Isuzu MU-X Specs, Engines & Dimensions (2017–2020) — First Generation Restyling

The Isuzu MU-X First Generation Restyling is a rugged mid-size SUV built for families and adventurers. This update sharpens its look while keeping the seven-seat practicality and proven diesel power that define the model.

← All Isuzu models

5 modificationsAll supplied years

Isuzu MU-X Engines and Transmissions

Every Isuzu MU-X engine is a 3.0-litre turbo diesel, known for strong low-end torque and long-term durability. You can pair it with a six-speed manual or automatic, and choose rear-wheel drive for lighter duties or all-wheel drive for tougher terrain. For example, the automatic rear-wheel-drive version suits highway cruising and towing, while the manual all-wheel-drive setup gives you more control off-road and better traction in mud or sand.

SUV 5-doors — Isuzu MU-X Engines and Transmissions

SUV 5-doors Isuzu MU-X Engines and Transmissions
ModificationEngine typeEngine capacityMaximum powerMaximum power, kwMaximum torque N⋅mTransmissionType of drive
3.0 ATDiesel2999 cm³177 hp130 kW380 N⋅mAutomaticRWD
3.0 ATDiesel2999 cm³177 hp130 kW380 N⋅mAutomaticAWD
3.0 MTDiesel2999 cm³177 hp130 kW380 N⋅mManualAWD
1.9 ATDiesel1898 cm³150 hp110 kW350 N⋅mAutomaticRWD
1.9 MTDiesel1898 cm³150 hp110 kW350 N⋅mManualRWD

Isuzu MU-X Dimensions

SUV 5-doors — Isuzu MU-X Dimensions

SUV 5-doors Isuzu MU-X Dimensions
ModificationLengthWidthHeightWheelbaseCurb weightMax weightGround clearance, minimum
3.0 AT4825 mm1860 mm1825 mm2845 mm1900 kg2650 kg220 mm
3.0 AT4825 mm1860 mm1825 mm2845 mm2000 kg2750 kg220 mm
3.0 MT4825 mm1860 mm1825 mm2845 mm1985 kg2750 kg220 mm
1.9 AT4825 mm1860 mm1825 mm2845 mmNot providedNot provided220 mm
1.9 MT4825 mm1860 mm1825 mm2845 mmNot providedNot provided220 mm

Isuzu MU-X Cargo Space

SUV 5-doors — Isuzu MU-X Cargo Space

SUV 5-doors Isuzu MU-X Cargo Space
ModificationTrunk volume minTrunk volume max
3.0 AT235 l1830 l
3.0 AT235 l1830 l
3.0 MT235 l1830 l
1.9 AT235 l1830 l
1.9 MT235 l1830 l
