Kia Ceed Specs, Engines & Dimensions (from 2021)

Kia Ceed Engines and Transmissions

Kia Ceed engine options cover a broad spectrum, from a punchy 1.0-litre turbo gasoline with quick-shifting DSG to a torquey 1.6 TDI diesel with a manual or iMT gearbox. Those seeking efficiency can opt for the 1.6 GDI plug-in hybrid with DCT, ideal for low-emission urban runs.

Estate 5-door — Kia Ceed Engines and Transmissions

Estate 5-door Kia Ceed Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.0 MT	Gasoline	998 cm³	120 hp	88 kW	172 N⋅m	Manual	FWD
1.0 DSG	Gasoline	998 cm³	120 hp	88 kW	172 N⋅m	Robotic	FWD
1.5 T-GDI MT	Gasoline	1482 cm³	160 hp	117 kW	Not provided	Manual	FWD
1.0 MT	Gasoline	998 cm³	100 hp	73 kW	172 N⋅m	Manual	FWD
1.6 GDI Plug-in Hybrid DCT	Plug-in	1580 cm³	141 hp	103 kW	Not provided	Robotic	FWD
1.6 TDI iMT	Diesel	1598 cm³	136 hp	100 kW	280 N⋅m	Robotic	FWD
1.5 T-GDI DSG	Gasoline	1482 cm³	160 hp	117 kW	Not provided	Robotic	FWD
1.5 T-GDI DSG	Gasoline	1482 cm³	140 hp	102 kW	Not provided	Robotic	FWD

Hatchback 5-door — Kia Ceed Engines and Transmissions

Hatchback 5-door Kia Ceed Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.0 MT	Gasoline	998 cm³	120 hp	88 kW	172 N⋅m	Manual	FWD
1.0 DSG	Gasoline	998 cm³	120 hp	88 kW	172 N⋅m	Robotic	FWD
1.6 TDI iMT	Diesel	1598 cm³	136 hp	100 kW	280 N⋅m	Robotic	FWD
1.5 T-GDI MT	Gasoline	1482 cm³	160 hp	117 kW	Not provided	Manual	FWD
1.0 MT	Gasoline	998 cm³	100 hp	73 kW	172 N⋅m	Manual	FWD
1.5 T-GDI DSG	Gasoline	1482 cm³	160 hp	117 kW	Not provided	Robotic	FWD
1.6 TDI MT	Diesel	1598 cm³	136 hp	100 kW	280 N⋅m	Manual	FWD

Kia Ceed Dimensions

Estate 5-door — Kia Ceed Dimensions

Estate 5-door Kia Ceed Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight
1.0 MT	4600 mm	1800 mm	1465 mm	2650 mm	1297 kg	1800 kg
1.0 DSG	4600 mm	1800 mm	1465 mm	2650 mm	Not provided	Not provided
1.5 T-GDI MT	4600 mm	1800 mm	1465 mm	2650 mm	Not provided	Not provided
1.0 MT	4600 mm	1800 mm	1465 mm	2650 mm	1229 kg	1790 kg
1.6 GDI Plug-in Hybrid DCT	4600 mm	1800 mm	1465 mm	2650 mm	1458 kg	2030 kg
1.6 TDI iMT	4600 mm	1800 mm	1465 mm	2650 mm	1388 kg	1880 kg
1.5 T-GDI DSG	4600 mm	1800 mm	1465 mm	2650 mm	Not provided	Not provided
1.5 T-GDI DSG	4600 mm	1800 mm	1465 mm	2650 mm	Not provided	Not provided

Hatchback 5-door — Kia Ceed Dimensions

Hatchback 5-door Kia Ceed Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight
1.0 MT	4310 mm	1800 mm	1447 mm	2650 mm	1297 kg	1800 kg
1.0 DSG	4310 mm	1800 mm	1447 mm	2650 mm	Not provided	Not provided
1.6 TDI iMT	4310 mm	1800 mm	1447 mm	2650 mm	1388 kg	1880 kg
1.5 T-GDI MT	4310 mm	1800 mm	1447 mm	2650 mm	Not provided	Not provided
1.0 MT	4310 mm	1800 mm	1447 mm	2650 mm	1223 kg	1780 kg
1.5 T-GDI DSG	4310 mm	1800 mm	1447 mm	2650 mm	Not provided	Not provided
1.6 TDI MT	4310 mm	1800 mm	1447 mm	2650 mm	1343 kg	1890 kg

Kia Ceed Cargo Space

Estate 5-door — Kia Ceed Cargo Space

Estate 5-door Kia Ceed Cargo Space
Modification	Trunk volume min	Trunk volume max
1.0 MT	625 l	1694 l
1.0 DSG	625 l	1694 l
1.5 T-GDI MT	625 l	1694 l
1.0 MT	625 l	1694 l
1.6 GDI Plug-in Hybrid DCT	625 l	1694 l
1.6 TDI iMT	625 l	1694 l
1.5 T-GDI DSG	625 l	1694 l
1.5 T-GDI DSG	625 l	1694 l

Hatchback 5-door — Kia Ceed Cargo Space

Hatchback 5-door Kia Ceed Cargo Space
Modification	Trunk volume min	Trunk volume max
1.0 MT	395 l	1291 l
1.0 DSG	395 l	1291 l
1.6 TDI iMT	395 l	1291 l
1.5 T-GDI MT	395 l	1291 l
1.0 MT	395 l	1291 l
1.5 T-GDI DSG	395 l	1291 l
1.6 TDI MT	395 l	1291 l

Kia Ceed Trims and Equipment

Kia Ceed trim levels tailor the experience to different needs. For instance, the 1.6 TDI iMT Estate with LX trim includes essential comfort and safety features, while higher trims add luxury and tech. Each powertrain can be paired with various equipment lines, so you can balance performance and features.

Kia Ceed Trims and Equipment
Modification	Body	Equipment
1.6 TDI iMT	Estate 5-door	LX
1.5 T-GDI DSG	Estate 5-door	LX
