Catalog / Mazda / 3 / 4 generation
Mazda 3 Engines and Transmissions
Selected Mazda 3 engine options for the sedan include the gasoline 1.5 AT, whose automatic transmission simplifies urban driving, and the diesel 1.8 MT, pairing manual control with diesel’s potential for efficient longer journeys. The gasoline 2.5L SKYACTIV-G AWD AT combines an automatic with all-wheel drive, which can help you accelerate on slippery surfaces.
Sedan — Mazda 3 Engines and Transmissions
Sedan Mazda 3 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.5 AT Gasoline 1496 cm³ 120 hp 88 kW 153 N⋅m Automatic FWD 2.0 MT Gasoline 1998 cm³ 122 hp 90 kW 213 N⋅m Manual FWD 2.0 AT Gasoline 1998 cm³ 122 hp 90 kW 213 N⋅m Automatic FWD 1.8 AT Diesel 1759 cm³ 116 hp 85 kW 270 N⋅m Automatic FWD 1.8 MT Diesel 1759 cm³ 116 hp 85 kW 270 N⋅m Manual FWD 2.5L SKYACTIV-G Gasoline 2488 cm³ 227 hp 166 kW 422 N⋅m Automatic FWD 2.0 AT Gasoline 1998 cm³ 153 hp 112 kW 203 N⋅m Automatic FWD 2.5L SKYACTIV-G AWD AT Gasoline 2488 cm³ 191 hp 140 kW 252 N⋅m Automatic AWD 2.5L SKYACTIV-G AT Gasoline 2488 cm³ 140 hp 102 kW 238 N⋅m Automatic FWD 2.5L SKYACTIV-G MT Gasoline 2488 cm³ 140 hp 102 kW 238 N⋅m Manual FWD 2.0L SKYACTIV-G Gasoline 1998 cm³ 165 hp Not provided 218 N⋅m Automatic FWD 2.5 AT Gasoline 2488 cm³ 227 hp 166 kW 422 N⋅m Automatic AWD 2.5L SKYACTIV-G Gasoline 2488 cm³ 186 hp 136 kW 252 N⋅m Automatic FWD 2.5L SKYACTIV-G AT Gasoline 2488 cm³ 191 hp 140 kW 252 N⋅m Automatic FWD
Hatchback 5-door — Mazda 3 Engines and Transmissions
Hatchback 5-door Mazda 3 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.5 MT Gasoline 1496 cm³ 120 hp 88 kW 153 N⋅m Manual FWD 1.5 AT Gasoline 1496 cm³ 120 hp 88 kW 153 N⋅m Automatic FWD 2.0 AT Gasoline 1998 cm³ 150 hp 110 kW 213 N⋅m Automatic FWD 2.0 MT Gasoline 1998 cm³ 122 hp 90 kW 213 N⋅m Manual FWD 2.0 AT Gasoline 1998 cm³ 122 hp 90 kW 213 N⋅m Automatic FWD 1.8 MT Diesel 1759 cm³ 116 hp 85 kW 270 N⋅m Manual FWD 1.8 AT Diesel 1759 cm³ 116 hp 85 kW 270 N⋅m Automatic FWD 2.5L SKYACTIV-G Gasoline 2488 cm³ 186 hp 136 kW 252 N⋅m Automatic FWD 2.5L SKYACTIV-G AT Gasoline 2488 cm³ 140 hp 102 kW 238 N⋅m Automatic FWD 2.5L SKYACTIV-G MT Gasoline 2488 cm³ 140 hp 102 kW 238 N⋅m Manual FWD 2.5L SKYACTIV-G AWD AT Gasoline 2488 cm³ 191 hp 140 kW 252 N⋅m Automatic AWD 2.0L SKYACTIV-G Gasoline 1998 cm³ 165 hp Not provided 218 N⋅m Automatic FWD 2.5L SKYACTIV-G Gasoline 2488 cm³ 227 hp 166 kW 422 N⋅m Automatic AWD 2.5L SKYACTIV-G AT Gasoline 2488 cm³ 191 hp 140 kW 252 N⋅m Automatic FWD
Mazda 3 Dimensions
Sedan — Mazda 3 Dimensions
Sedan Mazda 3 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.5 AT 4660 mm 1795 mm 1440 mm 2725 mm 1342 kg 1835 kg 135 mm 2.0 MT 4660 mm 1795 mm 1440 mm 2725 mm 1275 kg 1869 kg 135 mm 2.0 AT 4660 mm 1795 mm 1440 mm 2725 mm 1300 kg 1902 kg 135 mm 1.8 AT 4660 mm 1795 mm 1440 mm 2725 mm 1320 kg 1914 kg 135 mm 1.8 MT 4660 mm 1795 mm 1440 mm 2725 mm 1299 kg 1894 kg 135 mm 2.5L SKYACTIV-G 4660 mm 1795 mm 1440 mm 2725 mm Not provided Not provided Not provided 2.0 AT 4660 mm 1795 mm 1440 mm 2725 mm 1354 kg 1825 kg 135 mm 2.5L SKYACTIV-G AWD AT 4660 mm 1795 mm 1440 mm 2725 mm Not provided Not provided Not provided 2.5L SKYACTIV-G AT 4660 mm 1795 mm 1440 mm 2725 mm Not provided Not provided Not provided 2.5L SKYACTIV-G MT 4660 mm 1795 mm 1440 mm 2725 mm Not provided Not provided Not provided 2.0L SKYACTIV-G 4660 mm 1795 mm 1440 mm 2725 mm Not provided 1454 kg Not provided 2.5 AT 4660 mm 1795 mm 1440 mm 2725 mm 1534 kg Not provided Not provided 2.5L SKYACTIV-G 4660 mm 1795 mm 1440 mm 2725 mm 1407 kg Not provided Not provided 2.5L SKYACTIV-G AT 4660 mm 1795 mm 1440 mm 2725 mm Not provided Not provided Not provided
Hatchback 5-door — Mazda 3 Dimensions
Hatchback 5-door Mazda 3 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.5 MT 4460 mm 1795 mm 1435 mm 2725 mm 1320 kg 1835 kg 135 mm 1.5 AT 4460 mm 1795 mm 1435 mm 2725 mm 1342 kg 1835 kg 135 mm 2.0 AT 4460 mm 1795 mm 1435 mm 2725 mm 1362 kg 1907 kg 135 mm 2.0 MT 4460 mm 1795 mm 1435 mm 2725 mm 1274 kg 1875 kg 135 mm 2.0 AT 4460 mm 1795 mm 1435 mm 2725 mm 1299 kg 1907 kg 135 mm 1.8 MT 4460 mm 1795 mm 1435 mm 2725 mm 1299 kg 1898 kg 135 mm 1.8 AT 4460 mm 1795 mm 1435 mm 2725 mm 1320 kg 1919 kg 135 mm 2.5L SKYACTIV-G 4460 mm 1795 mm 1435 mm 2725 mm 1404 kg Not provided Not provided 2.5L SKYACTIV-G AT 4460 mm 1795 mm 1435 mm 2725 mm Not provided Not provided Not provided 2.5L SKYACTIV-G MT 4460 mm 1795 mm 1435 mm 2725 mm Not provided Not provided Not provided 2.5L SKYACTIV-G AWD AT 4460 mm 1795 mm 1435 mm 2725 mm Not provided Not provided Not provided 2.0L SKYACTIV-G 4460 mm 1795 mm 1435 mm 2725 mm 1451 kg Not provided 135 mm 2.5L SKYACTIV-G 4460 mm 1795 mm 1435 mm 2725 mm 1536 kg Not provided Not provided 2.5L SKYACTIV-G AT 4460 mm 1795 mm 1435 mm 2725 mm Not provided Not provided Not provided
Mazda 3 Cargo Space
Sedan — Mazda 3 Cargo Space
Hatchback 5-door — Mazda 3 Cargo Space
Mazda 3 Trims and Equipment
Mazda 3 trim levels distinguish equipment choices within a technical version. The 2.0L SKYACTIV-G sedan offers Spirit and Comfort configurations, both with gasoline power, an automatic transmission and front-wheel drive. Compare their listed equipment against your priorities for seat comfort, convenience and everyday use; the names alone do not establish a feature hierarchy.
