Mazda 3 Engines and Transmissions
The Mazda 3 engine lineup focuses on a 1.6-liter unit, offered in gasoline and diesel forms. A five-speed manual pairs with either fuel, while a four-speed automatic is reserved for the gasoline. All examples are front-wheel drive, suiting everyday commuting.
Sedan — Mazda 3 Engines and Transmissions
Sedan Mazda 3 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.6 MT Gasoline 1598 cm³ 105 hp 77 kW 145 N⋅m Manual FWD 2.0 AT Gasoline 1999 cm³ 150 hp 110 kW 187 N⋅m Automatic FWD 2.0 MT Gasoline 1999 cm³ 150 hp 110 kW 187 N⋅m Manual FWD 2.3 MT Gasoline 2261 cm³ 151 hp 113 kW 202 N⋅m Manual FWD 2.3 AT Gasoline 2261 cm³ 151 hp 113 kW 202 N⋅m Automatic FWD 2.3 AT Gasoline 2261 cm³ 156 hp 115 kW 203 N⋅m Automatic FWD 2.3 MT Gasoline 2261 cm³ 156 hp 115 kW 203 N⋅m Manual FWD 1.6 MT Diesel 1560 cm³ 109 hp 81 kW 245 N⋅m Manual FWD 2.0 MT Diesel 1998 cm³ 143 hp 105 kW 360 N⋅m Manual FWD 1.6 AT Gasoline 1598 cm³ 105 hp 77 kW 145 N⋅m Automatic FWD 2.0 AT Gasoline 1999 cm³ 150 hp 110 kW 187 N⋅m Automatic FWD
Hatchback 5-door — Mazda 3 Engines and Transmissions
Hatchback 5-door Mazda 3 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.6 MT Gasoline 1598 cm³ 105 hp 77 kW 145 N⋅m Manual FWD 2.0 MT Gasoline 1999 cm³ 150 hp 110 kW 187 N⋅m Manual FWD 1.4 MT Gasoline 1388 cm³ 84 hp 62 kW 122 N⋅m Manual FWD 2.3 AT Gasoline 2261 cm³ 151 hp 113 kW 202 N⋅m Automatic FWD 2.3 MT Gasoline 2261 cm³ 151 hp 113 kW 202 N⋅m Manual FWD 2.3 AT Gasoline 2261 cm³ 156 hp 115 kW 203 N⋅m Automatic FWD 2.3 MT Gasoline 2261 cm³ 156 hp 115 kW 203 N⋅m Manual FWD 1.6 MT Diesel 1560 cm³ 109 hp 80 kW 240 N⋅m Manual FWD 2.0 MT Diesel 1998 cm³ 143 hp 105 kW 360 N⋅m Manual FWD 1.6 AT Gasoline 1598 cm³ 105 hp 77 kW 145 N⋅m Automatic FWD 2.0 AT Gasoline 1999 cm³ 150 hp 110 kW 187 N⋅m Automatic FWD
Mazda 3 Dimensions
Sedan — Mazda 3 Dimensions
Sedan Mazda 3 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.6 MT 4490 mm 1755 mm 1465 mm 2640 mm 1245 kg 1710 kg 160 mm 2.0 AT 4490 mm 1755 mm 1465 mm 2640 mm 1306 kg 1770 kg 169 mm 2.0 MT 4490 mm 1755 mm 1465 mm 2640 mm 1306 kg 1770 kg 160 mm 2.3 MT 4490 mm 1755 mm 1465 mm 2640 mm 1325 kg Not provided 160 mm 2.3 AT 4490 mm 1755 mm 1465 mm 2640 mm 1350 kg Not provided 160 mm 2.3 AT 4490 mm 1755 mm 1465 mm 2640 mm Not provided Not provided 160 mm 2.3 MT 4490 mm 1755 mm 1465 mm 2640 mm 1215 kg 1725 kg 160 mm 1.6 MT 4490 mm 1755 mm 1465 mm 2640 mm 1265 kg 1770 kg 160 mm 2.0 MT 4490 mm 1755 mm 1465 mm 2640 mm 1400 kg 1925 kg Not provided 1.6 AT 4490 mm 1755 mm 1465 mm 2640 mm 1279 kg 1730 kg 160 mm 2.0 AT 4490 mm 1755 mm 1465 mm 2640 mm 1306 kg 1770 kg 169 mm
Hatchback 5-door — Mazda 3 Dimensions
Hatchback 5-door Mazda 3 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.6 MT 4415 mm 1755 mm 1465 mm 2640 mm 1265 kg 1725 kg 160 mm 2.0 MT 4415 mm 1755 mm 1465 mm 2640 mm 1327 kg 1790 kg 160 mm 1.4 MT 4415 mm 1755 mm 1465 mm 2640 mm 1150 kg 1625 kg 160 mm 2.3 AT 4415 mm 1755 mm 1465 mm 2640 mm 1360 kg Not provided 160 mm 2.3 MT 4415 mm 1755 mm 1465 mm 2640 mm 1336 kg Not provided 160 mm 2.3 AT 4415 mm 1755 mm 1465 mm 2640 mm Not provided Not provided 160 mm 2.3 MT 4415 mm 1755 mm 1465 mm 2640 mm 1410 kg 1910 kg 160 mm 1.6 MT 4415 mm 1755 mm 1465 mm 2640 mm 1260 kg 1770 kg 160 mm 2.0 MT 4415 mm 1755 mm 1465 mm 2640 mm 1415 kg 1945 kg Not provided 1.6 AT 4415 mm 1755 mm 1465 mm 2640 mm 1290 kg 1750 kg 160 mm 2.0 AT 4415 mm 1755 mm 1465 mm 2640 mm 1305 kg 1765 kg 160 mm
Mazda 3 Cargo Space
Sedan — Mazda 3 Cargo Space
Hatchback 5-door — Mazda 3 Cargo Space
Mazda 3 Trims and Equipment
Mazda 3 trim levels such as Flash Edition and Touring add comfort and style to the automatic gasoline sedan. Equipment may include upgraded upholstery, climate control, and alloy wheels. These trims help tailor the car to different tastes without altering the core driving character.
