Catalog / BMW / 5 series / 4 generation, restyling
BMW 5 Series Engines and Transmissions
Diesel and gasoline options provide a balance of efficiency and performance. Rear-wheel drive is standard, with a manual or automatic transmission. The 520d uses a 2.0-liter diesel for strong low-end torque, while the 525i offers a 2.5-liter gasoline engine with smooth power delivery.
Sedan — BMW 5 Series Engines and Transmissions
Sedan BMW 5 Series Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 520d 2.0 AT Diesel 1951 cm³ 136 hp 100 kW 280 N⋅m Automatic RWD 520d 2.0 MT Diesel 1951 cm³ 136 hp 100 kW 280 N⋅m Manual RWD 525d 2.5 MT Diesel 2497 cm³ 163 hp 120 kW 350 N⋅m Manual RWD 530d 2.9 MT Diesel 2926 cm³ 193 hp 142 kW 410 N⋅m Manual RWD 525i 2.5 MT Gasoline 2494 cm³ 192 hp 141 kW 245 N⋅m Manual RWD 535i 3.5 MT Gasoline 3498 cm³ 245 hp 180 kW 345 N⋅m Manual RWD 535i 3.5 AT Gasoline 3498 cm³ 245 hp 180 kW 345 N⋅m Automatic RWD 540i 4.4 MT Gasoline 4398 cm³ 286 hp 210 kW 420 N⋅m Manual RWD 525d 2.5 AT Diesel 2497 cm³ 163 hp 120 kW 350 N⋅m Automatic RWD 530d 2.9 AT Diesel 2926 cm³ 193 hp 142 kW 410 N⋅m Automatic RWD 523i 2.2 MT Gasoline 2171 cm³ 170 hp 125 kW 210 N⋅m Manual RWD 523i 2.2 AT Gasoline 2171 cm³ 170 hp 125 kW 210 N⋅m Automatic RWD 525i 2.5 AT Gasoline 2494 cm³ 192 hp 141 kW 245 N⋅m Automatic RWD 530i 3.0 MT Gasoline 2979 cm³ 231 hp 170 kW 300 N⋅m Manual RWD 530i 3.0 AT Gasoline 2979 cm³ 231 hp 170 kW 300 N⋅m Automatic RWD 540i 4.4 AT Gasoline 4398 cm³ 286 hp 210 kW 420 N⋅m Automatic RWD
Estate 5-door — BMW 5 Series Engines and Transmissions
Estate 5-door BMW 5 Series Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 520d 2.0 MT Diesel 1951 cm³ 136 hp 100 kW 280 N⋅m Manual RWD 525d 2.5 MT Diesel 2497 cm³ 163 hp 120 kW 350 N⋅m Manual RWD 525d 2.5 AT Diesel 2497 cm³ 163 hp 120 kW 350 N⋅m Automatic RWD 530d 2.9 MT Diesel 2926 cm³ 193 hp 142 kW 410 N⋅m Manual RWD 530d 2.9 AT Diesel 2926 cm³ 193 hp 142 kW 410 N⋅m Automatic RWD 520i 2.2 MT Gasoline 2171 cm³ 170 hp 125 kW 210 N⋅m Manual RWD 520i 2.2 AT Gasoline 2171 cm³ 170 hp 125 kW 210 N⋅m Automatic RWD 525i 2.5 MT Gasoline 2494 cm³ 192 hp 141 kW 245 N⋅m Manual RWD 525i 2.5 AT Gasoline 2494 cm³ 192 hp 141 kW 245 N⋅m Automatic RWD 530i 3.0 MT Gasoline 2979 cm³ 231 hp 170 kW 300 N⋅m Manual RWD 530i 3.0 AT Gasoline 2979 cm³ 231 hp 170 kW 300 N⋅m Automatic RWD 540i 4.4 MT Gasoline 4398 cm³ 286 hp 210 kW 440 N⋅m Manual RWD 540i 4.4 AT Gasoline 4398 cm³ 286 hp 210 kW 440 N⋅m Automatic RWD
BMW 5 Series Dimensions
Sedan — BMW 5 Series Dimensions
Sedan BMW 5 Series Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 520d 2.0 AT 4775 mm 1800 mm 1435 mm 2830 mm 1490 kg 2000 kg 120 mm 520d 2.0 MT 4775 mm 1800 mm 1435 mm 2830 mm 1490 kg 2000 kg 120 mm 525d 2.5 MT 4775 mm 1800 mm 1435 mm 2830 mm 1595 kg 2135 kg 120 mm 530d 2.9 MT 4775 mm 1800 mm 1435 mm 2830 mm 1625 kg 2165 kg 120 mm 525i 2.5 MT 4775 mm 1800 mm 1435 mm 2830 mm 1575 kg 2010 kg 120 mm 535i 3.5 MT 4775 mm 1800 mm 1435 mm 2830 mm 1535 kg 2150 kg 120 mm 535i 3.5 AT 4775 mm 1800 mm 1435 mm 2830 mm Not provided 2150 kg 120 mm 540i 4.4 MT 4775 mm 1800 mm 1435 mm 2830 mm 1585 kg 2170 kg 120 mm 525d 2.5 AT 4775 mm 1800 mm 1435 mm 2830 mm 1595 kg 2135 kg 120 mm 530d 2.9 AT 4775 mm 1800 mm 1435 mm 2830 mm 1625 kg 2165 kg 120 mm 523i 2.2 MT 4775 mm 1800 mm 1435 mm 2830 mm 1495 kg 2005 kg 120 mm 523i 2.2 AT 4775 mm 1800 mm 1435 mm 2830 mm 1495 kg 2005 kg 120 mm 525i 2.5 AT 4775 mm 1800 mm 1435 mm 2830 mm 1575 kg 2040 kg 120 mm 530i 3.0 MT 4775 mm 1800 mm 1435 mm 2830 mm 1530 kg 2070 kg 120 mm 530i 3.0 AT 4775 mm 1800 mm 1435 mm 2830 mm 1530 kg 2070 kg 120 mm 540i 4.4 AT 4775 mm 1800 mm 1435 mm 2830 mm 1615 kg 2220 kg 120 mm
Estate 5-door — BMW 5 Series Dimensions
Estate 5-door BMW 5 Series Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 520d 2.0 MT 4805 mm 1800 mm 1445 mm 2830 mm 1595 kg 2195 kg 120 mm 525d 2.5 MT 4805 mm 1800 mm 1445 mm 2830 mm 1705 kg 2305 kg 120 mm 525d 2.5 AT 4805 mm 1800 mm 1445 mm 2830 mm 1705 kg 2305 kg 120 mm 530d 2.9 MT 4805 mm 1800 mm 1445 mm 2830 mm 1735 kg 2335 kg 120 mm 530d 2.9 AT 4805 mm 1800 mm 1445 mm 2830 mm 1735 kg 2335 kg 120 mm 520i 2.2 MT 4805 mm 1800 mm 1445 mm 2830 mm 1595 kg 2195 kg 120 mm 520i 2.2 AT 4805 mm 1800 mm 1445 mm 2830 mm 1595 kg 2195 kg 120 mm 525i 2.5 MT 4805 mm 1800 mm 1445 mm 2830 mm 1605 kg 2205 kg 120 mm 525i 2.5 AT 4805 mm 1800 mm 1445 mm 2830 mm 1635 kg 2235 kg 120 mm 530i 3.0 MT 4805 mm 1800 mm 1445 mm 2830 mm 1645 kg 2345 kg 120 mm 530i 3.0 AT 4805 mm 1800 mm 1445 mm 2830 mm 1645 kg 2345 kg 120 mm 540i 4.4 MT 4805 mm 1800 mm 1445 mm 2830 mm 1740 kg 2280 kg 120 mm 540i 4.4 AT 4805 mm 1800 mm 1445 mm 2830 mm 1790 kg 2310 kg 120 mm
BMW 5 Series Cargo Space
Sedan — BMW 5 Series Cargo Space
Estate 5-door — BMW 5 Series Cargo Space
BMW 5 Series Trims and Equipment
Equipment levels like Exclusive and Standart shape the interior and technology features. Exclusive typically adds more luxury and convenience items, while Standart covers essentials. These trims allow buyers to tailor the car to comfort or value preferences without altering its core dynamic character.
