Hyundai XG Specs, Engines & Dimensions (1998–2003)

Hyundai XG Engines and Transmissions

Each Hyundai XG engine here is a gasoline unit driving the front wheels, so traction and packaging stay predictable. Selected examples include the 2.4 MT and the 2.5 in both manual and automatic form; the automatic suits relaxed city and highway driving, while the manual gives you more direct control over the powertrain.

Sedan — Hyundai XG Engines and Transmissions

Sedan Hyundai XG Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.4 MT	Gasoline	2351 cm³	139 hp	102 kW	192 N⋅m	Manual	FWD
2.5 AT	Gasoline	2494 cm³	163 hp	120 kW	230 N⋅m	Automatic	FWD
2.5 MT	Gasoline	2494 cm³	163 hp	120 kW	230 N⋅m	Manual	FWD
3.0 AT	Gasoline	2972 cm³	188 hp	138 kW	255 N⋅m	Automatic	FWD
3.0 AT	Gasoline	2972 cm³	192 hp	141 kW	260 N⋅m	Automatic	FWD
3.5 AT	Gasoline	3497 cm³	194 hp	145 kW	293 N⋅m	Automatic	FWD

Hyundai XG Dimensions

Sedan — Hyundai XG Dimensions

Sedan Hyundai XG Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.4 MT	4859 mm	1821 mm	1420 mm	2750 mm	1865 kg	2455 kg	160 mm
2.5 AT	4859 mm	1821 mm	1420 mm	2750 mm	1506 kg	2090 kg	160 mm
2.5 MT	4859 mm	1821 mm	1420 mm	2750 mm	1640 kg	2130 kg	160 mm
3.0 AT	4859 mm	1821 mm	1420 mm	2750 mm	1679 kg	2170 kg	160 mm
3.0 AT	4859 mm	1821 mm	1420 mm	2750 mm	1579 kg	2170 kg	160 mm
3.5 AT	4859 mm	1821 mm	1420 mm	2750 mm	1656 kg	Not provided	160 mm

Hyundai XG Cargo Space

Sedan — Hyundai XG Cargo Space

Sedan Hyundai XG Cargo Space
Modification	Trunk volume min
2.4 MT	411 l
2.5 AT	411 l
2.5 MT	411 l
3.0 AT	411 l
3.0 AT	411 l
3.5 AT	411 l
