Hyundai i35 Engines and Transmissions
The Hyundai i35 engine range in this restyling is gasoline with front-wheel drive. A 1.6 MT sedan uses a manual transmission, while 1.8 MT and 1.8 AT add displacement and let you choose stick or automatic. These powertrain examples illustrate the generation, not every drivetrain.
Sedan — Hyundai i35 Engines and Transmissions
| Modification | Engine type | Engine capacity | Maximum power | Maximum power, kw | Maximum torque N⋅m | Transmission | Type of drive |
|---|---|---|---|---|---|---|---|
| 1.6 MT | Gasoline | 1591 cm³ | 132 hp | 97 kW | 158 N⋅m | Manual | FWD |
| 1.8 MT | Gasoline | 1797 cm³ | 150 hp | 110 kW | 178 N⋅m | Manual | FWD |
| 1.8 AT | Gasoline | 1797 cm³ | 150 hp | 110 kW | 178 N⋅m | Automatic | FWD |
| 1.6 AT | Gasoline | 1591 cm³ | 132 hp | 97 kW | 158 N⋅m | Automatic | FWD |
Hyundai i35 Dimensions
Sedan — Hyundai i35 Dimensions
| Modification | Length | Width | Height | Wheelbase | Curb weight | Max weight | Ground clearance, minimum |
|---|---|---|---|---|---|---|---|
| 1.6 MT | 4550 mm | 1775 mm | 1445 mm | 2700 mm | 1236 kg | 1770 kg | 150 mm |
| 1.8 MT | 4550 mm | 1775 mm | 1445 mm | 2700 mm | 1267 kg | 1810 kg | 150 mm |
| 1.8 AT | 4550 mm | 1775 mm | 1445 mm | 2700 mm | 1267 kg | 1810 kg | 150 mm |
| 1.6 AT | 4550 mm | 1775 mm | 1445 mm | 2700 mm | 1266 kg | 1800 kg | 150 mm |
Hyundai i35 Cargo Space
Sedan — Hyundai i35 Cargo Space
Hyundai i35 Trims and Equipment
Hyundai i35 trim levels sit on a technical version rather than replacing it. The 1.6 AT sedan, a gasoline automatic with front-wheel drive, comes with Inspire and Supreme equipment configurations. Those trims change the specification around the same powertrain, so you choose equipment, not a different engine.
