Kia Rio Specs, Engines & Dimensions (2009–2012)

Kia Rio Engines and Transmissions

Choose a Kia Rio engine that matches how you drive. The 1.6 MT sedan pairs a 1.6-liter gasoline unit with a manual gearbox and front-wheel drive, while 1.6 AT adds an automatic. If you want diesel, 1.5 MT is a manual, front-wheel-drive sedan example of that powertrain.

Sedan — Kia Rio Engines and Transmissions

Sedan Kia Rio Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.4 MT	Gasoline	1399 cm³	97 hp	71 kW	125 N⋅m	Manual	FWD
1.4 MT	Gasoline	1399 cm³	95 hp	69 kW	125 N⋅m	Manual	FWD
1.4 AT	Gasoline	1399 cm³	95 hp	69 kW	125 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1599 cm³	112 hp	82 kW	146 N⋅m	Manual	FWD
1.6 AT	Gasoline	1599 cm³	112 hp	82 kW	146 N⋅m	Automatic	FWD
1.4 AT	Gasoline	1399 cm³	97 hp	71 kW	125 N⋅m	Automatic	FWD
1.5 MT	Diesel	1493 cm³	110 hp	80 kW	235 N⋅m	Manual	FWD

Mini 5-doors — Kia Rio Engines and Transmissions

Mini 5-doors Kia Rio Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.4 MT	Gasoline	1399 cm³	97 hp	71 kW	125 N⋅m	Manual	FWD
1.4 MT	Gasoline	1399 cm³	95 hp	69 kW	125 N⋅m	Manual	FWD
1.4 AT	Gasoline	1399 cm³	95 hp	69 kW	125 N⋅m	Automatic	FWD
1.6 AT	Gasoline	1599 cm³	112 hp	82 kW	146 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1599 cm³	112 hp	82 kW	146 N⋅m	Manual	FWD
1.5 MT	Diesel	1493 cm³	109 hp	80 kW	235 N⋅m	Manual	FWD
1.4 AT	Gasoline	1399 cm³	97 hp	71 kW	125 N⋅m	Automatic	FWD

Kia Rio Dimensions

Sedan — Kia Rio Dimensions

Sedan Kia Rio Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.4 MT	4250 mm	1695 mm	1470 mm	2500 mm	Not provided	Not provided	155 mm
1.4 MT	4250 mm	1695 mm	1470 mm	2500 mm	1070 kg	1580 kg	155 mm
1.4 AT	4250 mm	1695 mm	1470 mm	2500 mm	1095 kg	1600 kg	155 mm
1.6 MT	4250 mm	1695 mm	1470 mm	2500 mm	Not provided	Not provided	155 mm
1.6 AT	4250 mm	1695 mm	1470 mm	2500 mm	Not provided	Not provided	155 mm
1.4 AT	4250 mm	1695 mm	1470 mm	2500 mm	Not provided	Not provided	155 mm
1.5 MT	4250 mm	1695 mm	1470 mm	2500 mm	Not provided	Not provided	155 mm

Mini 5-doors — Kia Rio Dimensions

Mini 5-doors Kia Rio Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.4 MT	4025 mm	1695 mm	1470 mm	2500 mm	Not provided	Not provided	155 mm
1.4 MT	4025 mm	1695 mm	1470 mm	2500 mm	1085 kg	1580 kg	155 mm
1.4 AT	4025 mm	1695 mm	1470 mm	2500 mm	1095 kg	1580 kg	155 mm
1.6 AT	4025 mm	1695 mm	1470 mm	2500 mm	Not provided	Not provided	155 mm
1.6 MT	4025 mm	1695 mm	1470 mm	2500 mm	Not provided	Not provided	155 mm
1.5 MT	4025 mm	1695 mm	1470 mm	2500 mm	Not provided	Not provided	155 mm
1.4 AT	4025 mm	1695 mm	1470 mm	2500 mm	Not provided	Not provided	155 mm

Kia Rio Cargo Space

Sedan — Kia Rio Cargo Space

Sedan Kia Rio Cargo Space
Modification	Trunk volume min
1.4 MT	390 l
1.4 MT	390 l
1.4 AT	390 l
1.6 MT	390 l
1.6 AT	390 l
1.4 AT	390 l
1.5 MT	390 l

Mini 5-doors — Kia Rio Cargo Space

Mini 5-doors Kia Rio Cargo Space
Modification	Trunk volume min	Trunk volume max
1.4 MT	270 l	1107 l
1.4 MT	270 l	1107 l
1.4 AT	270 l	1107 l
1.6 AT	270 l	1107 l
1.6 MT	270 l	1107 l
1.5 MT	270 l	1107 l
1.4 AT	270 l	1107 l

Kia Rio Trims and Equipment

Kia Rio trim levels sit on top of a technical version and describe cabin and convenience equipment. On the 1.5 MT diesel sedan with a manual gearbox and front-wheel drive, one named configuration is EX. That equipment pack does not change the engine, transmission, or drivetrain.

Kia Rio Trims and Equipment
Modification	Body	Equipment
1.4 MT	Sedan	Classic
1.4 AT	Sedan	Comfort
1.4 AT	Sedan	Luxe
1.4 AT	Sedan	Prestige
1.4 AT	Sedan	EX
1.5 MT	Sedan	EX
1.4 AT	Mini 5-doors	Comfort
1.4 AT	Mini 5-doors	Luxe
1.4 AT	Mini 5-doors	Prestige
1.4 AT	Mini 5-doors	EX
