Fiat Marea Specs, Engines & Dimensions (1996–2002) — First Generation

The first-generation Fiat Marea is a practical family car in Sedan and Estate 5-door form. You choose a conventional gasoline layout and a body that suits commuting or extra load space.

← All Fiat models

Fiat Marea Engines and Transmissions

A Fiat Marea engine here is gasoline with a front-wheel-drive drivetrain. The 1.4 MT Sedan uses a manual transmission for simple commuting, while the 1.6 AT Sedan adds an automatic. The 2.5 MT Sedan is a larger manual example, not the complete powertrain range.

Sedan — Fiat Marea Engines and Transmissions

Sedan Fiat Marea Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.4 MT	Gasoline	1370 cm³	80 hp	59 kW	112 N⋅m	Manual	FWD
1.6 MT	Gasoline	1596 cm³	103 hp	76 kW	145 N⋅m	Manual	FWD
1.8 MT	Gasoline	1747 cm³	113 hp	83 kW	154 N⋅m	Manual	FWD
1.8 MT	Gasoline	1747 cm³	132 hp	97 kW	164 N⋅m	Manual	FWD
2.0 MT	Gasoline	1998 cm³	147 hp	108 kW	186 N⋅m	Manual	FWD
2.0 MT	Gasoline	1998 cm³	154 hp	113 kW	186 N⋅m	Manual	FWD
2.0 MT	Gasoline	1998 cm³	182 hp	134 kW	265 N⋅m	Manual	FWD
2.5 MT	Gasoline	2446 cm³	160 hp	118 kW	206 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	75 hp	55 kW	147 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	100 hp	74 kW	200 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	110 hp	81 kW	200 N⋅m	Manual	FWD
2.4 MT	Diesel	2387 cm³	125 hp	91 kW	265 N⋅m	Manual	FWD
2.4 MT	Diesel	2387 cm³	131 hp	96 kW	304 N⋅m	Manual	FWD
1.6 AT	Gasoline	1581 cm³	103 hp	76 kW	144 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1581 cm³	103 hp	76 kW	144 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	105 hp	77 kW	200 N⋅m	Manual	FWD

Estate 5-door — Fiat Marea Engines and Transmissions

Estate 5-door Fiat Marea Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.4 MT	Gasoline	1370 cm³	80 hp	59 kW	112 N⋅m	Manual	FWD
1.6 MT	Gasoline	1596 cm³	103 hp	76 kW	145 N⋅m	Manual	FWD
1.8 MT	Gasoline	1747 cm³	113 hp	83 kW	154 N⋅m	Manual	FWD
1.8 MT	Gasoline	1747 cm³	132 hp	97 kW	164 N⋅m	Manual	FWD
2.0 MT	Gasoline	1988 cm³	154 hp	113 kW	186 N⋅m	Manual	FWD
2.0 MT	Gasoline	1998 cm³	147 hp	108 kW	186 N⋅m	Manual	FWD
2.0 MT	Gasoline	1998 cm³	182 hp	134 kW	265 N⋅m	Manual	FWD
2.5 MT	Gasoline	2446 cm³	160 hp	118 kW	206 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	75 hp	55 kW	147 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	100 hp	74 kW	200 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	105 hp	77 kW	200 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	110 hp	81 kW	200 N⋅m	Manual	FWD
2.4 MT	Diesel	2387 cm³	125 hp	91 kW	265 N⋅m	Manual	FWD
2.4 MT	Diesel	2387 cm³	131 hp	96 kW	304 N⋅m	Manual	FWD
1.6 AT	Gasoline	1596 cm³	103 hp	76 kW	145 N⋅m	Automatic	FWD

Fiat Marea Dimensions

Sedan — Fiat Marea Dimensions

Sedan Fiat Marea Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.4 MT	4390 mm	1741 mm	1420 mm	2540 mm	1085 kg	1675 kg	120 mm
1.6 MT	4390 mm	1741 mm	1420 mm	2540 mm	1145 kg	1795 kg	130 mm
1.8 MT	4390 mm	1741 mm	1420 mm	2540 mm	1170 kg	1785 kg	130 mm
1.8 MT	4390 mm	1741 mm	1420 mm	2540 mm	1195 kg	1785 kg	120 mm
2.0 MT	4390 mm	1741 mm	1420 mm	2540 mm	1255 kg	1830 kg	130 mm
2.0 MT	4390 mm	1741 mm	1420 mm	2540 mm	1230 kg	1830 kg	130 mm
2.0 MT	4390 mm	1741 mm	1420 mm	2540 mm	1310 kg	1780 kg	130 mm
2.5 MT	4390 mm	1741 mm	1420 mm	2540 mm	1300 kg	1780 kg	120 mm
1.9 MT	4390 mm	1741 mm	1420 mm	2540 mm	1160 kg	1775 kg	130 mm
1.9 MT	4390 mm	1741 mm	1420 mm	2540 mm	1190 kg	1780 kg	130 mm
1.9 MT	4390 mm	1741 mm	1420 mm	2540 mm	1220 kg	1805 kg	130 mm
2.4 MT	4390 mm	1741 mm	1420 mm	2540 mm	1280 kg	1870 kg	130 mm
2.4 MT	4390 mm	1741 mm	1420 mm	2540 mm	1280 kg	1870 kg	120 mm
1.6 AT	4390 mm	1741 mm	1420 mm	2540 mm	1140 kg	1730 kg	120 mm
1.6 MT	4390 mm	1741 mm	1420 mm	2540 mm	1260 kg	1750 kg	120 mm
1.9 MT	4390 mm	1741 mm	1420 mm	2540 mm	1215 kg	1800 kg	120 mm

Estate 5-door — Fiat Marea Dimensions

Estate 5-door Fiat Marea Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.4 MT	4490 mm	1741 mm	1500 mm	2540 mm	1145 kg	1740 kg	120 mm
1.6 MT	4490 mm	1741 mm	1500 mm	2540 mm	1205 kg	1795 kg	119 mm
1.8 MT	4490 mm	1741 mm	1500 mm	2540 mm	1230 kg	1850 kg	119 mm
1.8 MT	4490 mm	1741 mm	1500 mm	2540 mm	1255 kg	1850 kg	120 mm
2.0 MT	4490 mm	1741 mm	1500 mm	2540 mm	1290 kg	1895 kg	119 mm
2.0 MT	4490 mm	1741 mm	1500 mm	2540 mm	1315 kg	1895 kg	119 mm
2.0 MT	4490 mm	1741 mm	1500 mm	2540 mm	1360 kg	1795 kg	119 mm
2.5 MT	4490 mm	1741 mm	1500 mm	2540 mm	1350 kg	1850 kg	120 mm
1.9 MT	4490 mm	1741 mm	1500 mm	2540 mm	1220 kg	1840 kg	119 mm
1.9 MT	4490 mm	1741 mm	1500 mm	2540 mm	1250 kg	1845 kg	119 mm
1.9 MT	4490 mm	1741 mm	1500 mm	2540 mm	1250 kg	1845 kg	119 mm
1.9 MT	4490 mm	1741 mm	1500 mm	2540 mm	1280 kg	1870 kg	119 mm
2.4 MT	4490 mm	1741 mm	1500 mm	2540 mm	1340 kg	1935 kg	119 mm
2.4 MT	4490 mm	1741 mm	1500 mm	2540 mm	1310 kg	1935 kg	120 mm
1.6 AT	4490 mm	1741 mm	1500 mm	2540 mm	1175 kg	1895 kg	120 mm

Fiat Marea Cargo Space

Sedan — Fiat Marea Cargo Space

Sedan Fiat Marea Cargo Space
Modification	Trunk volume min
1.4 MT	430 l
1.6 MT	430 l
1.8 MT	430 l
1.8 MT	430 l
2.0 MT	430 l
2.0 MT	430 l
2.0 MT	430 l
2.5 MT	430 l
1.9 MT	430 l
1.9 MT	430 l
1.9 MT	430 l
2.4 MT	430 l
2.4 MT	430 l
1.6 AT	430 l
1.6 MT	430 l
1.9 MT	430 l

Estate 5-door — Fiat Marea Cargo Space

Estate 5-door Fiat Marea Cargo Space
Modification	Trunk volume min
1.4 MT	1200 l
1.6 MT	1200 l
1.8 MT	1200 l
1.8 MT	1200 l
2.0 MT	1200 l
2.0 MT	1200 l
2.0 MT	1200 l
2.5 MT	1200 l
1.9 MT	1200 l
1.9 MT	1200 l
1.9 MT	1200 l
1.9 MT	1200 l
2.4 MT	1200 l
2.4 MT	1200 l
1.6 AT	1200 l

Fiat Marea Trims and Equipment

Fiat Marea trim levels sit on a named technical version rather than replacing it. The 1.6 AT Sedan, for example, was offered with ELX and SX equipment packs that alter cabin fittings. You choose those trims for kit, while the underlying automatic layout stays put.

Fiat Marea Trims and Equipment
Modification	Body	Equipment
1.6 MT	Sedan	ELX
1.6 AT	Sedan	ELX
1.6 AT	Sedan	SX
1.6 MT	Sedan	SX
1.9 MT	Sedan	SX
1.6 MT	Estate 5-door	SX
1.6 AT	Estate 5-door	ELX
