Jaecoo J5 Specs, Engines & Dimensions (from 2024) — First Generation

The first-generation Jaecoo J5 is a five-door SUV offered with several powertrain technologies, letting buyers choose between conventional, hybrid and fully electric driving while keeping the same practical, family-sized body.

← All Jaecoo models

4 modificationsAll supplied years

Jaecoo J5 Engines and Transmissions

The Jaecoo J5 engine range spans more than one technology. A 1.6 i T 4WD AT pairs a turbocharged gasoline unit with a robotic transmission and all-wheel drive, while a 1.5 AT hybrid and a fully electric AT version drive the front wheels automatically. All-wheel drive helps most on loose or slippery surfaces.

SUV 5-doors — Jaecoo J5 Engines and Transmissions

SUV 5-doors Jaecoo J5 Engines and Transmissions
ModificationEngine typeEngine capacityMaximum powerMaximum power, kwMaximum torque N⋅mTransmissionType of drive
1.6 i T 4WD ATGasoline1600 cm³197 hp144 kW290 N⋅mRoboticAWD
ATElectroNot provided211 hp155 kW294 N⋅mAutomaticFWD
1.6 i T ATGasoline1598 cm³147 hp108 kWNot providedRoboticFWD
1.5 ATHybrid1499 cm³224 hp164 kW219 N⋅mAutomaticFWD

Jaecoo J5 Dimensions

SUV 5-doors — Jaecoo J5 Dimensions

SUV 5-doors Jaecoo J5 Dimensions
ModificationLengthWidthHeightWheelbaseCurb weightMax weight
1.6 i T 4WD AT4380 mm1860 mm1650 mm2620 mmNot providedNot provided
AT4380 mm1860 mm1650 mm2620 mm1710 kg2185 kg
1.6 i T AT4380 mm1860 mm1650 mm2620 mmNot provided1943 kg
1.5 AT4380 mm1860 mm1650 mm2620 mm1536 kg2044 kg

Jaecoo J5 Cargo Space

SUV 5-doors — Jaecoo J5 Cargo Space

SUV 5-doors Jaecoo J5 Cargo Space
ModificationTrunk volume minTrunk volume max
1.6 i T 4WD AT480 l1180 l
AT480 l1180 l
1.6 i T AT480 l1180 l
1.5 AT480 l1180 l

Jaecoo J5 Trims and Equipment

Jaecoo J5 trim levels sit on top of the technical version rather than replacing it: the electric AT, for example, appears as Premium and Luxury. The mechanical package stays the same, while a higher grade generally adds comfort, convenience and interior equipment instead of changing how the car drives.

Jaecoo J5 Trims and Equipment
ModificationBodyEquipment
ATSUV 5-doorsPremium
ATSUV 5-doorsLuxury
1.6 i T ATSUV 5-doorsPremium
1.6 i T ATSUV 5-doorsLuxury
1.5 ATSUV 5-doorsPremium
1.5 ATSUV 5-doorsLuxury

Jaecoo J5 Battery, Range, Charging

Jaecoo J5 battery capacity matters most on the electric AT, which stores its energy in a lithium-ion pack. In everyday use you charge at home overnight and top up at public chargers on longer trips, while the 1.5 AT hybrid replenishes itself as you drive.

SUV 5-doors — Jaecoo J5 Battery, Range, Charging

SUV 5-doors Jaecoo J5 Battery, Range, Charging
ModificationBattery powerBattery typeDriving range, maximumFull public charging time
AT58.9 kWhLithium-ion batterie402 km27 min
1.5 AT1.83 kWhNot providedNot providedNot provided
