Hyundai XG Specs, Engines & Dimensions (2003–2005)

Hyundai XG Engines and Transmissions

Each Hyundai XG engine here is a gasoline V6 driving the front wheels. The 2.5 comes with either an automatic or a manual gearbox, the latter suiting drivers who prefer direct control, while the 3.0 AT adds effortless torque for loaded, long-distance cruising.

Sedan — Hyundai XG Engines and Transmissions

Sedan Hyundai XG Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.5 AT	Gasoline	2494 cm³	163 hp	120 kW	230 N⋅m	Automatic	FWD
2.5 MT	Gasoline	2494 cm³	163 hp	120 kW	230 N⋅m	Manual	FWD
3.0 AT	Gasoline	2972 cm³	188 hp	138 kW	255 N⋅m	Automatic	FWD
3.5 AT	Gasoline	3497 cm³	197 hp	145 kW	292 N⋅m	Automatic	FWD

Hyundai XG Dimensions

Sedan — Hyundai XG Dimensions

Sedan Hyundai XG Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.5 AT	4879 mm	1821 mm	1420 mm	2751 mm	1506 kg	2090 kg	160 mm
2.5 MT	4879 mm	1821 mm	1420 mm	2751 mm	1640 kg	2130 kg	160 mm
3.0 AT	4879 mm	1821 mm	1420 mm	2751 mm	1650 kg	Not provided	160 mm
3.5 AT	4879 mm	1821 mm	1420 mm	2751 mm	1795 kg	2230 kg	160 mm

Hyundai XG Cargo Space

Sedan — Hyundai XG Cargo Space

Sedan Hyundai XG Cargo Space
Modification	Trunk volume min
2.5 AT	411 l
2.5 MT	411 l
3.0 AT	411 l
3.5 AT	411 l

Hyundai XG Specs, Engines & Dimensions (2003–2005) — First Generation Restyling

Hyundai XG

Hyundai XG

Hyundai XG

Hyundai XG

Hyundai XG Engines and Transmissions

Sedan — Hyundai XG Engines and Transmissions

Hyundai XG Dimensions

Sedan — Hyundai XG Dimensions

Hyundai XG Cargo Space

Sedan — Hyundai XG Cargo Space
