Chrysler Grand Voyager Engines and Transmissions
Every Chrysler Grand Voyager engine here is a petrol V6 paired with an automatic transmission and front-wheel drive, as seen in the 3.3 AT, 3.8 AT and 3.6 AT. Larger displacement generally means easier pulling with a full cabin and luggage, rather than sporting pace.
Minivan — Chrysler Grand Voyager Engines and Transmissions
| Modification | Engine type | Engine capacity | Maximum power | Maximum power, kw | Maximum torque N⋅m | Transmission | Type of drive |
|---|---|---|---|---|---|---|---|
| 3.6 AT | Gasoline | 3600 cm³ | 283 hp | 208 kW | 352 N⋅m | Automatic | FWD |
| 2.8 AT | Diesel | 2768 cm³ | 150 hp | 110 kW | 360 N⋅m | Automatic | FWD |
| 2.8 AT | Diesel | 2768 cm³ | 163 hp | 120 kW | 360 N⋅m | Automatic | FWD |
| 3.8 AT | Gasoline | 3778 cm³ | 193 hp | 142 kW | 305 N⋅m | Automatic | FWD |
| 3.3 AT | Gasoline | 3301 cm³ | 174 hp | 128 kW | 278 N⋅m | Automatic | FWD |
Chrysler Grand Voyager Dimensions
Minivan — Chrysler Grand Voyager Dimensions
| Modification | Length | Width | Height | Wheelbase | Curb weight | Max weight | Ground clearance, minimum |
|---|---|---|---|---|---|---|---|
| 3.6 AT | 5143 mm | 1954 mm | 1750 mm | 3078 mm | Not provided | Not provided | 130 mm |
| 2.8 AT | 5143 mm | 1954 mm | 1750 mm | 3078 mm | 2100 kg | 2775 kg | 130 mm |
| 2.8 AT | 5143 mm | 1954 mm | 1750 mm | 3078 mm | 2100 kg | 2775 kg | 130 mm |
| 3.8 AT | 5143 mm | 1954 mm | 1750 mm | 3078 mm | 2085 kg | 2700 kg | 130 mm |
| 3.3 AT | 5143 mm | 1954 mm | 1750 mm | 3078 mm | Not provided | Not provided | 130 mm |
Chrysler Grand Voyager Cargo Space
Minivan — Chrysler Grand Voyager Cargo Space
Chrysler Grand Voyager Trims and Equipment
Chrysler Grand Voyager trim levels sit on top of a technical version, so the same 3.8 AT drivetrain can arrive as Limited or Touring LS. The mechanical package stays the same; what changes is comfort, seating and convenience equipment, so check each individual car's listed specification.
