Hyundai Elantra Engines and Transmissions
Hyundai Elantra engine and transmission combinations include the gasoline 1.6 MT, 1.8 MT and 1.8 AT, all with front-wheel drive. These examples give you a choice between manual control over gear changes and an automatic transmission that reduces the effort of driving in stop-start traffic.
Sedan — Hyundai Elantra Engines and Transmissions
| Modification | Engine type | Engine capacity | Maximum power | Maximum power, kw | Maximum torque N⋅m | Transmission | Type of drive |
|---|---|---|---|---|---|---|---|
| 1.6 MT | Gasoline | 1591 cm³ | 132 hp | 97 kW | 158 N⋅m | Manual | FWD |
| 1.6 AT | Gasoline | 1591 cm³ | 132 hp | 97 kW | 158 N⋅m | Automatic | FWD |
| 1.8 MT | Gasoline | 1797 cm³ | 150 hp | 110 kW | 178 N⋅m | Manual | FWD |
| 1.8 AT | Gasoline | 1797 cm³ | 150 hp | 110 kW | 178 N⋅m | Automatic | FWD |
| 1.6 AT | Gasoline | 1591 cm³ | 127 hp | 93 kW | 155 N⋅m | Automatic | FWD |
Hyundai Elantra Dimensions
Sedan — Hyundai Elantra Dimensions
| Modification | Length | Width | Height | Wheelbase | Curb weight | Max weight | Ground clearance, minimum |
|---|---|---|---|---|---|---|---|
| 1.6 MT | 4550 mm | 1775 mm | 1445 mm | 2700 mm | 1259 kg | 1770 kg | 150 mm |
| 1.6 AT | 4550 mm | 1775 mm | 1445 mm | 2700 mm | 1292 kg | 1800 kg | 150 mm |
| 1.8 MT | 4550 mm | 1775 mm | 1445 mm | 2700 mm | 1292 kg | 1790 kg | 150 mm |
| 1.8 AT | 4550 mm | 1775 mm | 1445 mm | 2700 mm | 1310 kg | 1810 kg | 150 mm |
| 1.6 AT | 4550 mm | 1775 mm | 1445 mm | 2700 mm | 1292 kg | 1800 kg | 150 mm |
Hyundai Elantra Cargo Space
Sedan — Hyundai Elantra Cargo Space
Hyundai Elantra Trims and Equipment
For the 1.6 MT, Hyundai Elantra trim levels include Active and Active + Winter package. These equipment choices share the same underlying powertrain, so focus on the conveniences you need. When considering the Winter package, check which cold-weather features the particular car includes and whether they work properly.
