Catalog / Chevrolet / S-10 Pickup / 3 generation
Chevrolet S-10 Pickup Engines and Transmissions
Among Chevrolet S-10 Pickup engine choices, double-cab examples include the gasoline 2.4 MT and diesel 2.8 MT, both with manual transmissions and rear-wheel drive. The diesel 2.8 AT pairs an automatic transmission with all-wheel drive, easing your workload in traffic and helping traction on loose surfaces.
Pickup double-cab — Chevrolet S-10 Pickup Engines and Transmissions
Pickup double-cab Chevrolet S-10 Pickup Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.4 MT Gasoline 2405 cm³ 147 hp 108 kW Not provided Manual RWD 2.8 MT Diesel 2776 cm³ 180 hp 132 kW 470 N⋅m Manual RWD 2.5 MT Gasoline 2457 cm³ 200 hp 147 kW 259 N⋅m Manual RWD 3.6 MT Gasoline 2776 cm³ 305 hp 224 kW 365 N⋅m Manual RWD 2.4 AT Gasoline 2405 cm³ 147 hp 108 kW Not provided Automatic RWD 2.5 AT Gasoline 2457 cm³ 200 hp 147 kW 259 N⋅m Automatic RWD 3.6 AT Gasoline 2776 cm³ 305 hp 224 kW 365 N⋅m Automatic RWD 2.8 AT Diesel 2776 cm³ 180 hp 132 kW 470 N⋅m Automatic RWD 2.4 AT Gasoline 2405 cm³ 147 hp 108 kW Not provided Automatic AWD 2.4 MT Gasoline 2405 cm³ 147 hp 108 kW Not provided Manual AWD 2.5 AT Gasoline 2457 cm³ 200 hp 147 kW 259 N⋅m Automatic AWD 2.5 MT Gasoline 2457 cm³ 200 hp 147 kW 259 N⋅m Manual AWD 3.6 AT Gasoline 2776 cm³ 305 hp 224 kW 365 N⋅m Automatic AWD 3.6 MT Gasoline 2776 cm³ 305 hp 224 kW 365 N⋅m Manual AWD 2.8 AT Diesel 2776 cm³ 180 hp 132 kW 470 N⋅m Automatic AWD 2.8 MT Diesel 2776 cm³ 180 hp 132 kW 470 N⋅m Manual AWD
Pickup single-cab — Chevrolet S-10 Pickup Engines and Transmissions
Pickup single-cab Chevrolet S-10 Pickup Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.4 MT Gasoline 2405 cm³ 147 hp 108 kW Not provided Manual RWD 2.8 MT Diesel 2776 cm³ 180 hp 132 kW 470 N⋅m Manual RWD 2.5 MT Gasoline 2457 cm³ 200 hp 147 kW 259 N⋅m Manual RWD 3.6 MT Gasoline 2776 cm³ 305 hp 224 kW 365 N⋅m Manual RWD 2.4 AT Gasoline 2405 cm³ 147 hp 108 kW Not provided Automatic RWD 2.5 AT Gasoline 2457 cm³ 200 hp 147 kW 259 N⋅m Automatic RWD 3.6 AT Gasoline 2776 cm³ 305 hp 224 kW 365 N⋅m Automatic RWD 2.8 AT Diesel 2776 cm³ 180 hp 132 kW 470 N⋅m Automatic RWD 2.4 AT Gasoline 2405 cm³ 147 hp 108 kW Not provided Automatic AWD 2.4 MT Gasoline 2405 cm³ 147 hp 108 kW Not provided Manual AWD 2.5 AT Gasoline 2457 cm³ 200 hp 147 kW 259 N⋅m Automatic AWD 2.5 MT Gasoline 2457 cm³ 200 hp 147 kW 259 N⋅m Manual AWD 3.6 AT Gasoline 2776 cm³ 305 hp 224 kW 365 N⋅m Automatic AWD 3.6 MT Gasoline 2776 cm³ 305 hp 224 kW 365 N⋅m Manual AWD 2.8 AT Diesel 2776 cm³ 180 hp 132 kW 470 N⋅m Automatic AWD 2.8 MT Diesel 2776 cm³ 180 hp 132 kW 470 N⋅m Manual AWD
Chevrolet S-10 Pickup Dimensions
Pickup double-cab — Chevrolet S-10 Pickup Dimensions
Pickup double-cab Chevrolet S-10 Pickup Dimensions Modification Length Width Height Wheelbase Curb weight Max weight 2.4 MT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.8 MT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.5 MT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 3.6 MT 4490 mm 1682 mm 1643 mm 2718 mm 1902 kg 2631 kg 2.4 AT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.5 AT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 3.6 AT 4490 mm 1682 mm 1643 mm 2718 mm 1902 kg 2631 kg 2.8 AT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.4 AT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.4 MT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.5 AT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.5 MT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 3.6 AT 4490 mm 1682 mm 1643 mm 2718 mm 1902 kg 2631 kg 3.6 MT 4490 mm 1682 mm 1643 mm 2718 mm 1902 kg 2631 kg 2.8 AT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.8 MT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided
Pickup single-cab — Chevrolet S-10 Pickup Dimensions
Pickup single-cab Chevrolet S-10 Pickup Dimensions Modification Length Width Height Wheelbase Curb weight Max weight 2.4 MT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.8 MT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.5 MT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 3.6 MT 4490 mm 1682 mm 1643 mm 2718 mm 1902 kg 2631 kg 2.4 AT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.5 AT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 3.6 AT 4490 mm 1682 mm 1643 mm 2718 mm 1902 kg 2631 kg 2.8 AT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.4 AT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.4 MT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.5 AT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.5 MT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 3.6 AT 4490 mm 1682 mm 1643 mm 2718 mm 1902 kg 2631 kg 3.6 MT 4490 mm 1682 mm 1643 mm 2718 mm 1902 kg 2631 kg 2.8 AT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided 2.8 MT 4490 mm 1682 mm 1643 mm 2718 mm Not provided Not provided
