Catalog / Kia / Rio / 4 generation
Kia Rio Engines and Transmissions
A Kia Rio engine in this generation works with a front-wheel-drive drivetrain and a manual or automatic transmission. The 1.6 MT sedan is a gasoline manual example; the 1.6 AT sedan keeps petrol with an automatic. The Mini 5-doors 1.1 MT diesel is another powertrain path, not the full lineup.
Sedan — Kia Rio Engines and Transmissions
Sedan Kia Rio Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.4 MT Gasoline 1368 cm³ 100 hp 73 kW 132 N⋅m Manual FWD 1.6 MT Gasoline 1591 cm³ 123 hp 90 kW 151 N⋅m Manual FWD 1.4 AT Gasoline 1368 cm³ 100 hp 73 kW 132 N⋅m Automatic FWD 1.0 MT Gasoline 998 cm³ 100 hp 74 kW 172 N⋅m Manual FWD 1.3 MT Gasoline 1248 cm³ 84 hp 62 kW 122 N⋅m Manual FWD 1.4 MT Gasoline 1368 cm³ 100 hp 74 kW 133 N⋅m Manual FWD 1.4 MT Diesel 1396 cm³ 77 hp 57 kW 240 N⋅m Manual FWD 1.4 MT Diesel 1396 cm³ 90 hp 66 kW 240 N⋅m Manual FWD 1.6 AT Gasoline 1591 cm³ 123 hp 90 kW 151 N⋅m Automatic FWD 1.0 AT Gasoline 998 cm³ 120 hp 88 kW 175 N⋅m Automatic FWD 1.4 AT Gasoline 1368 cm³ 100 hp 74 kW 133 N⋅m Automatic FWD
Mini 5-doors — Kia Rio Engines and Transmissions
Mini 5-doors Kia Rio Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.1 MT Diesel 1120 cm³ 75 hp 55 kW 150 N⋅m Manual FWD 1.4 MT Diesel 1396 cm³ 90 hp 66 kW 220 N⋅m Manual FWD 1.3 MT Gasoline 1248 cm³ 85 hp 63 kW 121 N⋅m Manual FWD 1.4 MT Gasoline 1396 cm³ 109 hp 81 kW 121 N⋅m Manual FWD 1.4 AT Gasoline 1396 cm³ 109 hp 81 kW 121 N⋅m Automatic FWD 1.6 MT Gasoline 1591 cm³ 140 hp 103 kW 167 N⋅m Manual FWD 1.6 AT Gasoline 1591 cm³ 140 hp 103 kW 167 N⋅m Automatic FWD 1.4 MT Gasoline 1368 cm³ 100 hp 73 kW 132 N⋅m Manual FWD 1.6 MT Gasoline 1591 cm³ 123 hp 90 kW 151 N⋅m Manual FWD 1.6 AT Gasoline 1591 cm³ 120 hp 88 kW 151 N⋅m Automatic FWD 1.0 AT Gasoline 998 cm³ 120 hp 88 kW 175 N⋅m Automatic FWD 1.4 AT Gasoline 1368 cm³ 100 hp 73 kW 132 N⋅m Automatic FWD 1.0 AT Gasoline 998 cm³ 100 hp 73 kW 175 N⋅m Automatic FWD
Kia Rio Dimensions
Sedan — Kia Rio Dimensions
Sedan Kia Rio Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.4 MT 4065 mm 1725 mm 1450 mm 2580 mm 1155 kg 1570 kg 170 mm 1.6 MT 4065 mm 1725 mm 1450 mm 2580 mm 1175 kg 1590 kg 170 mm 1.4 AT 4065 mm 1725 mm 1450 mm 2580 mm 1187 kg 1610 kg 170 mm 1.0 MT 4065 mm 1725 mm 1450 mm 2580 mm 1155 kg 1600 kg 135 mm 1.3 MT 4065 mm 1725 mm 1450 mm 2580 mm 1110 kg 1560 kg 135 mm 1.4 MT 4065 mm 1725 mm 1450 mm 2580 mm 1130 kg 1580 kg 135 mm 1.4 MT 4065 mm 1725 mm 1450 mm 2580 mm 1230 kg 1680 kg 135 mm 1.4 MT 4065 mm 1725 mm 1450 mm 2580 mm 1230 kg 1680 kg 135 mm 1.6 AT 4065 mm 1725 mm 1450 mm 2580 mm 1203 kg 1620 kg 170 mm 1.0 AT 4065 mm 1725 mm 1450 mm 2580 mm 1195 kg 1620 kg 135 mm 1.4 AT 4065 mm 1725 mm 1450 mm 2580 mm 1158 kg 1600 kg 135 mm
Mini 5-doors — Kia Rio Dimensions
Mini 5-doors Kia Rio Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.1 MT 4065 mm 1725 mm 1450 mm 2580 mm 1166 kg 1640 kg 150 mm 1.4 MT 4065 mm 1725 mm 1450 mm 2580 mm 1164 kg 1690 kg 150 mm 1.3 MT 4065 mm 1725 mm 1450 mm 2580 mm 1029 kg 1560 kg 150 mm 1.4 MT 4065 mm 1725 mm 1450 mm 2580 mm 1066 kg 1600 kg 150 mm 1.4 AT 4065 mm 1725 mm 1450 mm 2580 mm 1093 kg 1630 kg 150 mm 1.6 MT 4065 mm 1725 mm 1450 mm 2580 mm 1131 kg 1650 kg 150 mm 1.6 AT 4065 mm 1725 mm 1450 mm 2580 mm 1167 kg 1650 kg 150 mm 1.4 MT 4065 mm 1725 mm 1450 mm 2580 mm 1150 kg 1560 kg 160 mm 1.6 MT 4065 mm 1725 mm 1450 mm 2580 mm 1160 kg 1580 kg 160 mm 1.6 AT 4065 mm 1725 mm 1450 mm 2580 mm 1198 kg 1610 kg 160 mm 1.0 AT 4065 mm 1725 mm 1450 mm 2580 mm 1195 kg 1620 kg 135 mm 1.4 AT 4065 mm 1725 mm 1450 mm 2580 mm 1182 kg 1600 kg 160 mm 1.0 AT 4065 mm 1725 mm 1450 mm 2580 mm 1200 kg 1650 kg 135 mm
Kia Rio Cargo Space
Sedan — Kia Rio Cargo Space
Mini 5-doors — Kia Rio Cargo Space
Kia Rio Trims and Equipment
Kia Rio trim levels sit on a technical version rather than replacing it. For the 1.6 AT sedan, gasoline, automatic and front-wheel drive stay put while Europe League and Premium change cabin and convenience equipment. Choose the pack for the features you want, not a different engine.
