Kia Rio Specs, Engines & Dimensions (2015–2017)

Kia Rio Engines and Transmissions

This Kia Rio engine lineup pairs a 1.4 unit and manual transmission with a 1.6 gasoline automatic. Hatchback 5-door examples include gasoline and diesel 1.4 MT versions plus a 1.6 AT, all with a front-wheel-drive drivetrain. The manuals feel more involving; the automatic is simpler day to day.

Hatchback 5-door — Kia Rio Engines and Transmissions

Hatchback 5-door Kia Rio Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.4 MT	Gasoline	1396 cm³	107 hp	79 kW	135 N⋅m	Manual	FWD
1.6 AT	Gasoline	1591 cm³	123 hp	90 kW	155 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1591 cm³	123 hp	90 kW	155 N⋅m	Manual	FWD
1.4 AT	Gasoline	1396 cm³	109 hp	80 kW	135 N⋅m	Automatic	FWD
1.4 MT	Diesel	1396 cm³	90 hp	66 kW	220 N⋅m	Manual	FWD
1.2 MT	Gasoline	1248 cm³	82 hp	60 kW	123 N⋅m	Manual	FWD

Sedan — Kia Rio Engines and Transmissions

Sedan Kia Rio Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.4 MT	Gasoline	1396 cm³	107 hp	79 kW	135 N⋅m	Manual	FWD
1.6 AT	Gasoline	1591 cm³	123 hp	90 kW	155 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1591 cm³	123 hp	90 kW	155 N⋅m	Manual	FWD
1.4 AT	Gasoline	1396 cm³	109 hp	80 kW	135 N⋅m	Automatic	FWD

Kia Rio Dimensions

Hatchback 5-door — Kia Rio Dimensions

Hatchback 5-door Kia Rio Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.4 MT	4125 mm	1720 mm	1470 mm	2570 mm	1055 kg	1565 kg	160 mm
1.6 AT	4125 mm	1720 mm	1470 mm	2570 mm	1079 kg	1565 kg	160 mm
1.6 MT	4125 mm	1720 mm	1470 mm	2570 mm	1059 kg	1565 kg	160 mm
1.4 AT	4125 mm	1720 mm	1470 mm	2570 mm	1075 kg	1565 kg	160 mm
1.4 MT	4125 mm	1720 mm	1470 mm	2570 mm	1164 kg	1690 kg	160 mm
1.2 MT	4125 mm	1720 mm	1470 mm	2570 mm	Not provided	Not provided	160 mm

Sedan — Kia Rio Dimensions

Sedan Kia Rio Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.4 MT	4370 mm	1700 mm	1470 mm	2570 mm	1115 kg	1565 kg	160 mm
1.6 AT	4370 mm	1700 mm	1470 mm	2570 mm	1151 kg	1565 kg	160 mm
1.6 MT	4370 mm	1700 mm	1470 mm	2570 mm	1126 kg	1565 kg	160 mm
1.4 AT	4370 mm	1700 mm	1470 mm	2570 mm	1140 kg	1565 kg	160 mm

Kia Rio Cargo Space

Hatchback 5-door — Kia Rio Cargo Space

Hatchback 5-door Kia Rio Cargo Space
Modification	Trunk volume min
1.4 MT	389 l
1.6 AT	389 l
1.6 MT	389 l
1.4 AT	389 l
1.4 MT	389 l
1.2 MT	389 l

Sedan — Kia Rio Cargo Space

Sedan Kia Rio Cargo Space
Modification	Trunk volume min
1.4 MT	500 l
1.6 AT	500 l
1.6 MT	500 l
1.4 AT	500 l

Kia Rio Trims and Equipment

Kia Rio trim levels sit on a chosen technical version rather than replacing it. On the 1.6 AT Hatchback 5-door, Comfort Audio and Luxe are equipment packs for the same gasoline automatic. They change cabin features and convenience kit, so you pick fittings, not a different drivetrain.

Kia Rio Trims and Equipment
Modification	Body	Equipment
1.4 MT	Hatchback 5-door	Comfort Air A/C
1.6 AT	Hatchback 5-door	Comfort Audio
1.6 AT	Hatchback 5-door	Luxe
1.6 AT	Hatchback 5-door	Luxe FCC
1.6 AT	Hatchback 5-door	Premium
1.6 AT	Hatchback 5-door	Premium Navi
1.6 AT	Hatchback 5-door	Prestige
1.4 AT	Hatchback 5-door	LX
1.4 AT	Hatchback 5-door	Comfort Audio
1.4 AT	Hatchback 5-door	EX
1.4 MT	Hatchback 5-door	LX
1.2 MT	Hatchback 5-door	LX
1.4 MT	Sedan	Comfort
1.4 MT	Sedan	Comfort Air A/C
1.6 AT	Sedan	Comfort Audio
1.6 AT	Sedan	Luxe
1.6 AT	Sedan	Luxe FCC
1.6 AT	Sedan	Premium
1.6 AT	Sedan	Premium Navi
1.6 AT	Sedan	Prestige
1.4 AT	Sedan	LX
1.4 AT	Sedan	Comfort Audio
