Aston Martin DB7 Specs, Engines & Dimensions (1994–1999)

Aston Martin DB7 Engines and Transmissions

The Aston Martin DB7 engine range in this generation is gasoline-powered, with a rear-wheel-drive drivetrain. Cabrio examples include the 3.2 AT and 3.2 MT, so you can choose automatic or manual transmission, plus the 5.9 AT for a larger, more relaxed powertrain. These are selected examples, not every version.

Cabrio — Aston Martin DB7 Engines and Transmissions

Cabrio Aston Martin DB7 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.2 AT	Gasoline	3239 cm³	340 hp	250 kW	488 N⋅m	Automatic	RWD
3.2 MT	Gasoline	3239 cm³	340 hp	250 kW	488 N⋅m	Manual	RWD
5.9 AT	Gasoline	5935 cm³	420 hp	308 kW	542 N⋅m	Automatic	RWD
5.9 MT	Gasoline	5935 cm³	420 hp	308 kW	542 N⋅m	Manual	RWD

Coupe — Aston Martin DB7 Engines and Transmissions

Coupe Aston Martin DB7 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.2 AT	Gasoline	3239 cm³	340 hp	250 kW	488 N⋅m	Automatic	RWD
3.2 MT	Gasoline	3239 cm³	340 hp	250 kW	488 N⋅m	Manual	RWD
5.9 AT	Gasoline	5935 cm³	420 hp	308 kW	542 N⋅m	Automatic	RWD
5.9 MT	Gasoline	5935 cm³	420 hp	308 kW	542 N⋅m	Manual	RWD

Aston Martin DB7 Dimensions

Cabrio — Aston Martin DB7 Dimensions

Cabrio Aston Martin DB7 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
3.2 AT	4645 mm	1830 mm	1260 mm	2590 mm	Not provided	Not provided	152 mm
3.2 MT	4645 mm	1830 mm	1260 mm	2590 mm	1850 kg	Not provided	152 mm
5.9 AT	4645 mm	1830 mm	1260 mm	2590 mm	1780 kg	2150 kg	120 mm
5.9 MT	4645 mm	1830 mm	1260 mm	2590 mm	1780 kg	2150 kg	120 mm

Coupe — Aston Martin DB7 Dimensions

Coupe Aston Martin DB7 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
3.2 AT	4645 mm	1830 mm	1240 mm	2590 mm	Not provided	Not provided	152 mm
3.2 MT	4645 mm	1830 mm	1240 mm	2590 mm	1775 kg	Not provided	152 mm
5.9 AT	4645 mm	1830 mm	1240 mm	2590 mm	1780 kg	2150 kg	120 mm
5.9 MT	4645 mm	1830 mm	1240 mm	2590 mm	1780 kg	2150 kg	120 mm

Aston Martin DB7 Cargo Space

Cabrio — Aston Martin DB7 Cargo Space

Cabrio Aston Martin DB7 Cargo Space
Modification	Trunk volume min
3.2 AT	150 l
3.2 MT	150 l
5.9 AT	150 l
5.9 MT	150 l

Coupe — Aston Martin DB7 Cargo Space

Coupe Aston Martin DB7 Cargo Space
Modification	Trunk volume min
3.2 AT	180 l
3.2 MT	180 l
5.9 AT	180 l
5.9 MT	180 l
