Hyundai IONIQ 5 Specs, Electric Power & Dimensions (2021–2026)

Hyundai IONIQ 5 Electric Power and Drivetrain

The Hyundai IONIQ 5 uses a fully electric powertrain, so there’s no traditional transmission—just a single-speed reduction gear that delivers smooth, instant response. Depending on the version, it can have one motor driving the rear wheels or two motors for all-wheel drive. The dual-motor setup increases Hyundai IONIQ 5 horsepower for stronger acceleration and better traction in slippery conditions. Single-motor models prioritize efficiency and longer range.

Hatchback 5-door — Hyundai IONIQ 5 Electric Power and Drivetrain

Hatchback 5-door Hyundai IONIQ 5 Electric Power and Drivetrain
Modification	Engine type	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
AT	Electro	236 hp	173 kW	605 N⋅m	Automatic	AWD
AT	Electro	325 hp	239 kW	605 N⋅m	Automatic	AWD
AT	Electro	170 hp	125 kW	350 N⋅m	Automatic	RWD
AT	Electro	217 hp	159 kW	357 N⋅m	Automatic	RWD
AT	Electro	305 hp	224 kW	617 N⋅m	Automatic	AWD
AT	Electro	228 hp	167 kW	350 N⋅m	Automatic	RWD

Hyundai IONIQ 5 Dimensions

Hatchback 5-door — Hyundai IONIQ 5 Dimensions

Hatchback 5-door Hyundai IONIQ 5 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
AT	4635 mm	1890 mm	1605 mm	3000 mm	1940 kg	2480 kg	Not provided
AT	4635 mm	1890 mm	1605 mm	3000 mm	2025 kg	2540 kg	155 mm
AT	4635 mm	1890 mm	1605 mm	3000 mm	1830 kg	2370 kg	Not provided
AT	4635 mm	1890 mm	1605 mm	3000 mm	1910 kg	2430 kg	Not provided
AT	4635 mm	1890 mm	1605 mm	3000 mm	2020 kg	2540 kg	Not provided
AT	4635 mm	1890 mm	1605 mm	3000 mm	1905 kg	2430 kg	155 mm

Hyundai IONIQ 5 Cargo Space

Hatchback 5-door — Hyundai IONIQ 5 Cargo Space

Hatchback 5-door Hyundai IONIQ 5 Cargo Space
Modification	Trunk volume min	Trunk volume max
AT	588 l	1648 l
AT	588 l	1648 l
AT	588 l	1648 l
AT	588 l	1648 l
AT	588 l	1648 l
AT	588 l	1648 l

Hyundai IONIQ 5 Trims and Equipment

Hyundai IONIQ 5 Trims and Equipment
Modification	Body	Equipment
AT	Hatchback 5-door	Prestige
AT	Hatchback 5-door	Supreme
AT	Hatchback 5-door	Elite
AT	Hatchback 5-door	Luxury
AT	Hatchback 5-door	Elite
AT	Hatchback 5-door	Luxury
AT	Hatchback 5-door	Limited

Hyundai IONIQ 5 Battery, Range, Charging

Hatchback 5-door — Hyundai IONIQ 5 Battery, Range, Charging

Hatchback 5-door Hyundai IONIQ 5 Battery, Range, Charging
Modification	Battery power	Battery type	Driving range, maximum	Full charge home	Full public charging time
AT	56 kWh	Lithium-ion batterie	Not provided	600 min	50 min
AT	77.5 kWh	Lithium-ion batterie	Not provided	900 min	92 min
AT	56 kWh	Lithium-ion batterie	Not provided	600 min	50 min
AT	72.6 kWh	Lithium-ion batterie	481 km	800 min	60 min
AT	72.6 kWh	Lithium-ion batterie	430 km	800 min	60 min
AT	77.4 kWh	Lithium-ion batterie	482 km	920 min	92 min
