Caterham Seven Specs, Engines & Dimensions (from 1992)

Caterham Seven Engines and Transmissions

The Caterham Seven engine choices here are gasoline units with a manual transmission and rear-wheel drive. The 1.4 MT Roadster is the smaller-displacement everyday option, while the 2.0 MT Roadster uses extra displacement for stronger pull. Both keep the drivetrain simple so you feel every gear change.

Roadster — Caterham Seven Engines and Transmissions

Roadster Caterham Seven Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.4 MT	Gasoline	1396 cm³	106 hp	78 kW	128 N⋅m	Manual	RWD
1.6 MT	Gasoline	1588 cm³	115 hp	85 kW	150 N⋅m	Manual	RWD
1.6 MT	Gasoline	1588 cm³	133 hp	98 kW	149 N⋅m	Manual	RWD
1.6 MT	Gasoline	1596 cm³	125 hp	92 kW	159 N⋅m	Manual	RWD
1.8 MT	Gasoline	1795 cm³	124 hp	91 kW	165 N⋅m	Manual	RWD
1.8 MT	Gasoline	1795 cm³	140 hp	103 kW	167 N⋅m	Manual	RWD
1.8 MT	Gasoline	1795 cm³	153 hp	113 kW	174 N⋅m	Manual	RWD
1.8 MT	Gasoline	1795 cm³	193 hp	142 kW	203 N⋅m	Manual	RWD
1.8 MT	Gasoline	1795 cm³	232 hp	171 kW	210 N⋅m	Manual	RWD
2.0 MT	Gasoline	1999 cm³	175 hp	129 kW	190 N⋅m	Manual	RWD

Caterham Seven Dimensions

Roadster — Caterham Seven Dimensions

Roadster Caterham Seven Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.4 MT	3380 mm	1580 mm	1120 mm	2230 mm	540 kg	Not provided	100 mm
1.6 MT	3380 mm	1580 mm	1120 mm	2230 mm	550 kg	860 kg	100 mm
1.6 MT	3380 mm	1580 mm	1120 mm	2230 mm	550 kg	860 kg	100 mm
1.6 MT	3380 mm	1580 mm	1120 mm	2230 mm	540 kg	Not provided	100 mm
1.8 MT	3380 mm	1580 mm	1120 mm	2230 mm	550 kg	860 kg	100 mm
1.8 MT	3380 mm	1580 mm	1120 mm	2230 mm	550 kg	860 kg	100 mm
1.8 MT	3380 mm	1580 mm	1120 mm	2230 mm	530 kg	860 kg	100 mm
1.8 MT	3380 mm	1580 mm	1120 mm	2230 mm	Not provided	850 kg	100 mm
1.8 MT	3380 mm	1580 mm	1120 mm	2230 mm	Not provided	Not provided	100 mm
2.0 MT	3380 mm	1580 mm	1120 mm	2230 mm	550 kg	Not provided	100 mm

Caterham Seven Cargo Space

Roadster — Caterham Seven Cargo Space

Roadster Caterham Seven Cargo Space
Modification	Trunk volume min
1.4 MT	75 l
1.6 MT	75 l
1.6 MT	75 l
1.6 MT	75 l
1.8 MT	75 l
1.8 MT	75 l
1.8 MT	75 l
1.8 MT	75 l
1.8 MT	75 l
2.0 MT	75 l
