Vauxhall Zafira Engines and Transmissions
Vauxhall Zafira engine and transmission combinations include the petrol 1.4 AT automatic and 1.4 MT manual, alongside the diesel 1.6 MT manual. These examples all have front-wheel drive. An automatic saves you repeated clutch work in traffic, while diesel generally suits regular longer journeys better than frequent short trips.
Minivan — Vauxhall Zafira Engines and Transmissions
Minivan Vauxhall Zafira Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.4 AT Gasoline 1364 cm³ 140 hp 103 kW 200 N⋅m Automatic FWD 1.4 MT Gasoline 1364 cm³ 140 hp 103 kW 200 N⋅m Manual FWD 1.6 MT Diesel 1598 cm³ 136 hp 100 kW 320 N⋅m Manual FWD 2.0 MT Diesel 1956 cm³ 170 hp 125 kW 400 N⋅m Manual FWD 2.0 AT Diesel 1956 cm³ 170 hp 125 kW 400 N⋅m Automatic FWD
Vauxhall Zafira Dimensions
Minivan — Vauxhall Zafira Dimensions
Minivan Vauxhall Zafira Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.4 AT 4666 mm 1884 mm 1660 mm 2760 mm 1628 kg 2315 kg 160 mm 1.4 MT 4666 mm 1884 mm 1660 mm 2760 mm 1628 kg 2285 kg 160 mm 1.6 MT 4666 mm 1884 mm 1660 mm 2760 mm 1701 kg 2380 kg 165 mm 2.0 MT 4666 mm 1884 mm 1660 mm 2760 mm 1748 kg 2455 kg 160 mm 2.0 AT 4666 mm 1884 mm 1660 mm 2760 mm 1803 kg 2470 kg 160 mm
Vauxhall Zafira Cargo Space
Minivan — Vauxhall Zafira Cargo Space
Minivan Vauxhall Zafira Cargo Space Modification Trunk volume min Trunk volume max
1.4 AT 152 l 1860 l 1.4 MT 152 l 1860 l 1.6 MT 152 l 1860 l 2.0 MT 152 l 1860 l 2.0 AT 152 l 1860 l
