Fiat 127 Specs, Engines & Dimensions (1971–1987)

Fiat 127 Engines and Transmissions

Fiat 127 engines focus on simplicity and everyday efficiency. The 1.1-liter gasoline engine with manual transmission suits city commutes and light loads, offering straightforward operation. For those needing more low-end pull, especially in the Estate, the 1.3-liter diesel provides economical long-distance cruising. The 1.3-liter gasoline in the Mini delivers responsive performance. All configurations drive the rear wheels, giving the 127 a classic feel.

Estate 3-door — Fiat 127 Engines and Transmissions

Estate 3-door Fiat 127 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.1 MT	Gasoline	1049 cm³	50 hp	37 kW	77 N⋅m	Manual	RWD
1.3 MT	Diesel	1301 cm³	45 hp	33 kW	112 N⋅m	Manual	RWD

Mini 3-doors — Fiat 127 Engines and Transmissions

Mini 3-doors Fiat 127 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
0.9 MT	Gasoline	903 cm³	45 hp	33 kW	66 N⋅m	Manual	RWD
1.1 MT	Gasoline	1049 cm³	50 hp	37 kW	77 N⋅m	Manual	RWD
1.1 MT	Gasoline	1049 cm³	70 hp	51 kW	83 N⋅m	Manual	RWD
1.3 MT	Gasoline	1301 cm³	75 hp	55 kW	103 N⋅m	Manual	RWD
1.3 MT	Diesel	1301 cm³	45 hp	33 kW	112 N⋅m	Manual	RWD
0.9 MT	Gasoline	903 cm³	40 hp	29 kW	64 N⋅m	Manual	RWD

Fiat 127 Dimensions

Estate 3-door — Fiat 127 Dimensions

Estate 3-door Fiat 127 Dimensions
Modification	Length	Width	Height	Wheelbase	Ground clearance, minimum
1.1 MT	3650 mm	1527 mm	1360 mm	2225 mm	130 mm
1.3 MT	3650 mm	1527 mm	1360 mm	2225 mm	130 mm

Mini 3-doors — Fiat 127 Dimensions

Mini 3-doors Fiat 127 Dimensions
Modification	Length	Width	Height	Wheelbase	Ground clearance, minimum
0.9 MT	3594 mm	1524 mm	1372 mm	2223 mm	130 mm
1.1 MT	3594 mm	1524 mm	1372 mm	2223 mm	130 mm
1.1 MT	3594 mm	1524 mm	1372 mm	2223 mm	130 mm
1.3 MT	3594 mm	1524 mm	1372 mm	2223 mm	130 mm
1.3 MT	3594 mm	1524 mm	1372 mm	2223 mm	130 mm
0.9 MT	3594 mm	1524 mm	1372 mm	2223 mm	130 mm
