Toyota Land Cruiser Prado Specs, Engines & Dimensions (2020–2024)

Toyota Land Cruiser Prado Engines and Transmissions

The powertrain lineup includes a 2.7-liter gasoline engine paired with an automatic transmission, and a 2.8-liter diesel with either a manual or automatic. A larger 4.0-liter gasoline with automatic is also available. All configurations use all-wheel drive, providing confident traction in varied conditions.

SUV 5-doors — Toyota Land Cruiser Prado Engines and Transmissions

SUV 5-doors Toyota Land Cruiser Prado Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.7 AT	Gasoline	2694 cm³	163 hp	119 kW	246 N⋅m	Automatic	AWD
4.0 AT	Gasoline	3956 cm³	249 hp	183 kW	381 N⋅m	Automatic	AWD
2.8 MT	Diesel	2755 cm³	204 hp	150 kW	510 N⋅m	Manual	AWD
2.8 AT	Diesel	2755 cm³	204 hp	150 kW	510 N⋅m	Automatic	AWD
2.8 AT	Diesel	2755 cm³	177 hp	130 kW	459 N⋅m	Automatic	AWD

SUV 3-doors — Toyota Land Cruiser Prado Engines and Transmissions

SUV 3-doors Toyota Land Cruiser Prado Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.8 AT	Diesel	2755 cm³	204 hp	150 kW	510 N⋅m	Automatic	AWD

Toyota Land Cruiser Prado Dimensions

SUV 5-doors — Toyota Land Cruiser Prado Dimensions

SUV 5-doors Toyota Land Cruiser Prado Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.7 AT	4840 mm	1885 mm	1835 mm	2790 mm	2095 kg	2850 kg	215 mm
4.0 AT	4840 mm	1885 mm	1835 mm	2790 mm	2150 kg	2900 kg	215 mm
2.8 MT	4840 mm	1885 mm	1835 mm	2790 mm	2140 kg	2990 kg	215 mm
2.8 AT	4840 mm	1885 mm	1835 mm	2790 mm	2220 kg	2990 kg	215 mm
2.8 AT	4840 mm	1885 mm	1835 mm	2790 mm	2205 kg	2990 kg	215 mm

SUV 3-doors — Toyota Land Cruiser Prado Dimensions

SUV 3-doors Toyota Land Cruiser Prado Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.8 AT	4395 mm	1885 mm	1845 mm	2450 mm	2030 kg	2600 kg	215 mm

Toyota Land Cruiser Prado Cargo Space

SUV 5-doors — Toyota Land Cruiser Prado Cargo Space

SUV 5-doors Toyota Land Cruiser Prado Cargo Space
Modification	Trunk volume min	Trunk volume max
2.7 AT	190 l	1127 l
4.0 AT	190 l	1127 l
2.8 MT	190 l	1127 l
2.8 AT	190 l	1127 l
2.8 AT	190 l	1127 l

SUV 3-doors — Toyota Land Cruiser Prado Cargo Space

SUV 3-doors Toyota Land Cruiser Prado Cargo Space
Modification	Trunk volume min
2.8 AT	720 l

Toyota Land Cruiser Prado Trims and Equipment

Trim levels for the three-door diesel automatic version, such as Luxury 3 doors, focus on upscale comfort and convenience features. Equipment varies by market, but this trim typically adds premium materials and advanced infotainment options to enhance the driving experience.

Toyota Land Cruiser Prado Trims and Equipment
Modification	Body	Equipment
2.8 AT	SUV 5-doors	Luxury 5 doors 5 seats
2.8 AT	SUV 5-doors	TS
2.8 AT	SUV 5-doors	Luxury 7 seats
2.8 AT	SUV 5-doors	Select 7 seats
2.8 AT	SUV 5-doors	Limited 7 seats
2.8 AT	SUV 5-doors	Limited Sahara 7 seats
2.8 AT	SUV 5-doors	Select 5 seats
2.8 AT	SUV 5-doors	Limited 5 seats
2.8 AT	SUV 5-doors	TS 7 seats
2.8 AT	SUV 5-doors	Select 7 seats
2.8 AT	SUV 5-doors	Limited Sahara 7 seats
2.8 AT	SUV 3-doors	Luxury 3 doors
