Ford Fiesta Engines and Transmissions
The Ford Fiesta engine range covers everyday needs. A 1.2-liter gasoline with a manual gearbox suits simple motoring, while the 1.3-liter automatic adds convenience. For efficiency, the 1.4-liter diesel with Powershift robotic transmission is a strong choice.
Mini 5-doors — Ford Fiesta Engines and Transmissions
Mini 5-doors Ford Fiesta Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.2 MT Gasoline 1242 cm³ 75 hp 55 kW 110 N⋅m Manual FWD 1.3 MT Gasoline 1299 cm³ 58 hp 43 kW 101 N⋅m Manual FWD 1.3 AT Gasoline 1299 cm³ 58 hp 43 kW 101 N⋅m Automatic FWD 1.3 MT Gasoline 1299 cm³ 68 hp 50 kW 108 N⋅m Manual FWD 1.4 Powershift Diesel 1399 cm³ 68 hp 50 kW 160 N⋅m Robotic FWD 1.6 AT Gasoline 1596 cm³ 101 hp 74 kW 146 N⋅m Automatic FWD 1.6 MT Gasoline 1596 cm³ 101 hp 74 kW 146 N⋅m Manual FWD 1.3 MT Gasoline 1299 cm³ 70 hp 51 kW 106 N⋅m Manual FWD 1.6 MT Diesel 1560 cm³ 90 hp 66 kW 212 N⋅m Manual FWD 1.4 MT Gasoline 1388 cm³ 80 hp 59 kW 124 N⋅m Manual FWD 1.4 Powershift Gasoline 1388 cm³ 80 hp 59 kW 124 N⋅m Robotic FWD 1.4 MT Diesel 1399 cm³ 68 hp 50 kW 160 N⋅m Manual FWD
Mini 3-doors — Ford Fiesta Engines and Transmissions
Mini 3-doors Ford Fiesta Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.3 MT Gasoline 1299 cm³ 70 hp 52 kW 106 N⋅m Manual FWD 1.4 Powershift Gasoline 1388 cm³ 80 hp 59 kW 124 N⋅m Robotic FWD 1.4 MT Gasoline 1388 cm³ 80 hp 59 kW 124 N⋅m Manual FWD 1.6 MT Gasoline 1596 cm³ 101 hp 74 kW 146 N⋅m Manual FWD 1.6 AT Gasoline 1596 cm³ 101 hp 74 kW 146 N⋅m Automatic FWD 1.2 MT Gasoline 1242 cm³ 75 hp 55 kW 110 N⋅m Manual FWD 1.3 MT Gasoline 1299 cm³ 58 hp 43 kW 101 N⋅m Manual FWD 1.3 AT Gasoline 1299 cm³ 58 hp 43 kW 101 N⋅m Automatic FWD 1.3 MT Gasoline 1299 cm³ 68 hp 50 kW 108 N⋅m Manual FWD 1.4 MT Diesel 1399 cm³ 68 hp 50 kW 160 N⋅m Manual FWD 1.4 Powershift Diesel 1399 cm³ 68 hp 50 kW 160 N⋅m Robotic FWD 1.6 MT Diesel 1560 cm³ 90 hp 66 kW 204 N⋅m Manual FWD
Ford Fiesta Dimensions
Mini 5-doors — Ford Fiesta Dimensions
Mini 5-doors Ford Fiesta Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.2 MT 3918 mm 1685 mm 1468 mm 2486 mm 1030 kg 1520 kg 140 mm 1.3 MT 3918 mm 1685 mm 1468 mm 2486 mm 1035 kg 1520 kg 140 mm 1.3 AT 3918 mm 1685 mm 1468 mm 2486 mm Not provided 1520 kg 140 mm 1.3 MT 3918 mm 1685 mm 1468 mm 2486 mm 1035 kg 1520 kg 140 mm 1.4 Powershift 3918 mm 1685 mm 1468 mm 2486 mm Not provided 1560 kg 140 mm 1.6 AT 3918 mm 1685 mm 1468 mm 2486 mm 1115 kg 1525 kg 140 mm 1.6 MT 3918 mm 1685 mm 1468 mm 2486 mm 1045 kg 1540 kg 140 mm 1.3 MT 3918 mm 1685 mm 1468 mm 2486 mm 1040 kg 1520 kg Not provided 1.6 MT 3918 mm 1685 mm 1468 mm 2486 mm 1164 kg 1555 kg 140 mm 1.4 MT 3918 mm 1685 mm 1468 mm 2486 mm 1040 kg 1530 kg 140 mm 1.4 Powershift 3918 mm 1685 mm 1468 mm 2486 mm 1102 kg 1520 kg 140 mm 1.4 MT 3918 mm 1685 mm 1468 mm 2486 mm 1022 kg Not provided 140 mm
Mini 3-doors — Ford Fiesta Dimensions
Mini 3-doors Ford Fiesta Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.3 MT 3918 mm 1685 mm 1468 mm 2486 mm 1117 kg 1530 kg 140 mm 1.4 Powershift 3918 mm 1685 mm 1468 mm 2486 mm 1108 kg 1525 kg 140 mm 1.4 MT 3918 mm 1685 mm 1468 mm 2486 mm 1102 kg 1520 kg 140 mm 1.6 MT 3918 mm 1685 mm 1468 mm 2486 mm 1115 kg 1525 kg 140 mm 1.6 AT 3918 mm 1685 mm 1468 mm 2486 mm 1140 kg 1570 kg 140 mm 1.2 MT 3918 mm 1685 mm 1468 mm 2486 mm 1030 kg 1520 kg 140 mm 1.3 MT 3918 mm 1685 mm 1468 mm 2486 mm 1035 kg 1520 kg 140 mm 1.3 AT 3918 mm 1685 mm 1468 mm 2486 mm Not provided 1520 kg 140 mm 1.3 MT 3918 mm 1685 mm 1468 mm 2486 mm 1035 kg 1520 kg 140 mm 1.4 MT 3918 mm 1685 mm 1468 mm 2486 mm 1022 kg Not provided 140 mm 1.4 Powershift 3918 mm 1685 mm 1468 mm 2486 mm Not provided 1560 kg 140 mm 1.6 MT 3918 mm 1685 mm 1468 mm 2486 mm 1085 kg 1610 kg Not provided
Ford Fiesta Cargo Space
Mini 5-doors — Ford Fiesta Cargo Space
Mini 3-doors — Ford Fiesta Cargo Space
Ford Fiesta Trims and Equipment
Ford Fiesta trim levels shape comfort and style. The 1.4 MT model, for instance, comes in Comfort and Trend versions. Comfort covers the basics, while Trend adds more conveniences, letting you pick the equipment that fits your daily drive.
