0D MT	Diesel	1998 cm³	72 hp	105 kW	128 N⋅m	Manual	FWD
1.8i AT	Gasoline	1839 cm³	114 hp	83 kW	157 N⋅m	Automatic	FWD

Mazda 323F Dimensions

Liftback — Mazda 323F Dimensions

Liftback Mazda 323F Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
1.5i MT	4245 mm	1695 mm	1355 mm	2605 mm	1115 kg	150 mm
1.8i MT	4245 mm	1695 mm	1355 mm	2605 mm	1115 kg	150 mm
2.0i MT	4245 mm	1695 mm	1355 mm	2605 mm	1210 kg	150 mm
2.0i AT	4245 mm	1695 mm	1355 mm	2605 mm	1210 kg	150 mm
2.0D MT	4245 mm	1695 mm	1355 mm	2605 mm	1175 kg	150 mm
1.8i AT	4245 mm	1695 mm	1355 mm	2605 mm	1115 kg	150 mm

Mazda 323F Cargo Space

Liftback — Mazda 323F Cargo Space

Liftback Mazda 323F Cargo Space
Modification	Trunk volume min
1.5i MT	415 l
1.8i MT	415 l
2.0i MT	415 l
2.0i AT	415 l
2.0D MT	415 l
1.8i AT	415 l

Mazda 323F Specs, Engines & Dimensions (1996–1998) — Second Generation

Mazda 323F

Mazda 323F

Mazda 323F

Mazda 323F

Mazda 323F

Mazda 323F

Mazda 323F Engines and Transmissions

Liftback — Mazda 323F Engines and Transmissions

Mazda 323F Dimensions

Liftback — Mazda 323F Dimensions

Mazda 323F Cargo Space

Liftback — Mazda 323F Cargo Space
