Toyota Land Cruiser Specs, Engines & Dimensions (1960–1984) — Fifth Generation

You get the fifth-generation Toyota Land Cruiser as an SUV 3-doors, SUV 5-doors, SUV cabriolet or Pickup single-cab, with gasoline and diesel power depending on the version.

← All Toyota models

Toyota Land Cruiser Engines and Transmissions

A Toyota Land Cruiser engine in this generation is a gasoline or diesel unit with a manual transmission. The 3.0 MT three-door diesel uses a rear-wheel drivetrain for simpler road work, while the 4.2 MT gasoline and 3.2 MT diesel three-doors add all-wheel drive. Other powertrain pairings exist beyond these examples.

SUV 3-doors — Toyota Land Cruiser Engines and Transmissions

SUV 3-doors Toyota Land Cruiser Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.0 MT	Diesel	2977 cm³	80 hp	59 kW	191 N⋅m	Manual	RWD
3.2 MT	Diesel	3168 cm³	93 hp	68 kW	215 N⋅m	Manual	AWD
3.4 MT	Diesel	3431 cm³	90 hp	66 kW	217 N⋅m	Manual	RWD
3.6 MT	Diesel	3576 cm³	90 hp	66 kW	204 N⋅m	Manual	AWD
3.9 MT	Gasoline	3878 cm³	105 hp	77 kW	261 N⋅m	Manual	AWD
3.9 MT	Gasoline	3878 cm³	125 hp	92 kW	289 N⋅m	Manual	AWD
4.2 MT	Gasoline	4230 cm³	135 hp	99 kW	271 N⋅m	Manual	AWD

SUV 5-doors — Toyota Land Cruiser Engines and Transmissions

SUV 5-doors Toyota Land Cruiser Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.0 MT	Diesel	2977 cm³	80 hp	59 kW	191 N⋅m	Manual	RWD
3.2 MT	Diesel	3168 cm³	93 hp	68 kW	215 N⋅m	Manual	AWD
3.4 MT	Diesel	3431 cm³	90 hp	66 kW	217 N⋅m	Manual	RWD
3.6 MT	Diesel	3576 cm³	90 hp	66 kW	204 N⋅m	Manual	AWD
3.9 MT	Gasoline	3878 cm³	105 hp	77 kW	261 N⋅m	Manual	AWD
3.9 MT	Gasoline	3878 cm³	125 hp	92 kW	289 N⋅m	Manual	AWD
4.2 MT	Gasoline	4230 cm³	135 hp	99 kW	271 N⋅m	Manual	AWD

SUV cabriolet — Toyota Land Cruiser Engines and Transmissions

SUV cabriolet Toyota Land Cruiser Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.0 MT	Diesel	2977 cm³	80 hp	59 kW	191 N⋅m	Manual	RWD
3.2 MT	Diesel	3168 cm³	93 hp	68 kW	215 N⋅m	Manual	AWD
3.4 MT	Diesel	3431 cm³	90 hp	66 kW	217 N⋅m	Manual	RWD
3.6 MT	Diesel	3576 cm³	90 hp	66 kW	204 N⋅m	Manual	AWD
3.9 MT	Gasoline	3878 cm³	105 hp	77 kW	261 N⋅m	Manual	AWD
3.9 MT	Gasoline	3878 cm³	125 hp	92 kW	289 N⋅m	Manual	AWD
4.2 MT	Gasoline	4230 cm³	135 hp	99 kW	271 N⋅m	Manual	AWD

Pickup single-cab — Toyota Land Cruiser Engines and Transmissions

Pickup single-cab Toyota Land Cruiser Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.0 MT	Diesel	2977 cm³	80 hp	59 kW	191 N⋅m	Manual	RWD
3.2 MT	Diesel	3168 cm³	93 hp	68 kW	215 N⋅m	Manual	AWD
3.4 MT	Diesel	3431 cm³	90 hp	66 kW	217 N⋅m	Manual	RWD
3.6 MT	Diesel	3576 cm³	90 hp	66 kW	204 N⋅m	Manual	AWD
3.9 MT	Gasoline	3878 cm³	105 hp	77 kW	261 N⋅m	Manual	AWD
3.9 MT	Gasoline	3878 cm³	125 hp	92 kW	289 N⋅m	Manual	AWD
4.2 MT	Gasoline	4230 cm³	135 hp	99 kW	271 N⋅m	Manual	AWD

Toyota Land Cruiser Dimensions

SUV 3-doors — Toyota Land Cruiser Dimensions

SUV 3-doors Toyota Land Cruiser Dimensions
Modification	Length	Width	Height	Wheelbase	Ground clearance, minimum
3.0 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.2 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.4 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.6 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.9 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.9 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
4.2 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm

SUV 5-doors — Toyota Land Cruiser Dimensions

SUV 5-doors Toyota Land Cruiser Dimensions
Modification	Length	Width	Height	Wheelbase	Ground clearance, minimum
3.0 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.2 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.4 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.6 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.9 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.9 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
4.2 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm

SUV cabriolet — Toyota Land Cruiser Dimensions

SUV cabriolet Toyota Land Cruiser Dimensions
Modification	Length	Width	Height	Wheelbase	Ground clearance, minimum
3.0 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.2 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.4 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.6 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.9 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.9 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
4.2 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm

Pickup single-cab — Toyota Land Cruiser Dimensions

Pickup single-cab Toyota Land Cruiser Dimensions
Modification	Length	Width	Height	Wheelbase	Ground clearance, minimum
3.0 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.2 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.4 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.6 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.9 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
3.9 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
4.2 MT	3841 mm	1666 mm	2001 mm	2286 mm	200 mm
