Volvo V60 Specs, Engines & Dimensions (2018–2020)

Volvo V60 Engines and Transmissions

Volvo V60 engine options include the diesel 2.0 AT and the plug-in hybrid 2.0 AT T6 and 2.0 AT T8. These selected versions pair an automatic transmission with all-wheel drive. The diesel is worth considering for frequent long journeys, where its fuel economy can be particularly useful.

Estate 5-door — Volvo V60 Engines and Transmissions

Estate 5-door Volvo V60 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 MT	Diesel	1969 cm³	150 hp	110 kW	320 N⋅m	Manual	FWD
2.0 AT	Diesel	1969 cm³	150 hp	110 kW	320 N⋅m	Automatic	FWD
2.0 MT	Diesel	1969 cm³	190 hp	140 kW	400 N⋅m	Manual	FWD
2.0 AT	Diesel	1969 cm³	190 hp	140 kW	400 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1969 cm³	310 hp	228 kW	400 N⋅m	Automatic	AWD
2.0 AT	Plug-in	1969 cm³	340 hp	251 kW	590 N⋅m	Automatic	AWD
2.0 AT T8	Plug-in	1969 cm³	310 hp	228 kW	400 N⋅m	Automatic	AWD
2.0 AT T6	Plug-in	1969 cm³	253 hp	186 kW	350 N⋅m	Automatic	AWD
2.0 AT	Plug-in	1969 cm³	405 hp	297 kW	670 N⋅m	Automatic	AWD
2.0 AT	Gasoline	1969 cm³	163 hp	119 kW	265 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1969 cm³	190 hp	139 kW	300 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1969 cm³	197 hp	144 kW	300 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1969 cm³	250 hp	183 kW	350 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1969 cm³	250 hp	183 kW	350 N⋅m	Automatic	AWD
2.0 AT	Gasoline	1969 cm³	300 hp	220 kW	420 N⋅m	Automatic	AWD
2.0 AT	Diesel	1969 cm³	190 hp	140 kW	400 N⋅m	Automatic	AWD
2.0 AT	Diesel	1969 cm³	150 hp	110 kW	320 N⋅m	Automatic	FWD
2.0 AT	Diesel	1969 cm³	197 hp	144 kW	420 N⋅m	Automatic	FWD
2.0 AT	Plug-in	1969 cm³	390 hp	288 kW	408 N⋅m	Automatic	AWD

Volvo V60 Dimensions

Estate 5-door — Volvo V60 Dimensions

Estate 5-door Volvo V60 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 MT	4761 mm	1850 mm	1427 mm	2872 mm	1690 kg	Not provided	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1690 kg	Not provided	128 mm
2.0 MT	4761 mm	1850 mm	1427 mm	2872 mm	1690 kg	Not provided	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1690 kg	Not provided	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1690 kg	Not provided	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1690 kg	Not provided	128 mm
2.0 AT T8	4761 mm	1850 mm	1427 mm	2872 mm	1757 kg	2550 kg	128 mm
2.0 AT T6	4761 mm	1850 mm	1427 mm	2872 mm	1757 kg	2550 kg	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1695 kg	2550 kg	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1695 kg	2550 kg	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1695 kg	2550 kg	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1695 kg	2550 kg	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1690 kg	2570 kg	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1695 kg	2570 kg	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1695 kg	2570 kg	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1690 kg	2570 kg	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1690 kg	2570 kg	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1690 kg	2550 kg	128 mm
2.0 AT	4761 mm	1850 mm	1427 mm	2872 mm	1690 kg	Not provided	128 mm

Volvo V60 Cargo Space

Estate 5-door — Volvo V60 Cargo Space

Estate 5-door Volvo V60 Cargo Space
Modification	Trunk volume min
2.0 MT	529 l
2.0 AT	529 l
2.0 MT	529 l
2.0 AT	529 l
2.0 AT	529 l
2.0 AT	529 l
2.0 AT T8	529 l
2.0 AT T6	529 l
2.0 AT	529 l
2.0 AT	529 l
2.0 AT	529 l
2.0 AT	529 l
2.0 AT	529 l
2.0 AT	529 l
2.0 AT	529 l
2.0 AT	529 l
2.0 AT	529 l
2.0 AT	529 l
2.0 AT	529 l

Volvo V60 Trims and Equipment

Volvo V60 trim levels describe equipment choices alongside the technical version: Ultimate Bright is an equipment configuration available with the 2.0 AT T8 plug-in hybrid. When choosing a car, check its individual equipment list for the seating, parking aids and other features you will use regularly.

Volvo V60 Trims and Equipment
Modification	Body	Equipment
2.0 AT T8	Estate 5-door	Ultimate Bright
2.0 AT	Estate 5-door	Inscription

Volvo V60 Battery, Range, Charging

The 2.0 AT T6 and 2.0 AT T8 plug-in hybrids use lithium-ion batteries. Assess Volvo V60 battery capacity alongside your daily mileage and charging access: regular charging helps you make use of electric driving, while cold weather, faster roads and cabin heating can reduce electric range.

Estate 5-door — Volvo V60 Battery, Range, Charging

Estate 5-door Volvo V60 Battery, Range, Charging
Modification	Battery power	Battery type	Driving range, maximum	Full charge home
2.0 AT T8	14.9 kWh	Lithium-ion batterie	75 km	780 min
2.0 AT T6	14.9 kWh	Lithium-ion batterie	75 km	780 min
2.0 AT	14.9 kWh	Lithium-ion batterie	51 km	780 min
