Catalog / Kia / Sportage / 5 generation
Kia Sportage Engines and Transmissions
Kia Sportage engine options here include hybrid, turbo gasoline and diesel, each with its own transmission and drivetrain. You will find the 1,6 TGDI HEV AT in SUV Long form as a hybrid automatic with front-wheel drive. On the five-door SUV, the 1,6 TGDI 7DCT uses a robotic gearbox and all-wheel drive, while the 2.0 TDI AT is a diesel automatic with all-wheel drive.
SUV Long — Kia Sportage Engines and Transmissions
SUV Long Kia Sportage Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1,6 TGDI HEV AT Hybrid 1600 cm³ 230 hp 169 kW 350 N⋅m Automatic FWD
SUV 5-doors — Kia Sportage Engines and Transmissions
SUV 5-doors Kia Sportage Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1,6 TGDI 7DCT Gasoline 1600 cm³ 180 hp 132 kW 265 N⋅m Robotic AWD 1,6 TGDI MT Gasoline 1600 cm³ 180 hp 132 kW 265 N⋅m Manual AWD 1,6 TGDI MT Gasoline 1600 cm³ 180 hp 132 kW 265 N⋅m Manual FWD 2.0 TDI AT Diesel 2000 cm³ 186 hp 136 kW 417 N⋅m Automatic AWD 2.0 TDI AT Diesel 2000 cm³ 186 hp 100 kW 417 N⋅m Automatic FWD 1,6 TGDI Plug-in 1600 cm³ 265 hp 194 kW 350 N⋅m Automatic FWD 1.6 TDI MT Diesel 1600 cm³ 136 hp 100 kW 320 N⋅m Manual FWD 1.6 TDI MT Diesel 1600 cm³ 115 hp 84 kW 280 N⋅m Manual FWD 1.6 TDI AT Diesel 1600 cm³ 115 hp 84 kW 280 N⋅m Automatic FWD 1,6 TGDI MT Gasoline 1600 cm³ 150 hp 110 kW 250 N⋅m Manual FWD 1,6 TGDI 7DCT Gasoline 1600 cm³ 150 hp 110 kW 250 N⋅m Robotic FWD 2.5 Smartstream AT Gasoline 2497 cm³ 187 hp 137 kW Not provided Automatic AWD 1,6 TGDI HEV AT Hybrid 1598 cm³ 215 hp 158 kW 350 N⋅m Automatic AWD 1,6 TGDI 7DCT Gasoline 1600 cm³ 177 hp 130 kW Not provided Robotic FWD 1,6 TGDI HEV AT Hybrid 1598 cm³ 230 hp 169 kW 350 N⋅m Automatic FWD 1.6 TDI AT Diesel 1600 cm³ 136 hp 100 kW 320 N⋅m Automatic FWD 2.0 Smartstream AT Gasoline 2000 cm³ 156 hp 114 kW 192 N⋅m Automatic FWD 1.6 T-GDi PHEV AWD AT Plug-in 1600 cm³ 265 hp 194 kW 350 N⋅m Automatic AWD 1,6 TGDI 7DCT Gasoline 1598 cm³ 180 hp 132 kW 265 N⋅m Robotic FWD 2.5 Smartstream AT Gasoline 2497 cm³ 187 hp 137 kW Not provided Automatic FWD 1.6 TGDI 7DCT Gasoline 1600 cm³ 160 hp 117 kW Not provided Robotic FWD 1,6 TGDI HEV AT Hybrid 1598 cm³ 210 hp 154 kW 350 N⋅m Automatic FWD
Kia Sportage Dimensions
SUV Long — Kia Sportage Dimensions
SUV Long Kia Sportage Dimensions Modification Length Width Height Wheelbase 1,6 TGDI HEV AT 4660 mm 1865 mm 1645 mm 2756 mm
SUV 5-doors — Kia Sportage Dimensions
SUV 5-doors Kia Sportage Dimensions Modification Length Width Height Wheelbase Curb weight Max weight 1,6 TGDI 7DCT 4515 mm 1865 mm 1645 mm 2680 mm Not provided Not provided 1,6 TGDI MT 4515 mm 1865 mm 1645 mm 2680 mm Not provided Not provided 1,6 TGDI MT 4515 mm 1865 mm 1645 mm 2680 mm Not provided Not provided 2.0 TDI AT 4515 mm 1865 mm 1645 mm 2680 mm Not provided Not provided 2.0 TDI AT 4515 mm 1865 mm 1645 mm 2680 mm Not provided Not provided 1,6 TGDI 4515 mm 1865 mm 1645 mm 2680 mm Not provided Not provided 1.6 TDI MT 4515 mm 1865 mm 1645 mm 2680 mm Not provided Not provided 1.6 TDI MT 4515 mm 1865 mm 1645 mm 2680 mm Not provided Not provided 1.6 TDI AT 4515 mm 1865 mm 1645 mm 2680 mm Not provided Not provided 1,6 TGDI MT 4515 mm 1865 mm 1645 mm 2680 mm Not provided Not provided 1,6 TGDI 7DCT 4515 mm 1865 mm 1645 mm 2680 mm Not provided Not provided 2.5 Smartstream AT 4515 mm 1865 mm 1645 mm 2680 mm 1727 kg 2200 kg 1,6 TGDI HEV AT 4515 mm 1865 mm 1645 mm 2680 mm 1748 kg 2245 kg 1,6 TGDI 7DCT 4515 mm 1865 mm 1645 mm 2680 mm Not provided Not provided 1,6 TGDI HEV AT 4515 mm 1865 mm 1645 mm 2680 mm Not provided Not provided 1.6 TDI AT 4515 mm 1865 mm 1645 mm 2680 mm 1527 kg 2150 kg 2.0 Smartstream AT 4515 mm 1865 mm 1645 mm 2680 mm Not provided Not provided 1.6 T-GDi PHEV AWD AT 4515 mm 1865 mm 1645 mm 2680 mm 1922 kg 2415 kg 1,6 TGDI 7DCT 4515 mm 1865 mm 1645 mm 2680 mm 1555 kg 2120 kg 2.5 Smartstream AT 4515 mm 1865 mm 1645 mm 2680 mm 1650 kg 2120 kg 1.6 TGDI 7DCT 4515 mm 1865 mm 1645 mm 2680 mm 1505 kg 2145 kg 1,6 TGDI HEV AT 4515 mm 1865 mm 1645 mm 2680 mm 1682 kg 2175 kg
Kia Sportage Cargo Space
SUV Long — Kia Sportage Cargo Space
SUV Long Kia Sportage Cargo Space Modification Trunk volume min Trunk volume max 1,6 TGDI HEV AT 633 l 1715 l
SUV 5-doors — Kia Sportage Cargo Space
SUV 5-doors Kia Sportage Cargo Space Modification Trunk volume min Trunk volume max 1,6 TGDI 7DCT 591 l 1715 l 1,6 TGDI MT 591 l 1715 l 1,6 TGDI MT 591 l 1715 l 2.0 TDI AT 591 l 1715 l 2.0 TDI AT 591 l 1715 l 1,6 TGDI 591 l 1715 l 1.6 TDI MT 591 l 1715 l 1.6 TDI MT 591 l 1715 l 1.6 TDI AT 591 l 1715 l 1,6 TGDI MT 591 l 1715 l 1,6 TGDI 7DCT 591 l 1715 l 2.5 Smartstream AT 591 l 1715 l 1,6 TGDI HEV AT 591 l 1715 l 1,6 TGDI 7DCT 591 l 1715 l 1,6 TGDI HEV AT 591 l 1715 l 1.6 TDI AT 591 l 1715 l 2.0 Smartstream AT 591 l 1715 l 1.6 T-GDi PHEV AWD AT 591 l 1715 l 1,6 TGDI 7DCT 591 l 1715 l 2.5 Smartstream AT 591 l 1715 l 1.6 TGDI 7DCT 591 l 1715 l 1,6 TGDI HEV AT 591 l 1715 l
Kia Sportage Trims and Equipment
Kia Sportage trim levels on the 2.0 Smartstream AT five-door SUV are Urban and Top. That gasoline automatic with front-wheel drive keeps the same powertrain across both; Urban and Top are equipment configurations, not separate engines. When you read those names, treat them as cabin and convenience packages on this specific version, and match the equipment to how you actually use the car.
Kia Sportage Trims and Equipment Modification Body Equipment 1,6 TGDI HEV AT SUV Long Urban Long 1,6 TGDI HEV AT SUV Long Premium Long 1,6 TGDI 7DCT SUV 5-doors Urban 1,6 TGDI 7DCT SUV 5-doors Top 1,6 TGDI 7DCT SUV 5-doors EX 1,6 TGDI 7DCT SUV 5-doors Premium 1,6 TGDI 7DCT SUV 5-doors Urban Top 1,6 TGDI HEV AT SUV 5-doors Urban 1,6 TGDI HEV AT SUV 5-doors EX 1,6 TGDI HEV AT SUV 5-doors Premium 1,6 TGDI HEV AT SUV 5-doors GT Line 1.6 TDI AT SUV 5-doors Urban 1.6 TDI AT SUV 5-doors Top 1.6 TDI AT SUV 5-doors Black Edition 2.0 Smartstream AT SUV 5-doors Urban 2.0 Smartstream AT SUV 5-doors Top 2.0 Smartstream AT SUV 5-doors Premium 1.6 T-GDi PHEV AWD AT SUV 5-doors GT Line 1,6 TGDI 7DCT SUV 5-doors Urban 1,6 TGDI 7DCT SUV 5-doors EX 1,6 TGDI 7DCT SUV 5-doors Premium 1,6 TGDI 7DCT SUV 5-doors Urban Top 1.6 TGDI 7DCT SUV 5-doors Urban 1.6 TGDI 7DCT SUV 5-doors Premium 1,6 TGDI HEV AT SUV 5-doors Urban 1,6 TGDI HEV AT SUV 5-doors EX 1,6 TGDI HEV AT SUV 5-doors Premium
Kia Sportage Battery and Range
A Kia Sportage battery capacity figure belongs to a specific version, not the whole generation. Both the 1,6 TGDI HEV AT in SUV Long form and the 1,6 TGDI five-door SUV plug-in hybrid use a lithium-ion battery and automatic front-wheel drive. The hybrid mainly assists the engine; the plug-in hybrid lets you charge and use electric range on short trips.
SUV Long — Kia Sportage Battery and Range
SUV Long Kia Sportage Battery and Range Modification Battery power Battery type 1,6 TGDI HEV AT 1.49 kWh Lithium-ion batterie
SUV 5-doors — Kia Sportage Battery and Range
