Ford Focus Engines and Transmissions
Selected Ford Focus engine and transmission combinations include the gasoline 1.0 AT estate and diesel estates in 2.0 MT manual and 1.5 AT automatic form. These examples use front-wheel drive. An automatic reduces shifting in traffic, while a manual gives you direct control over gear selection.
Estate 5-door — Ford Focus Engines and Transmissions
Estate 5-door Ford Focus Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.0 MT Gasoline 998 cm³ 85 hp 63 kW Not provided Manual FWD 1.0 MT Gasoline 998 cm³ 100 hp 74 kW 170 N⋅m Manual FWD 1.0 AT Gasoline 998 cm³ 125 hp 92 kW 170 N⋅m Automatic FWD 1.0 MT Gasoline 998 cm³ 125 hp 92 kW 170 N⋅m Manual FWD 1.5 MT Gasoline 1499 cm³ 150 hp 110 kW 240 N⋅m Manual FWD 1.5 MT Gasoline 1499 cm³ 182 hp 134 kW 240 N⋅m Manual FWD 1.5 MT Diesel 1499 cm³ 95 hp 70 kW 270 N⋅m Manual FWD 1.5 MT Diesel 1499 cm³ 120 hp 88 kW 270 N⋅m Manual FWD 1.5 AT Diesel 1499 cm³ 120 hp 88 kW 270 N⋅m Automatic FWD 2.0 AT Diesel 1997 cm³ 150 hp 110 kW 370 N⋅m Automatic FWD 1.5 AT Gasoline 1497 cm³ 150 hp 110 kW 240 N⋅m Automatic FWD 2.0 MT Diesel 1996 cm³ 150 hp 110 kW 370 N⋅m Manual FWD 1.5L AT EcoBoost Gasoline 1496 cm³ 182 hp 134 kW 244 N⋅m Automatic FWD
Sedan — Ford Focus Engines and Transmissions
Sedan Ford Focus Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.0 MT Gasoline 999 cm³ 100 hp 74 kW 170 N⋅m Manual FWD 1.0 MT Gasoline 999 cm³ 125 hp 92 kW 170 N⋅m Manual FWD 1.5 AT Gasoline 1497 cm³ 150 hp 110 kW 240 N⋅m Automatic FWD 1.5 MT Gasoline 1497 cm³ 150 hp 110 kW 240 N⋅m Manual FWD 1.5 MT Diesel 1500 cm³ 95 hp 70 kW 300 N⋅m Manual FWD 1.5 MT Diesel 1500 cm³ 120 hp 88 kW 300 N⋅m Manual FWD 1.5 AT Gasoline 1497 cm³ 182 hp 134 kW 240 N⋅m Automatic FWD 1.0L AT EcoBoost Gasoline 999 cm³ 125 hp 92 kW 173 N⋅m Automatic FWD 1.5D AT EcoBlue Diesel 1500 cm³ 120 hp 88 kW 305 N⋅m Automatic FWD
Hatchback 5-door — Ford Focus Engines and Transmissions
Hatchback 5-door Ford Focus Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.0 MT Gasoline 999 cm³ 125 hp 92 kW 170 N⋅m Manual FWD 1.5 AT Diesel 1500 cm³ 120 hp 88 kW 300 N⋅m Automatic FWD 1.0 MT Gasoline 999 cm³ 85 hp 63 kW 170 N⋅m Manual FWD 1.0 MT Gasoline 999 cm³ 100 hp 74 kW 170 N⋅m Manual FWD 1.0 AT Gasoline 999 cm³ 125 hp 92 kW 170 N⋅m Automatic FWD 1.5 AT Gasoline 1497 cm³ 150 hp 110 kW 240 N⋅m Automatic FWD 1.5 MT Gasoline 1497 cm³ 150 hp 110 kW 240 N⋅m Manual FWD 1.5 MT Gasoline 1497 cm³ 182 hp 134 kW 240 N⋅m Manual FWD 1.5 MT Diesel 1500 cm³ 95 hp 70 kW 300 N⋅m Manual FWD 1.5 MT Diesel 1500 cm³ 120 hp 88 kW 300 N⋅m Manual FWD 2.0 MT Diesel 1996 cm³ 150 hp 110 kW 370 N⋅m Manual FWD 2.0 AT Diesel 1996 cm³ 150 hp 110 kW 370 N⋅m Automatic FWD 1.5L AT EcoBoost Gasoline 1496 cm³ 182 hp 134 kW 244 N⋅m Automatic FWD
Ford Focus Dimensions
Estate 5-door — Ford Focus Dimensions
Estate 5-door Ford Focus Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.0 MT 4693 mm 1844 mm 1545 mm 2700 mm Not provided 1900 kg Not provided 1.0 MT 4693 mm 1844 mm 1545 mm 2700 mm Not provided 1900 kg Not provided 1.0 AT 4693 mm 1844 mm 1545 mm 2700 mm Not provided 1900 kg Not provided 1.0 MT 4693 mm 1844 mm 1545 mm 2700 mm Not provided 1900 kg Not provided 1.5 MT 4693 mm 1844 mm 1545 mm 2700 mm Not provided 1900 kg Not provided 1.5 MT 4693 mm 1844 mm 1545 mm 2700 mm Not provided 1900 kg Not provided 1.5 MT 4693 mm 1844 mm 1545 mm 2700 mm Not provided 1900 kg Not provided 1.5 MT 4693 mm 1844 mm 1545 mm 2700 mm Not provided 1900 kg Not provided 1.5 AT 4693 mm 1844 mm 1545 mm 2700 mm Not provided 1900 kg Not provided 2.0 AT 4693 mm 1844 mm 1545 mm 2700 mm Not provided 2025 kg Not provided 1.5 AT 4693 mm 1844 mm 1545 mm 2700 mm 1445 kg 1980 kg 163 mm 2.0 MT 4693 mm 1844 mm 1545 mm 2700 mm 1553 kg 2080 kg 163 mm 1.5L AT EcoBoost 4693 mm 1844 mm 1545 mm 2700 mm 1442 kg 1905 kg 163 mm
Sedan — Ford Focus Dimensions
Sedan Ford Focus Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.0 MT 4647 mm 1825 mm 1452 mm 2700 mm 1326 kg 1735 kg Not provided 1.0 MT 4647 mm 1825 mm 1452 mm 2700 mm 1326 kg 1735 kg Not provided 1.5 AT 4647 mm 1825 mm 1452 mm 2700 mm 1384 kg 1790 kg Not provided 1.5 MT 4647 mm 1825 mm 1452 mm 2700 mm 1356 kg 1765 kg Not provided 1.5 MT 4647 mm 1825 mm 1452 mm 2700 mm 1367 kg 1775 kg Not provided 1.5 MT 4647 mm 1825 mm 1452 mm 2700 mm 1367 kg 1775 kg Not provided 1.5 AT 4647 mm 1825 mm 1452 mm 2700 mm 1404 kg 1905 kg 163 mm 1.0L AT EcoBoost 4647 mm 1825 mm 1452 mm 2700 mm 1415 kg 1785 kg 135 mm 1.5D AT EcoBlue 4647 mm 1825 mm 1452 mm 2700 mm 1439 kg 1805 kg 135 mm
Hatchback 5-door — Ford Focus Dimensions
Hatchback 5-door Ford Focus Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.0 MT 4397 mm 1844 mm 1515 mm 2700 mm 1322 kg 1855 kg 163 mm 1.5 AT 4397 mm 1844 mm 1515 mm 2700 mm 1394 kg 1910 kg 163 mm 1.0 MT 4397 mm 1844 mm 1515 mm 2700 mm 1322 kg 1855 kg 135 mm 1.0 MT 4397 mm 1844 mm 1515 mm 2700 mm 1322 kg 1855 kg 135 mm 1.0 AT 4397 mm 1844 mm 1515 mm 2700 mm 1371 kg 1905 kg 135 mm 1.5 AT 4397 mm 1844 mm 1515 mm 2700 mm 1404 kg 1905 kg 135 mm 1.5 MT 4397 mm 1844 mm 1515 mm 2700 mm 1369 kg 1890 kg 135 mm 1.5 MT 4397 mm 1844 mm 1515 mm 2700 mm 1369 kg 1890 kg 135 mm 1.5 MT 4397 mm 1844 mm 1515 mm 2700 mm Not provided 1900 kg 135 mm 1.5 MT 4397 mm 1844 mm 1515 mm 2700 mm Not provided 1900 kg 135 mm 2.0 MT 4397 mm 1844 mm 1515 mm 2700 mm Not provided 2025 kg 135 mm 2.0 AT 4397 mm 1844 mm 1515 mm 2700 mm Not provided 2025 kg 135 mm 1.5L AT EcoBoost 4397 mm 1844 mm 1515 mm 2700 mm 1442 kg 1905 kg 163 mm
Ford Focus Cargo Space
Estate 5-door — Ford Focus Cargo Space
Sedan — Ford Focus Cargo Space
Hatchback 5-door — Ford Focus Cargo Space
Ford Focus Trims and Equipment
The gasoline, automatic 1.0L AT EcoBoost Sedan has a Titanium equipment configuration. Ford Focus trim levels help you compare comfort, convenience and cabin features alongside the powertrain. When choosing a car, check its fitted equipment, since a trim name alone may not establish every feature.
