Catalog / Volkswagen / Passat CC / 1 generation, restyling
Volkswagen Passat CC Engines and Transmissions
Volkswagen Passat CC engine choices run from economical turbocharged fours to a broad-shouldered six. The 1.8 gasoline with a manual gearbox and front-wheel drive suits everyday commuting, while a 2.0 diesel pairs the robotic DSG transmission with all-wheel drive for relaxed highway pace. The 3.6 gasoline DSG adds effortless overtaking through a similar all-wheel-drive layout.
Fastback — Volkswagen Passat CC Engines and Transmissions
Fastback Volkswagen Passat CC Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.8 MT Gasoline 1798 cm³ 152 hp 112 kW 250 N⋅m Manual FWD 1.8 DSG Gasoline 1798 cm³ 152 hp 112 kW 250 N⋅m Robotic FWD 3.6 DSG Gasoline 3597 cm³ 300 hp 220 kW 350 N⋅m Robotic AWD 1.4 MT Gasoline 1390 cm³ 160 hp 118 kW 240 N⋅m Manual FWD 1.4 DSG Gasoline 1390 cm³ 160 hp 118 kW 240 N⋅m Robotic FWD 1.4 MT Gasoline 1395 cm³ 150 hp 110 kW 250 N⋅m Manual FWD 1.4 DSG Gasoline 1395 cm³ 150 hp 110 kW 250 N⋅m Robotic FWD 2.0 MT Gasoline 1984 cm³ 210 hp 154 kW 280 N⋅m Manual FWD 2.0 MT Diesel 1968 cm³ 140 hp 103 kW 320 N⋅m Manual FWD 2.0 MT Diesel 1968 cm³ 140 hp 103 kW 320 N⋅m Manual AWD 2.0 MT Diesel 1968 cm³ 150 hp 110 kW 340 N⋅m Manual FWD 2.0 DSG Diesel 1968 cm³ 150 hp 110 kW 340 N⋅m Robotic FWD 2.0 DSG Diesel 1968 cm³ 170 hp 125 kW 350 N⋅m Robotic FWD 2.0 DSG Diesel 1968 cm³ 177 hp 130 kW 380 N⋅m Robotic FWD 2.0 DSG Diesel 1968 cm³ 177 hp 130 kW 380 N⋅m Robotic AWD 2.0 MT Diesel 1968 cm³ 177 hp 130 kW 380 N⋅m Manual FWD 2.0 MT Diesel 1968 cm³ 184 hp 135 kW 380 N⋅m Manual FWD 2.0 DSG Diesel 1968 cm³ 184 hp 135 kW 380 N⋅m Robotic FWD 2.0 DSG Gasoline 1984 cm³ 210 hp 155 kW 290 N⋅m Robotic FWD 2.0 DSG Diesel 1968 cm³ 140 hp 103 kW 320 N⋅m Robotic FWD 1.8 DSG Gasoline 1798 cm³ 160 hp 117 kW 255 N⋅m Robotic FWD
Volkswagen Passat CC Dimensions
Fastback — Volkswagen Passat CC Dimensions
Fastback Volkswagen Passat CC Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.8 MT 4802 mm 1885 mm 1417 mm 2711 mm 1505 kg 1950 kg 154 mm 1.8 DSG 4802 mm 1885 mm 1417 mm 2711 mm 1513 kg 1960 kg 154 mm 3.6 DSG 4802 mm 1885 mm 1417 mm 2711 mm 1705 kg 2130 kg 154 mm 1.4 MT 4802 mm 1885 mm 1417 mm 2711 mm 1505 kg 1950 kg 154 mm 1.4 DSG 4802 mm 1885 mm 1417 mm 2711 mm 1531 kg 1970 kg 154 mm 1.4 MT 4802 mm 1885 mm 1417 mm 2711 mm 1489 kg 1910 kg 124 mm 1.4 DSG 4802 mm 1885 mm 1417 mm 2711 mm 1497 kg 1930 kg 124 mm 2.0 MT 4802 mm 1885 mm 1417 mm 2711 mm 1515 kg 1980 kg 154 mm 2.0 MT 4802 mm 1885 mm 1417 mm 2711 mm 1550 kg 1970 kg 154 mm 2.0 MT 4802 mm 1885 mm 1417 mm 2711 mm 1640 kg 2060 kg 154 mm 2.0 MT 4802 mm 1885 mm 1417 mm 2711 mm 1573 kg 2000 kg 124 mm 2.0 DSG 4802 mm 1885 mm 1417 mm 2711 mm 1596 kg 2020 kg 124 mm 2.0 DSG 4802 mm 1885 mm 1417 mm 2711 mm 1581 kg 1970 kg 154 mm 2.0 DSG 4802 mm 1885 mm 1417 mm 2711 mm 1582 kg 2010 kg 154 mm 2.0 DSG 4802 mm 1885 mm 1417 mm 2711 mm 1683 kg 2110 kg 154 mm 2.0 MT 4802 mm 1885 mm 1417 mm 2711 mm 1565 kg 1990 kg 154 mm 2.0 MT 4802 mm 1885 mm 1417 mm 2711 mm 1590 kg 2010 kg 124 mm 2.0 DSG 4802 mm 1885 mm 1417 mm 2711 mm 1607 kg 2030 kg 124 mm 2.0 DSG 4802 mm 1885 mm 1417 mm 2711 mm 1535 kg 1990 kg 154 mm 2.0 DSG 4802 mm 1885 mm 1417 mm 2711 mm 1564 kg 1990 kg 154 mm 1.8 DSG 4802 mm 1885 mm 1417 mm 2711 mm 1513 kg 1960 kg 154 mm
Volkswagen Passat CC Cargo Space
Fastback — Volkswagen Passat CC Cargo Space
Volkswagen Passat CC Trims and Equipment
Volkswagen Passat CC trim levels sit on top of a chosen technical version, so the 2.0 gasoline DSG with front-wheel drive is offered as either Standart or Luxury. The mechanics stay the same; what changes is comfort, upholstery, climate and infotainment content, so check the equipment of each individual car.
