Catalog / Hyundai / i30 / 2 generation, restyling
Hyundai i30 Engines and Transmissions
Five-door hatchback examples illustrate the Hyundai i30 engine choices: petrol 1.6 AT and 1.6 DCT versions, and the diesel 1.4 MT, all with front-wheel drive. The AT handles gear changes automatically, while the DCT uses automated clutches. Choose a manual if you prefer to control gear selection yourself.
Hatchback 5-door — Hyundai i30 Engines and Transmissions
Hatchback 5-door Hyundai i30 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.4 MT Gasoline 1396 cm³ 100 hp 74 kW 133 N⋅m Manual FWD 1.6 AT Gasoline 1591 cm³ 130 hp 95 kW 157 N⋅m Automatic FWD 1.6 MT Gasoline 1591 cm³ 130 hp 95 kW 157 N⋅m Manual FWD 1.6 MT Gasoline 1591 cm³ 120 hp 88 kW 156 N⋅m Manual FWD 1.6 MT Gasoline 1591 cm³ 135 hp 95 kW 164 N⋅m Manual FWD 1.6 MT Gasoline 1591 cm³ 186 hp 137 kW 265 N⋅m Manual FWD 1.8 MT Gasoline 1797 cm³ 146 hp 107 kW 175 N⋅m Manual FWD 1.8 AT Gasoline 1797 cm³ 146 hp 107 kW 175 N⋅m Automatic FWD 1.4 MT Diesel 1396 cm³ 90 hp 66 kW 240 N⋅m Manual FWD 1.6 MT Diesel 1582 cm³ 110 hp 81 kW 280 N⋅m Manual FWD 1.6 DCT Diesel 1582 cm³ 110 hp 81 kW 300 N⋅m Robotic FWD 1.6 MT Diesel 1582 cm³ 136 hp 100 kW 280 N⋅m Manual FWD 1.6 DCT Diesel 1582 cm³ 136 hp 100 kW 300 N⋅m Robotic FWD 1.4 MT Gasoline 1368 cm³ 100 hp 74 kW 134 N⋅m Manual FWD 1.6 DCT Gasoline 1591 cm³ 135 hp 95 kW 164 N⋅m Robotic FWD
Hatchback 3-door — Hyundai i30 Engines and Transmissions
Hatchback 3-door Hyundai i30 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.4 MT Gasoline 1396 cm³ 100 hp 74 kW 133 N⋅m Manual FWD 1.6 AT Gasoline 1591 cm³ 130 hp 95 kW 157 N⋅m Automatic FWD 1.6 MT Gasoline 1591 cm³ 130 hp 95 kW 157 N⋅m Manual FWD 1.6 DCT Gasoline 1591 cm³ 135 hp 99 kW 164 N⋅m Robotic FWD 1.6 MT Gasoline 1591 cm³ 135 hp 99 kW 164 N⋅m Manual FWD 1.6 MT Gasoline 1591 cm³ 186 hp 137 kW 265 N⋅m Manual FWD 1.6 MT Diesel 1582 cm³ 110 hp 81 kW 280 N⋅m Manual FWD 1.6 DCT Diesel 1582 cm³ 110 hp 81 kW 300 N⋅m Robotic FWD 1.6 DCT Diesel 1582 cm³ 136 hp 100 kW 300 N⋅m Robotic FWD 1.6 MT Diesel 1582 cm³ 136 hp 100 kW 280 N⋅m Manual FWD
Estate 5-door — Hyundai i30 Engines and Transmissions
Estate 5-door Hyundai i30 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.6 AT Gasoline 1591 cm³ 130 hp 95 kW 157 N⋅m Automatic FWD 1.6 MT Gasoline 1591 cm³ 130 hp 95 kW 157 N⋅m Manual FWD 1.4 MT Gasoline 1368 cm³ 100 hp 74 kW 134 N⋅m Manual FWD 1.6 MT Gasoline 1591 cm³ 135 hp 99 kW 164 N⋅m Manual FWD 1.6 MT Diesel 1582 cm³ 110 hp 81 kW 280 N⋅m Manual FWD 1.6 DCT Diesel 1582 cm³ 110 hp 81 kW 300 N⋅m Robotic FWD 1.6 MT Diesel 1582 cm³ 136 hp 100 kW 280 N⋅m Manual FWD 1.6 DCT Diesel 1582 cm³ 136 hp 100 kW 300 N⋅m Robotic FWD 1.6 DCT Gasoline 1591 cm³ 135 hp 99 kW 164 N⋅m Robotic FWD
Hyundai i30 Dimensions
Hatchback 5-door — Hyundai i30 Dimensions
Hatchback 5-door Hyundai i30 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.4 MT 4300 mm 1780 mm 1470 mm 2650 mm 1247 kg 1820 kg 150 mm 1.6 AT 4300 mm 1780 mm 1470 mm 2650 mm 1290 kg 1850 kg 150 mm 1.6 MT 4300 mm 1780 mm 1470 mm 2650 mm 1254 kg 1820 kg 150 mm 1.6 MT 4300 mm 1780 mm 1470 mm 2650 mm 1179 kg 1820 kg 140 mm 1.6 MT 4300 mm 1780 mm 1470 mm 2650 mm 1179 kg 1820 kg 140 mm 1.6 MT 4300 mm 1780 mm 1470 mm 2650 mm 1179 kg 1820 kg 140 mm 1.8 MT 4300 mm 1780 mm 1470 mm 2650 mm 1220 kg 1770 kg 140 mm 1.8 AT 4300 mm 1780 mm 1470 mm 2650 mm 1241 kg 1800 kg 140 mm 1.4 MT 4300 mm 1780 mm 1470 mm 2650 mm 1282 kg 1910 kg 140 mm 1.6 MT 4300 mm 1780 mm 1470 mm 2650 mm 1282 kg 1910 kg 140 mm 1.6 DCT 4300 mm 1780 mm 1470 mm 2650 mm 1282 kg 1910 kg 140 mm 1.6 MT 4300 mm 1780 mm 1470 mm 2650 mm 1282 kg 1910 kg 140 mm 1.6 DCT 4300 mm 1780 mm 1470 mm 2650 mm 1282 kg 1910 kg 140 mm 1.4 MT 4300 mm 1780 mm 1470 mm 2650 mm 1179 kg 1820 kg 140 mm 1.6 DCT 4300 mm 1780 mm 1470 mm 2650 mm 1179 kg 1820 kg 140 mm
Hatchback 3-door — Hyundai i30 Dimensions
Hatchback 3-door Hyundai i30 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.4 MT 4300 mm 1780 mm 1470 mm 2650 mm 1247 kg 1820 kg 150 mm 1.6 AT 4300 mm 1780 mm 1470 mm 2650 mm 1290 kg 1850 kg 150 mm 1.6 MT 4300 mm 1780 mm 1470 mm 2650 mm 1254 kg 1820 kg 150 mm 1.6 DCT 4300 mm 1780 mm 1470 mm 2650 mm 1297 kg 1850 kg 140 mm 1.6 MT 4300 mm 1780 mm 1470 mm 2650 mm 1263 kg 1820 kg 140 mm 1.6 MT 4300 mm 1780 mm 1470 mm 2650 mm 1357 kg 1870 kg 140 mm 1.6 MT 4300 mm 1780 mm 1470 mm 2650 mm 1356 kg 1920 kg 135 mm 1.6 DCT 4300 mm 1780 mm 1470 mm 2650 mm 1383 kg 1940 kg 135 mm 1.6 DCT 4300 mm 1780 mm 1470 mm 2650 mm 1383 kg 1940 kg 135 mm 1.6 MT 4300 mm 1780 mm 1470 mm 2650 mm 1356 kg 1920 kg 135 mm
Estate 5-door — Hyundai i30 Dimensions
Estate 5-door Hyundai i30 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.6 AT 4485 mm 1780 mm 1500 mm 2650 mm 1321 kg 1850 kg 150 mm 1.6 MT 4485 mm 1780 mm 1500 mm 2650 mm 1288 kg 1820 kg 150 mm 1.4 MT 4485 mm 1780 mm 1500 mm 2650 mm 1278 kg 1820 kg 135 mm 1.6 MT 4485 mm 1780 mm 1500 mm 2650 mm 1294 kg 1820 kg 135 mm 1.6 MT 4485 mm 1780 mm 1500 mm 2650 mm 1388 kg 1920 kg 135 mm 1.6 DCT 4485 mm 1780 mm 1500 mm 2650 mm 1415 kg 1940 kg 135 mm 1.6 MT 4485 mm 1780 mm 1500 mm 2650 mm 1388 kg 1920 kg 135 mm 1.6 DCT 4485 mm 1780 mm 1500 mm 2650 mm 1415 kg 1940 kg 135 mm 1.6 DCT 4485 mm 1780 mm 1500 mm 2650 mm 1329 kg 1850 kg 135 mm
Hyundai i30 Cargo Space
Hatchback 5-door — Hyundai i30 Cargo Space
Hatchback 3-door — Hyundai i30 Cargo Space
Estate 5-door — Hyundai i30 Cargo Space
Hyundai i30 Trims and Equipment
Active and Classic are Hyundai i30 trim levels available with the petrol, automatic, front-wheel-drive 1.6 AT five-door estate. They identify equipment configurations within that technical version. When comparing cars, check the fitted comfort and convenience features to find the combination that suits your daily use.
Hyundai i30 Trims and Equipment Modification Body Equipment 1.4 MT Hatchback 5-door Classic 1.4 MT Hatchback 5-door Start 1.6 AT Hatchback 5-door Active 1.6 AT Hatchback 5-door Comfort 1.6 AT Hatchback 5-door Vision 1.6 MT Hatchback 5-door Active 1.4 MT Hatchback 5-door Inspire 1.6 DCT Hatchback 5-door Inspire 1.6 DCT Hatchback 5-door Premium 1.4 MT Hatchback 3-door Start 1.6 AT Hatchback 3-door Active 1.6 AT Hatchback 3-door Classic 1.6 AT Estate 5-door Active 1.6 AT Estate 5-door Classic 1.6 AT Estate 5-door Comfort 1.6 AT Estate 5-door Vision 1.4 MT Estate 5-door Inspire SW 1.6 DCT Estate 5-door Inspire SW
