Lexus IS Specs, Engines & Dimensions (1999–2005)

Lexus IS Engines and Transmissions

The first-generation Lexus IS offers two main gasoline engine choices, both designed for smooth everyday driving. In the Sedan, a 2.0-liter unit pairs with an automatic transmission for effortless progress, while the Estate 5-door can be had with the same engine and a manual gearbox for more involvement. For those wanting extra performance, a 3.0-liter engine is available in the Estate with a manual transmission, delivering stronger acceleration.

Sedan — Lexus IS Engines and Transmissions

Sedan Lexus IS Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 MT	Gasoline	1988 cm³	155 hp	114 kW	195 N⋅m	Manual	RWD
2.0 AT	Gasoline	1988 cm³	155 hp	114 kW	195 N⋅m	Automatic	RWD
2.0 MT	Gasoline	1988 cm³	186 hp	137 kW	225 N⋅m	Manual	RWD
3.0 MT	Gasoline	2997 cm³	210 hp	154 kW	289 N⋅m	Manual	RWD
3.0 MT	Gasoline	2997 cm³	214 hp	157 kW	288 N⋅m	Manual	RWD
3.0 AT	Gasoline	2997 cm³	218 hp	161 kW	296 N⋅m	Automatic	RWD
3.0 AT	Gasoline	2997 cm³	214 hp	157 kW	288 N⋅m	Automatic	RWD

Estate 5-door — Lexus IS Engines and Transmissions

Estate 5-door Lexus IS Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 MT	Gasoline	1988 cm³	155 hp	114 kW	195 N⋅m	Manual	RWD
3.0 MT	Gasoline	2997 cm³	210 hp	154 kW	289 N⋅m	Manual	RWD
3.0 AT	Gasoline	2997 cm³	214 hp	157 kW	288 N⋅m	Automatic	RWD

Lexus IS Dimensions

Sedan — Lexus IS Dimensions

Sedan Lexus IS Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 MT	4400 mm	1725 mm	1425 mm	2670 mm	1400 kg	1830 kg	125 mm
2.0 AT	4400 mm	1725 mm	1425 mm	2670 mm	1360 kg	1820 kg	150 mm
2.0 MT	4400 mm	1725 mm	1425 mm	2670 mm	1450 kg	1870 kg	150 mm
3.0 MT	4400 mm	1725 mm	1425 mm	2670 mm	1495 kg	Not provided	150 mm
3.0 MT	4400 mm	1725 mm	1425 mm	2670 mm	1510 kg	1955 kg	150 mm
3.0 AT	4400 mm	1725 mm	1425 mm	2670 mm	1565 kg	1955 kg	125 mm
3.0 AT	4400 mm	1725 mm	1425 mm	2670 mm	1510 kg	1955 kg	125 mm

Estate 5-door — Lexus IS Dimensions

Estate 5-door Lexus IS Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 MT	4505 mm	1725 mm	1430 mm	2670 mm	1450 kg	1870 kg	125 mm
3.0 MT	4505 mm	1725 mm	1430 mm	2670 mm	Not provided	Not provided	150 mm
3.0 AT	4505 mm	1725 mm	1430 mm	2670 mm	1540 kg	1990 kg	125 mm

Lexus IS Cargo Space

Sedan — Lexus IS Cargo Space

Sedan Lexus IS Cargo Space
Modification	Trunk volume min
2.0 MT	400 l
2.0 AT	400 l
2.0 MT	400 l
3.0 MT	400 l
3.0 MT	400 l
3.0 AT	400 l
3.0 AT	400 l

Estate 5-door — Lexus IS Cargo Space

Estate 5-door Lexus IS Cargo Space
Modification	Trunk volume min
2.0 MT	620 l
3.0 MT	620 l
3.0 AT	620 l
