Volkswagen Type 4 Specs, Engines & Dimensions (1972–1975)

Volkswagen Type 4 Engines and Transmissions

The Volkswagen Type 4 engine here is a 1.7-liter gasoline unit. Estate 3-door versions such as the 1.7 MT and 1.7 AT pair it with a manual or automatic transmission and a front-wheel-drive drivetrain, so you either shift yourself or let the gearbox work in traffic.

Sedan — Volkswagen Type 4 Engines and Transmissions

Sedan Volkswagen Type 4 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Transmission	Type of drive
1.8 MT	Gasoline	1795 cm³	75 hp	55 kW	Manual	FWD
1.8 AT	Gasoline	1795 cm³	75 hp	55 kW	Automatic	FWD
1.8 MT	Gasoline	1795 cm³	86 hp	63 kW	Manual	FWD
1.8 AT	Gasoline	1795 cm³	86 hp	63 kW	Automatic	FWD

Estate 3-door — Volkswagen Type 4 Engines and Transmissions

Estate 3-door Volkswagen Type 4 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Transmission	Type of drive
1.7 MT	Gasoline	1679 cm³	80 hp	59 kW	Manual	FWD
1.7 AT	Gasoline	1679 cm³	80 hp	59 kW	Automatic	FWD
1.8 MT	Gasoline	1795 cm³	75 hp	55 kW	Manual	FWD
1.8 AT	Gasoline	1795 cm³	75 hp	55 kW	Automatic	FWD
1.8 MT	Gasoline	1795 cm³	86 hp	63 kW	Manual	FWD
1.8 AT	Gasoline	1795 cm³	86 hp	63 kW	Automatic	FWD

Volkswagen Type 4 Dimensions

Sedan — Volkswagen Type 4 Dimensions

Sedan Volkswagen Type 4 Dimensions
Modification	Length	Width	Height	Wheelbase	Ground clearance, minimum
1.8 MT	4583 mm	1675 mm	1475 mm	2500 mm	160 mm
1.8 AT	4583 mm	1675 mm	1475 mm	2500 mm	160 mm
1.8 MT	4583 mm	1675 mm	1475 mm	2500 mm	160 mm
1.8 AT	4583 mm	1675 mm	1475 mm	2500 mm	160 mm

Estate 3-door — Volkswagen Type 4 Dimensions

Estate 3-door Volkswagen Type 4 Dimensions
Modification	Length	Width	Height	Wheelbase	Ground clearance, minimum
1.7 MT	4583 mm	1675 mm	1475 mm	2500 mm	160 mm
1.7 AT	4583 mm	1675 mm	1475 mm	2500 mm	160 mm
1.8 MT	4583 mm	1675 mm	1475 mm	2500 mm	160 mm
1.8 AT	4583 mm	1675 mm	1475 mm	2500 mm	160 mm
1.8 MT	4583 mm	1675 mm	1475 mm	2500 mm	160 mm
1.8 AT	4583 mm	1675 mm	1475 mm	2500 mm	160 mm
