Ford S-MAX Specs, Engines & Dimensions (2015–2019)

Ford S-MAX Engines and Transmissions

Ford S-MAX engine options include the gasoline 1.5 MT, whose manual transmission gives you control over gear changes, and the gasoline 2.0 AT, whose automatic eases driving in traffic. Both examples use front-wheel drive. The diesel 2.0 Powershift combines an automated dual-clutch transmission with all-wheel drive, which can help you pull away on slippery surfaces. These illustrate part of the powertrain range.

Minivan — Ford S-MAX Engines and Transmissions

Minivan Ford S-MAX Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.5 MT	Gasoline	1498 cm³	160 hp	117 kW	240 N⋅m	Manual	FWD
2.0 AT	Gasoline	1999 cm³	240 hp	177 kW	345 N⋅m	Automatic	FWD
2.0 MT	Diesel	1997 cm³	120 hp	88 kW	310 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	150 hp	110 kW	350 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	150 hp	110 kW	350 N⋅m	Manual	AWD
2.0 Powershift	Diesel	1997 cm³	150 hp	110 kW	350 N⋅m	Robotic	FWD
2.0 Powershift	Diesel	1997 cm³	180 hp	132 kW	400 N⋅m	Robotic	FWD
2.0 MT	Diesel	1997 cm³	180 hp	132 kW	400 N⋅m	Manual	FWD
2.0 Powershift	Diesel	1997 cm³	180 hp	132 kW	400 N⋅m	Robotic	AWD
2.0 Powershift	Diesel	1997 cm³	210 hp	154 kW	450 N⋅m	Robotic	FWD

Ford S-MAX Dimensions

Minivan — Ford S-MAX Dimensions

Minivan Ford S-MAX Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.5 MT	4796 mm	1916 mm	1658 mm	2849 mm	1645 kg	2450 kg	128 mm
2.0 AT	4796 mm	1916 mm	1658 mm	2849 mm	1704 kg	2510 kg	128 mm
2.0 MT	4796 mm	1916 mm	1658 mm	2849 mm	1725 kg	2505 kg	128 mm
2.0 MT	4796 mm	1916 mm	1658 mm	2849 mm	1725 kg	2530 kg	128 mm
2.0 MT	4796 mm	1916 mm	1658 mm	2849 mm	1784 kg	2590 kg	128 mm
2.0 Powershift	4796 mm	1916 mm	1658 mm	2849 mm	1733 kg	2540 kg	128 mm
2.0 Powershift	4796 mm	1916 mm	1658 mm	2849 mm	1734 kg	2540 kg	128 mm
2.0 MT	4796 mm	1916 mm	1658 mm	2849 mm	1726 kg	2535 kg	128 mm
2.0 Powershift	4796 mm	1916 mm	1658 mm	2849 mm	1809 kg	2615 kg	128 mm
2.0 Powershift	4796 mm	1916 mm	1658 mm	2849 mm	1766 kg	2575 kg	128 mm

Ford S-MAX Cargo Space

Minivan — Ford S-MAX Cargo Space

Minivan Ford S-MAX Cargo Space
Modification	Trunk volume min	Trunk volume max
1.5 MT	285 l	2200 l
2.0 AT	285 l	2200 l
2.0 MT	285 l	2200 l
2.0 MT	285 l	2200 l
2.0 MT	285 l	2200 l
2.0 Powershift	285 l	2200 l
2.0 Powershift	285 l	2200 l
2.0 MT	285 l	2200 l
2.0 Powershift	285 l	2200 l
2.0 Powershift	285 l	2200 l

Ford S-MAX Trims and Equipment

Titanium is an equipment configuration available with the 2.0 AT gasoline automatic and front-wheel drive. When comparing Ford S-MAX trim levels, consider equipment separately from the mechanical specification. Check the individual vehicle for features you value, such as parking assistance and seat adjustment, because the technical version name alone does not confirm them.

Ford S-MAX Trims and Equipment
Modification	Body	Equipment
2.0 AT	Minivan	Titanium
