Catalog / Fiat / Stilo / 1 generation
Fiat Stilo Engines and Transmissions
Fiat Stilo engine choices emphasize everyday usability. The 1.2 manual suits city driving with straightforward operation, while the 2.5 automatic offers relaxed cruising. A 2.5 with robotic transmission provides automatic convenience in a different driving feel. All examples drive the front wheels.
Hatchback 3-door — Fiat Stilo Engines and Transmissions
Hatchback 3-door Fiat Stilo Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.2 MT Gasoline 1242 cm³ 80 hp 59 kW 114 N⋅m Manual FWD 1.4 MT Gasoline 1368 cm³ 95 hp 70 kW 128 N⋅m Manual FWD 1.6 MT Gasoline 1596 cm³ 103 hp 76 kW 145 N⋅m Manual FWD 1.8 MT Gasoline 1747 cm³ 133 hp 98 kW 162 N⋅m Manual FWD 2.5 AT Gasoline 2446 cm³ 170 hp 125 kW 221 N⋅m Automatic FWD 1.9 MT Diesel 1910 cm³ 80 hp 59 kW 196 N⋅m Manual FWD 1.9 MT Diesel 1910 cm³ 115 hp 85 kW 255 N⋅m Manual FWD 1.9 MT Diesel 1910 cm³ 140 hp 103 kW 305 N⋅m Manual FWD
Hatchback 5-door — Fiat Stilo Engines and Transmissions
Hatchback 5-door Fiat Stilo Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.2 MT Gasoline 1242 cm³ 80 hp 59 kW 114 N⋅m Manual FWD 1.4 MT Gasoline 1368 cm³ 95 hp 70 kW 128 N⋅m Manual FWD 1.6 MT Gasoline 1596 cm³ 103 hp 76 kW 145 N⋅m Manual FWD 1.8 MT Gasoline 1747 cm³ 133 hp 98 kW 162 N⋅m Manual FWD 2.5 DSG Gasoline 2446 cm³ 170 hp 125 kW 221 N⋅m Robotic FWD 1.9 MT Diesel 1910 cm³ 80 hp 59 kW 196 N⋅m Manual FWD 1.9 MT Diesel 1910 cm³ 115 hp 85 kW 255 N⋅m Manual FWD 1.9 MT Diesel 1910 cm³ 140 hp 103 kW 305 N⋅m Manual FWD
Estate 5-door — Fiat Stilo Engines and Transmissions
Estate 5-door Fiat Stilo Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.6 MT Gasoline 1596 cm³ 95 hp 70 kW 128 N⋅m Manual FWD 1.6 MT Gasoline 1596 cm³ 103 hp 76 kW 145 N⋅m Manual FWD 1.8 MT Gasoline 1747 cm³ 133 hp 98 kW 162 N⋅m Manual FWD 1.9 MT Diesel 1910 cm³ 80 hp 59 kW 196 N⋅m Manual FWD 1.9 MT Diesel 1910 cm³ 115 hp 85 kW 255 N⋅m Manual FWD 1.9 MT Diesel 1910 cm³ 140 hp 103 kW 305 N⋅m Manual FWD
Fiat Stilo Dimensions
Hatchback 3-door — Fiat Stilo Dimensions
Hatchback 3-door Fiat Stilo Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.2 MT 4182 mm 1784 mm 1475 mm 2600 mm 1090 kg 1600 kg 150 mm 1.4 MT 4182 mm 1784 mm 1475 mm 2600 mm 1090 kg 1600 kg 150 mm 1.6 MT 4182 mm 1784 mm 1475 mm 2600 mm 1195 kg 1705 kg 150 mm 1.8 MT 4182 mm 1784 mm 1475 mm 2600 mm 1240 kg 1750 kg 150 mm 2.5 AT 4182 mm 1784 mm 1475 mm 2600 mm 1265 kg 1750 kg 150 mm 1.9 MT 4182 mm 1784 mm 1475 mm 2600 mm 1250 kg 1760 kg 150 mm 1.9 MT 4182 mm 1784 mm 1475 mm 2600 mm 1265 kg 1775 kg 150 mm 1.9 MT 4182 mm 1784 mm 1475 mm 2600 mm 1285 kg 1795 kg 150 mm
Hatchback 5-door — Fiat Stilo Dimensions
Hatchback 5-door Fiat Stilo Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.2 MT 4249 mm 1760 mm 1481 mm 2601 mm 1165 kg 1656 kg 150 mm 1.4 MT 4249 mm 1760 mm 1481 mm 2601 mm 1145 kg 1650 kg 150 mm 1.6 MT 4249 mm 1760 mm 1481 mm 2601 mm 1180 kg 1715 kg 150 mm 1.8 MT 4249 mm 1760 mm 1481 mm 2601 mm 1295 kg 1800 kg 150 mm 2.5 DSG 4249 mm 1760 mm 1481 mm 2601 mm 1320 kg 1800 kg 150 mm 1.9 MT 4249 mm 1760 mm 1481 mm 2601 mm 1395 kg 1905 kg 150 mm 1.9 MT 4249 mm 1760 mm 1481 mm 2601 mm 1410 kg 1920 kg 150 mm 1.9 MT 4249 mm 1760 mm 1481 mm 2601 mm 1430 kg 1940 kg 150 mm
Estate 5-door — Fiat Stilo Dimensions
Estate 5-door Fiat Stilo Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.6 MT 4516 mm 1756 mm 1570 mm 2600 mm 1235 kg 1804 kg 150 mm 1.6 MT 4516 mm 1756 mm 1570 mm 2600 mm 1298 kg 1805 kg 150 mm 1.8 MT 4516 mm 1756 mm 1570 mm 2600 mm 1385 kg 1895 kg 150 mm 1.9 MT 4516 mm 1756 mm 1570 mm 2600 mm 1395 kg 1905 kg 150 mm 1.9 MT 4516 mm 1756 mm 1570 mm 2600 mm 1410 kg 1920 kg 150 mm 1.9 MT 4516 mm 1756 mm 1570 mm 2600 mm 1430 kg 1805 kg 150 mm
Fiat Stilo Cargo Space
Hatchback 3-door — Fiat Stilo Cargo Space
Hatchback 5-door — Fiat Stilo Cargo Space
Estate 5-door — Fiat Stilo Cargo Space
Estate 5-door Fiat Stilo Cargo Space Modification Trunk volume min Trunk volume max
1.6 MT 510 l 1480 l 1.6 MT 510 l 1480 l 1.8 MT 510 l 1480 l 1.9 MT 510 l 1480 l 1.9 MT 510 l 1480 l 1.9 MT 510 l 1480 l
