BMW X3 Specs, Engines & Dimensions (2003–2006)

BMW X3 Engines and Transmissions

BMW X3 engine options include diesel and gasoline choices. Selected examples include the diesel manual 2.0d 2.0 MT xDrive, gasoline manual 2.0i 2.0 MT xDrive and gasoline automatic 3.0i 3.0 AT xDrive. All three have all-wheel drive; the automatic saves you repeated clutch operation and gear changes in traffic.

SUV 5-doors — BMW X3 Engines and Transmissions

SUV 5-doors BMW X3 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0d 2.0 MT xDrive	Diesel	1995 cm³	150 hp	110 kW	330 N⋅m	Manual	AWD
3.0d 3.0 MT xDrive	Diesel	2993 cm³	204 hp	150 kW	410 N⋅m	Manual	AWD
3.0d 3.0 MT xDrive	Diesel	2993 cm³	218 hp	160 kW	500 N⋅m	Manual	AWD
3.0d 3.0 AT xDrive	Diesel	2993 cm³	218 hp	160 kW	500 N⋅m	Automatic	AWD
2.0i 2.0 MT xDrive	Gasoline	1995 cm³	150 hp	110 kW	200 N⋅m	Manual	AWD
2.5i 2.5 AT xDrive	Gasoline	2494 cm³	184 hp	137 kW	237 N⋅m	Automatic	AWD
2.5i 2.5 MT xDrive	Gasoline	2494 cm³	184 hp	137 kW	237 N⋅m	Manual	AWD
2.5i 2.5 MT xDrive	Gasoline	2494 cm³	192 hp	141 kW	245 N⋅m	Manual	AWD
3.0i 3.0 MT xDrive	Gasoline	2979 cm³	231 hp	170 kW	300 N⋅m	Manual	AWD
3.0d 3.0 AT xDrive	Diesel	2993 cm³	204 hp	150 kW	410 N⋅m	Automatic	AWD
2.5i 2.5 AT xDrive	Gasoline	2494 cm³	192 hp	141 kW	245 N⋅m	Automatic	AWD
3.0i 3.0 AT xDrive	Gasoline	2979 cm³	231 hp	170 kW	300 N⋅m	Automatic	AWD

BMW X3 Dimensions

SUV 5-doors — BMW X3 Dimensions

SUV 5-doors BMW X3 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0d 2.0 MT xDrive	4569 mm	1853 mm	1674 mm	2795 mm	1750 kg	2265 kg	200 mm
3.0d 3.0 MT xDrive	4569 mm	1853 mm	1674 mm	2795 mm	1835 kg	2350 kg	200 mm
3.0d 3.0 MT xDrive	4569 mm	1853 mm	1674 mm	2795 mm	1880 kg	2350 kg	200 mm
3.0d 3.0 AT xDrive	4569 mm	1853 mm	1674 mm	2795 mm	1925 kg	2355 kg	200 mm
2.0i 2.0 MT xDrive	4569 mm	1853 mm	1674 mm	2795 mm	1660 kg	2200 kg	200 mm
2.5i 2.5 AT xDrive	4569 mm	1853 mm	1674 mm	2795 mm	1840 kg	2265 kg	200 mm
2.5i 2.5 MT xDrive	4569 mm	1853 mm	1674 mm	2795 mm	1815 kg	2265 kg	200 mm
2.5i 2.5 MT xDrive	4569 mm	1853 mm	1674 mm	2795 mm	1815 kg	2240 kg	200 mm
3.0i 3.0 MT xDrive	4569 mm	1853 mm	1674 mm	2795 mm	1835 kg	2260 kg	200 mm
3.0d 3.0 AT xDrive	4569 mm	1853 mm	1674 mm	2795 mm	1925 kg	2355 kg	200 mm
2.5i 2.5 AT xDrive	4569 mm	1853 mm	1674 mm	2795 mm	1815 kg	2270 kg	200 mm
3.0i 3.0 AT xDrive	4569 mm	1853 mm	1674 mm	2795 mm	1770 kg	2280 kg	200 mm

BMW X3 Cargo Space

SUV 5-doors — BMW X3 Cargo Space

SUV 5-doors BMW X3 Cargo Space
Modification	Trunk volume min
2.0d 2.0 MT xDrive	500 l
3.0d 3.0 MT xDrive	500 l
3.0d 3.0 MT xDrive	500 l
3.0d 3.0 AT xDrive	500 l
2.0i 2.0 MT xDrive	500 l
2.5i 2.5 AT xDrive	500 l
2.5i 2.5 MT xDrive	500 l
2.5i 2.5 MT xDrive	500 l
3.0i 3.0 MT xDrive	500 l
3.0d 3.0 AT xDrive	500 l
2.5i 2.5 AT xDrive	500 l
3.0i 3.0 AT xDrive	500 l

BMW X3 Trims and Equipment

When comparing BMW X3 trim levels, look beyond the version name to the equipment fitted. On the 3.0i 3.0 AT xDrive, the xDrive designation alone does not establish every comfort or convenience feature. Check each car for the upholstery, climate controls and parking aids you want.

BMW X3 Trims and Equipment
Modification	Body	Equipment
3.0d 3.0 AT xDrive	SUV 5-doors	xDrive
3.0i 3.0 AT xDrive	SUV 5-doors	xDrive
