Hummer H3 Specs, Engines & Dimensions (2005–2013)

Hummer H3 Engines and Transmissions

Every Hummer H3 engine here is a gasoline unit driving all four wheels, so the real choice is displacement and transmission. Examples include 3.5 MT and 3.7 MT with a manual, or 3.7 AT with an automatic. The manual suits drivers who want direct control; the automatic eases traffic and low-speed crawling.

SUV 5-doors — Hummer H3 Engines and Transmissions

SUV 5-doors Hummer H3 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.7 MT	Gasoline	3653 cm³	245 hp	180 kW	327 N⋅m	Manual	AWD
3.5 MT	Gasoline	3465 cm³	223 hp	164 kW	305 N⋅m	Manual	AWD
3.7 AT	Gasoline	3653 cm³	245 hp	180 kW	327 N⋅m	Automatic	AWD
3.5 AT	Gasoline	3465 cm³	223 hp	164 kW	305 N⋅m	Automatic	AWD
5.3 AT	Gasoline	5328 cm³	300 hp	221 kW	434 N⋅m	Automatic	AWD

Pickup double-cab — Hummer H3 Engines and Transmissions

Pickup double-cab Hummer H3 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.7 AT	Gasoline	3653 cm³	245 hp	180 kW	328 N⋅m	Automatic	AWD
3.7 MT	Gasoline	3653 cm³	245 hp	180 kW	328 N⋅m	Manual	AWD
5.3 AT	Gasoline	5328 cm³	300 hp	221 kW	434 N⋅m	Automatic	AWD

Hummer H3 Dimensions

SUV 5-doors — Hummer H3 Dimensions

SUV 5-doors Hummer H3 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
3.7 MT	4782 mm	1989 mm	1872 mm	2842 mm	2231 kg	2660 kg	230 mm
3.5 MT	4782 mm	1989 mm	1872 mm	2842 mm	2115 kg	2564 kg	Not provided
3.7 AT	4782 mm	1989 mm	1872 mm	2842 mm	2231 kg	2660 kg	230 mm
3.5 AT	4782 mm	1989 mm	1872 mm	2842 mm	2135 kg	2564 kg	Not provided
5.3 AT	4782 mm	1989 mm	1872 mm	2842 mm	Not provided	2654 kg	230 mm

Pickup double-cab — Hummer H3 Dimensions

Pickup double-cab Hummer H3 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
3.7 AT	5403 mm	1897 mm	1859 mm	3409 mm	2238 kg	2660 kg	230 mm
3.7 MT	5403 mm	1897 mm	1859 mm	3409 mm	2238 kg	2660 kg	230 mm
5.3 AT	5403 mm	1897 mm	1859 mm	3409 mm	2299 kg	2654 kg	230 mm

Hummer H3 Cargo Space

SUV 5-doors — Hummer H3 Cargo Space

SUV 5-doors Hummer H3 Cargo Space
Modification	Trunk volume min	Trunk volume max
3.7 MT	835 l	1577 l
3.5 MT	835 l	1577 l
3.7 AT	835 l	1577 l
3.5 AT	835 l	1577 l
5.3 AT	835 l	1577 l

Hummer H3 Trims and Equipment

Hummer H3 trim levels sit on top of the mechanical version rather than replacing it: the 3.7 MT, for instance, appears in Base form. Equipment differences typically cover upholstery, climate control, audio and convenience features, while the engine, gearbox and drivetrain stay exactly as the technical version describes.

Hummer H3 Trims and Equipment
Modification	Body	Equipment
3.7 MT	SUV 5-doors	Base
3.7 AT	SUV 5-doors	H3x
