Chrysler Grand Voyager Specs, Engines & Dimensions (2000–2004)

Chrysler Grand Voyager Engines and Transmissions

Most buyers meet this Chrysler Grand Voyager engine range through petrol V6 units such as the 3.3 and 3.8, paired with an automatic transmission that suits a heavy, fully loaded minivan. A 2.5 diesel with a manual gearbox serves drivers chasing lower fuel bills, while the drivetrain is usually front-wheel drive, with all-wheel-drive versions also offered.

Minivan — Chrysler Grand Voyager Engines and Transmissions

Minivan Chrysler Grand Voyager Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.4 MT	Gasoline	2429 cm³	147 hp	108 kW	218 N⋅m	Manual	FWD
2.4 AT	Gasoline	2429 cm³	147 hp	108 kW	218 N⋅m	Automatic	FWD
2.4 AT	Gasoline	2429 cm³	150 hp	110 kW	226 N⋅m	Automatic	FWD
2.4 AT	Gasoline	2429 cm³	152 hp	112 kW	226 N⋅m	Automatic	FWD
2.4 MT	Gasoline	2429 cm³	152 hp	112 kW	226 N⋅m	Manual	FWD
3.8 AT	Gasoline	3778 cm³	218 hp	160 kW	332 N⋅m	Automatic	FWD
2.5 MT	Diesel	2499 cm³	141 hp	105 kW	320 N⋅m	Manual	FWD
3.3 AT	Gasoline	3301 cm³	174 hp	128 kW	278 N⋅m	Automatic	AWD
3.8 AT	Gasoline	3778 cm³	218 hp	160 kW	332 N⋅m	Automatic	AWD
2.5 AT	Diesel	2499 cm³	141 hp	105 kW	320 N⋅m	Automatic	FWD
3.3 AT	Gasoline	3301 cm³	174 hp	128 kW	278 N⋅m	Automatic	FWD

Chrysler Grand Voyager Dimensions

Minivan — Chrysler Grand Voyager Dimensions

Minivan Chrysler Grand Voyager Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.4 MT	4805 mm	1995 mm	1750 mm	2880 mm	1750 kg	2450 kg	140 mm
2.4 AT	4805 mm	1995 mm	1750 mm	2880 mm	1750 kg	2450 kg	140 mm
2.4 AT	4805 mm	1995 mm	1750 mm	2880 mm	Not provided	2450 kg	140 mm
2.4 AT	4805 mm	1995 mm	1750 mm	2880 mm	Not provided	2450 kg	140 mm
2.4 MT	4805 mm	1995 mm	1750 mm	2880 mm	1750 kg	2450 kg	140 mm
3.8 AT	4805 mm	1995 mm	1750 mm	2880 mm	1800 kg	2450 kg	140 mm
2.5 MT	4805 mm	1995 mm	1750 mm	2880 mm	1850 kg	2570 kg	140 mm
3.3 AT	4805 mm	1995 mm	1750 mm	2880 mm	2165 kg	2670 kg	140 mm
3.8 AT	4805 mm	1995 mm	1750 mm	2880 mm	1950 kg	2450 kg	140 mm
2.5 AT	4805 mm	1995 mm	1750 mm	2880 mm	1850 kg	2570 kg	140 mm
3.3 AT	4805 mm	1995 mm	1750 mm	2880 mm	1800 kg	2450 kg	140 mm

Chrysler Grand Voyager Cargo Space

Minivan — Chrysler Grand Voyager Cargo Space

Minivan Chrysler Grand Voyager Cargo Space
Modification	Trunk volume min	Trunk volume max
2.4 MT	445 l	4080 l
2.4 AT	445 l	4080 l
2.4 AT	445 l	4080 l
2.4 AT	445 l	4080 l
2.4 MT	445 l	4080 l
3.8 AT	445 l	4080 l
2.5 MT	445 l	4080 l
3.3 AT	445 l	4080 l
3.8 AT	445 l	4080 l
2.5 AT	445 l	4080 l
3.3 AT	445 l	4080 l
