BMW 2 Series Active Tourer Engines and Transmissions
BMW 2 Series Active Tourer engine options balance everyday usability and efficiency. The 218i gasoline model suits urban errands, while the 218d diesel offers longer cruising range. The plug-in hybrid 230e adds electric-only driving for short commutes, reducing fuel use.
Compact Van — BMW 2 Series Active Tourer Engines and Transmissions
| Modification | Engine type | Engine capacity | Maximum power | Maximum power, kw | Maximum torque N⋅m | Transmission | Type of drive |
|---|---|---|---|---|---|---|---|
| 218i AT Steptronic | Gasoline | 1499 cm³ | 136 hp | 100 kW | 230 N⋅m | Automatic | FWD |
| 220i AT Steptronic | Gasoline | 1499 cm³ | 170 hp | 125 kW | 240 N⋅m | Automatic | FWD |
| 223i AT Steptronic | Gasoline | 1998 cm³ | 218 hp | 160 kW | 320 N⋅m | Automatic | FWD |
| 218d AT Steptronic | Diesel | 1995 cm³ | 150 hp | 110 kW | 360 N⋅m | Automatic | FWD |
| 223d AT MHEV xDrive Steptronic | Diesel | 1995 cm³ | 211 hp | 155 kW | 400 N⋅m | Automatic | FWD |
| 230e AT Plug-in Hybrid xDrive Steptronic | Plug-in | 1499 cm³ | 326 hp | 239 kW | 477 N⋅m | Automatic | FWD |
| 225e AT Plug-in Hybrid xDrive Steptronic | Plug-in | 1499 cm³ | 245 hp | 180 kW | 477 N⋅m | Automatic | FWD |
| 216i AT Steptronic | Gasoline | 1499 cm³ | 122 hp | 89 kW | 230 N⋅m | Automatic | FWD |
BMW 2 Series Active Tourer Dimensions
Compact Van — BMW 2 Series Active Tourer Dimensions
| Modification | Length | Width | Height | Wheelbase | Curb weight | Max weight | Ground clearance, minimum |
|---|---|---|---|---|---|---|---|
| 218i AT Steptronic | 4386 mm | 1824 mm | 1576 mm | 2670 mm | 1470 kg | 2015 kg | 171 mm |
| 220i AT Steptronic | 4386 mm | 1824 mm | 1576 mm | 2670 mm | 1520 kg | 2075 kg | 171 mm |
| 223i AT Steptronic | 4386 mm | 1824 mm | 1576 mm | 2670 mm | 1545 kg | 2105 kg | 171 mm |
| 218d AT Steptronic | 4386 mm | 1824 mm | 1576 mm | 2670 mm | 1545 kg | 2085 kg | 171 mm |
| 223d AT MHEV xDrive Steptronic | 4386 mm | 1824 mm | 1576 mm | 2670 mm | 1655 kg | 2210 kg | 171 mm |
| 230e AT Plug-in Hybrid xDrive Steptronic | 4386 mm | 1824 mm | 1576 mm | 2670 mm | 1845 kg | 2420 kg | 171 mm |
| 225e AT Plug-in Hybrid xDrive Steptronic | 4386 mm | 1824 mm | 1576 mm | 2670 mm | 1825 kg | 2400 kg | 171 mm |
| 216i AT Steptronic | 4386 mm | 1824 mm | 1576 mm | 2670 mm | Not provided | Not provided | 171 mm |
BMW 2 Series Active Tourer Cargo Space
Compact Van — BMW 2 Series Active Tourer Cargo Space
| Modification | Trunk volume min | Trunk volume max |
|---|---|---|
| 218i AT Steptronic | 470 l | 1455 l |
| 220i AT Steptronic | 470 l | 1455 l |
| 223i AT Steptronic | 470 l | 1455 l |
| 218d AT Steptronic | 470 l | 1455 l |
| 223d AT MHEV xDrive Steptronic | 470 l | 1455 l |
| 230e AT Plug-in Hybrid xDrive Steptronic | 470 l | 1455 l |
| 225e AT Plug-in Hybrid xDrive Steptronic | 470 l | 1455 l |
| 216i AT Steptronic | 470 l | 1455 l |
