Audi TT Specs, Engines & Dimensions (2003–2006) — First Generation Restyling

The facelifted first-generation Audi TT kept its compact, design-led shape while sharpening the details, offering the sharp Coupe and the open-top Cabrio to drivers who want style with genuine everyday usability.

← All Audi models

Audi TT Engines and Transmissions

The headline Audi TT engine here is a 3.2-litre petrol V6, seen in the 3.2 MT Coupe and Cabrio with a manual gearbox, and in the 3.2 S-tronic Cabrio with a dual-clutch robotic transmission. Both send power through all-wheel drive, so traction stays secure in rain or cold weather.

Cabrio — Audi TT Engines and Transmissions

Cabrio Audi TT Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 MT	Gasoline	1781 cm³	150 hp	110 kW	210 N⋅m	Manual	FWD
1.8 AT	Gasoline	1781 cm³	150 hp	110 kW	210 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1781 cm³	163 hp	120 kW	225 N⋅m	Manual	FWD
1.8 MT	Gasoline	1781 cm³	180 hp	132 kW	235 N⋅m	Manual	AWD
1.8 MT	Gasoline	1781 cm³	180 hp	132 kW	235 N⋅m	Manual	FWD
1.8 AT	Gasoline	1781 cm³	180 hp	132 kW	235 N⋅m	Automatic	FWD
1.8 AT	Gasoline	1781 cm³	180 hp	132 kW	235 N⋅m	Automatic	AWD
1.8 MT	Gasoline	1781 cm³	225 hp	165 kW	280 N⋅m	Manual	AWD
1.8 AT	Gasoline	1781 cm³	225 hp	165 kW	280 N⋅m	Automatic	AWD
1.8 MT	Gasoline	1798 cm³	190 hp	140 kW	240 N⋅m	Manual	AWD
1.8 MT	Gasoline	1798 cm³	190 hp	140 kW	240 N⋅m	Manual	FWD
3.2 MT	Gasoline	3189 cm³	250 hp	184 kW	320 N⋅m	Manual	AWD
3.2 S-tronic	Gasoline	3189 cm³	250 hp	184 kW	320 N⋅m	Robotic	AWD

Coupe — Audi TT Engines and Transmissions

Coupe Audi TT Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 MT	Gasoline	1781 cm³	150 hp	110 kW	210 N⋅m	Manual	FWD
1.8 AT	Gasoline	1781 cm³	150 hp	110 kW	210 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1781 cm³	163 hp	120 kW	225 N⋅m	Manual	FWD
1.8 AT	Gasoline	1781 cm³	163 hp	120 kW	225 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1781 cm³	180 hp	132 kW	235 N⋅m	Manual	AWD
1.8 MT	Gasoline	1781 cm³	180 hp	132 kW	235 N⋅m	Manual	FWD
1.8 AT	Gasoline	1781 cm³	180 hp	132 kW	235 N⋅m	Automatic	AWD
1.8 MT	Gasoline	1781 cm³	190 hp	140 kW	240 N⋅m	Manual	FWD
1.8 AT	Gasoline	1781 cm³	190 hp	140 kW	240 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1781 cm³	190 hp	140 kW	240 N⋅m	Manual	AWD
1.8 MT	Gasoline	1781 cm³	225 hp	165 kW	280 N⋅m	Manual	AWD
1.8 AT	Gasoline	1781 cm³	225 hp	165 kW	280 N⋅m	Automatic	AWD
1.8 MT	Gasoline	1781 cm³	240 hp	176 kW	320 N⋅m	Manual	AWD
3.2 MT	Gasoline	3189 cm³	250 hp	184 kW	320 N⋅m	Manual	AWD
3.2 S-tronic	Gasoline	3189 cm³	250 hp	184 kW	320 N⋅m	Robotic	AWD
1.8 AT	Gasoline	1781 cm³	180 hp	132 kW	235 N⋅m	Automatic	FWD

Audi TT Dimensions

Cabrio — Audi TT Dimensions

Cabrio Audi TT Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.8 MT	4041 mm	1764 mm	1349 mm	2422 mm	1340 kg	1635 kg	130 mm
1.8 AT	4041 mm	1764 mm	1349 mm	2422 mm	1340 kg	1640 kg	130 mm
1.8 MT	4041 mm	1764 mm	1349 mm	2422 mm	1335 kg	1635 kg	130 mm
1.8 MT	4041 mm	1764 mm	1349 mm	2422 mm	1395 kg	1765 kg	130 mm
1.8 MT	4041 mm	1764 mm	1349 mm	2422 mm	1310 kg	1610 kg	130 mm
1.8 AT	4041 mm	1764 mm	1349 mm	2422 mm	1310 kg	1610 kg	130 mm
1.8 AT	4041 mm	1764 mm	1349 mm	2422 mm	1410 kg	1710 kg	130 mm
1.8 MT	4041 mm	1764 mm	1349 mm	2422 mm	1460 kg	1760 kg	130 mm
1.8 AT	4041 mm	1764 mm	1349 mm	2422 mm	1460 kg	1760 kg	130 mm
1.8 MT	4041 mm	1764 mm	1349 mm	2422 mm	1465 kg	1765 kg	130 mm
1.8 MT	4041 mm	1764 mm	1349 mm	2422 mm	1340 kg	1640 kg	130 mm
3.2 MT	4041 mm	1764 mm	1349 mm	2422 mm	1590 kg	1890 kg	130 mm
3.2 S-tronic	4041 mm	1764 mm	1349 mm	2422 mm	Not provided	1890 kg	130 mm

Coupe — Audi TT Dimensions

Coupe Audi TT Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.8 MT	4041 mm	1764 mm	1346 mm	2422 mm	1280 kg	1665 kg	130 mm
1.8 AT	4041 mm	1764 mm	1346 mm	2422 mm	1280 kg	1665 kg	130 mm
1.8 MT	4041 mm	1764 mm	1346 mm	2422 mm	1280 kg	1760 kg	130 mm
1.8 AT	4041 mm	1764 mm	1346 mm	2422 mm	1280 kg	1760 kg	130 mm
1.8 MT	4041 mm	1764 mm	1346 mm	2422 mm	1340 kg	1710 kg	130 mm
1.8 MT	4041 mm	1764 mm	1346 mm	2422 mm	1240 kg	1610 kg	130 mm
1.8 AT	4041 mm	1764 mm	1346 mm	2422 mm	1340 kg	1710 kg	130 mm
1.8 MT	4041 mm	1764 mm	1346 mm	2422 mm	1280 kg	1665 kg	130 mm
1.8 AT	4041 mm	1764 mm	1346 mm	2422 mm	1320 kg	1705 kg	130 mm
1.8 MT	4041 mm	1764 mm	1346 mm	2422 mm	1280 kg	1795 kg	130 mm
1.8 MT	4041 mm	1764 mm	1346 mm	2422 mm	1395 kg	1765 kg	130 mm
1.8 AT	4041 mm	1764 mm	1346 mm	2422 mm	1395 kg	1765 kg	130 mm
1.8 MT	4041 mm	1764 mm	1346 mm	2422 mm	1390 kg	1775 kg	130 mm
3.2 MT	4041 mm	1764 mm	1346 mm	2422 mm	1520 kg	1905 kg	130 mm
3.2 S-tronic	4041 mm	1764 mm	1346 mm	2422 mm	1520 kg	1905 kg	130 mm
1.8 AT	4041 mm	1764 mm	1346 mm	2422 mm	1240 kg	1610 kg	130 mm

Audi TT Cargo Space

Cabrio — Audi TT Cargo Space

Cabrio Audi TT Cargo Space
Modification	Trunk volume min
1.8 MT	220 l
1.8 AT	220 l
1.8 MT	220 l
1.8 MT	220 l
1.8 MT	220 l
1.8 AT	220 l
1.8 AT	220 l
1.8 MT	220 l
1.8 AT	220 l
1.8 MT	220 l
1.8 MT	220 l
3.2 MT	220 l
3.2 S-tronic	220 l

Coupe — Audi TT Cargo Space

Coupe Audi TT Cargo Space
Modification	Trunk volume min	Trunk volume max
1.8 MT	270 l	540 l
1.8 AT	270 l	540 l
1.8 MT	270 l	540 l
1.8 AT	270 l	540 l
1.8 MT	270 l	540 l
1.8 MT	270 l	540 l
1.8 AT	270 l	540 l
1.8 MT	270 l	540 l
1.8 AT	270 l	540 l
1.8 MT	270 l	540 l
1.8 MT	270 l	540 l
1.8 AT	270 l	540 l
1.8 MT	270 l	540 l
3.2 MT	270 l	540 l
3.2 S-tronic	270 l	540 l
1.8 AT	270 l	540 l
