Toyota Land Cruiser Prado Specs, Engines & Dimensions (2007–2009)

Toyota Land Cruiser Prado Engines and Transmissions

The Toyota Land Cruiser Prado engine lineup covers both gasoline and diesel options, each paired with a specific transmission and all-wheel drive. The 3.4 AT offers smooth automatic shifting, while the 3.0 MT with a manual gearbox gives diesel efficiency and direct control. A 2.7 AT serves as a balanced gasoline alternative.

SUV 3-doors — Toyota Land Cruiser Prado Engines and Transmissions

SUV 3-doors Toyota Land Cruiser Prado Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.4 AT	Gasoline	3378 cm³	185 hp	136 kW	294 N⋅m	Automatic	AWD
2.7 AT	Gasoline	2693 cm³	163 hp	120 kW	241 N⋅m	Automatic	AWD
2.7 MT	Gasoline	2693 cm³	163 hp	120 kW	241 N⋅m	Manual	AWD
4.0 MT	Gasoline	3955 cm³	249 hp	183 kW	380 N⋅m	Manual	AWD
3.0 AT	Diesel	2982 cm³	163 hp	120 kW	343 N⋅m	Automatic	AWD
3.0 MT	Diesel	2982 cm³	166 hp	122 kW	343 N⋅m	Manual	AWD
3.0 AT	Diesel	2982 cm³	173 hp	127 kW	410 N⋅m	Automatic	AWD
4.0 AT	Gasoline	3955 cm³	250 hp	183 kW	380 N⋅m	Automatic	AWD

SUV 5-doors — Toyota Land Cruiser Prado Engines and Transmissions

SUV 5-doors Toyota Land Cruiser Prado Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.7 MT	Gasoline	2693 cm³	163 hp	120 kW	241 N⋅m	Manual	AWD
2.7 AT	Gasoline	2693 cm³	163 hp	120 kW	241 N⋅m	Automatic	AWD
3.4 AT	Gasoline	3378 cm³	185 hp	136 kW	294 N⋅m	Automatic	AWD
4.0 AT4	Gasoline	3956 cm³	250 hp	183 kW	382 N⋅m	Automatic	AWD
3.0 MT	Diesel	2975 cm³	95 hp	70 kW	192 N⋅m	Manual	AWD
3.0 AT	Diesel	2982 cm³	131 hp	96 kW	289 N⋅m	Automatic	AWD
3.0 MT	Diesel	2982 cm³	131 hp	96 kW	289 N⋅m	Manual	AWD
3.0 MT	Diesel	2982 cm³	173 hp	127 kW	410 N⋅m	Manual	AWD
4.0 AT5	Gasoline	3956 cm³	250 hp	183 kW	382 N⋅m	Automatic	AWD
3.0 AT	Diesel	2982 cm³	173 hp	127 kW	410 N⋅m	Automatic	AWD

Toyota Land Cruiser Prado Dimensions

SUV 3-doors — Toyota Land Cruiser Prado Dimensions

SUV 3-doors Toyota Land Cruiser Prado Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
3.4 AT	4340 mm	1875 mm	1865 mm	2455 mm	1790 kg	2065 kg	220 mm
2.7 AT	4340 mm	1875 mm	1865 mm	2455 mm	1790 kg	2065 kg	220 mm
2.7 MT	4340 mm	1875 mm	1865 mm	2455 mm	1790 kg	2065 kg	220 mm
4.0 MT	4340 mm	1875 mm	1865 mm	2455 mm	1760 kg	2800 kg	220 mm
3.0 AT	4340 mm	1875 mm	1865 mm	2455 mm	1840 kg	2600 kg	220 mm
3.0 MT	4340 mm	1875 mm	1865 mm	2455 mm	1925 kg	2600 kg	220 mm
3.0 AT	4340 mm	1875 mm	1865 mm	2455 mm	1840 kg	2600 kg	220 mm
4.0 AT	4340 mm	1875 mm	1865 mm	2455 mm	1760 kg	2800 kg	220 mm

SUV 5-doors — Toyota Land Cruiser Prado Dimensions

SUV 5-doors Toyota Land Cruiser Prado Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum	Ground clearance, maximum
2.7 MT	4715 mm	1875 mm	1855 mm	2790 mm	1880 kg	2155 kg	220 mm	Not provided
2.7 AT	4715 mm	1875 mm	1855 mm	2790 mm	1880 kg	2155 kg	220 mm	Not provided
3.4 AT	4715 mm	1875 mm	1855 mm	2790 mm	1790 kg	2065 kg	220 mm	Not provided
4.0 AT4	4715 mm	1875 mm	1855 mm	2790 mm	2070 kg	2650 kg	230 mm	Not provided
3.0 MT	4715 mm	1875 mm	1855 mm	2790 mm	1790 kg	2065 kg	220 mm	Not provided
3.0 AT	4715 mm	1875 mm	1855 mm	2790 mm	Not provided	2065 kg	220 mm	Not provided
3.0 MT	4715 mm	1875 mm	1855 mm	2790 mm	1790 kg	2065 kg	220 mm	Not provided
3.0 MT	4715 mm	1875 mm	1855 mm	2790 mm	2025 kg	2850 kg	220 mm	Not provided
4.0 AT5	4715 mm	1875 mm	1855 mm	2790 mm	1900 kg	2850 kg	220 mm	250 mm
3.0 AT	4715 mm	1875 mm	1855 mm	2790 mm	1940 kg	2850 kg	220 mm	Not provided

Toyota Land Cruiser Prado Cargo Space

SUV 3-doors — Toyota Land Cruiser Prado Cargo Space

SUV 3-doors Toyota Land Cruiser Prado Cargo Space
Modification	Trunk volume min	Trunk volume max
3.4 AT	403 l	1150 l
2.7 AT	403 l	1150 l
2.7 MT	403 l	1150 l
4.0 MT	403 l	1150 l
3.0 AT	403 l	1150 l
3.0 MT	403 l	1150 l
3.0 AT	403 l	1150 l
4.0 AT	403 l	1150 l

SUV 5-doors — Toyota Land Cruiser Prado Cargo Space

SUV 5-doors Toyota Land Cruiser Prado Cargo Space
Modification	Trunk volume min	Trunk volume max
2.7 MT	620 l	1850 l
2.7 AT	620 l	1850 l
3.4 AT	620 l	1850 l
4.0 AT4	620 l	1850 l
3.0 MT	620 l	1850 l
3.0 AT	620 l	1850 l
3.0 MT	620 l	1850 l
3.0 MT	620 l	1850 l
4.0 AT5	620 l	1850 l
3.0 AT	620 l	1850 l

Toyota Land Cruiser Prado Trims and Equipment

Toyota Land Cruiser Prado trim levels tailor the vehicle to different needs. For example, the 4.0 AT5 in SUV 5-doors form comes in Long and Luxury 5 seats configurations, adding extra space or premium comfort. These trims refine the experience without altering core off-road capability.

Toyota Land Cruiser Prado Trims and Equipment
Modification	Body	Equipment
3.0 AT	SUV 3-doors	Luxury 5 seats
3.0 AT	SUV 3-doors	Premium
3.0 AT	SUV 3-doors	Short
3.0 AT	SUV 3-doors	STD
3.0 AT	SUV 3-doors	Luxury 8 seats
4.0 AT	SUV 3-doors	Luxury 5 seats
4.0 AT	SUV 3-doors	Premium
4.0 AT	SUV 3-doors	Luxury 8 seats
4.0 AT5	SUV 5-doors	Long
4.0 AT5	SUV 5-doors	Luxury 5 seats
4.0 AT5	SUV 5-doors	Plus
4.0 AT5	SUV 5-doors	Standart
4.0 AT5	SUV 5-doors	Luxury 8 seats
3.0 AT	SUV 5-doors	Long
3.0 AT	SUV 5-doors	Luxury 5 seats
3.0 AT	SUV 5-doors	Plus
3.0 AT	SUV 5-doors	Standart
3.0 AT	SUV 5-doors	Regular
3.0 AT	SUV 5-doors	Luxury 8 seats
3.0 AT	SUV 5-doors	Standart 8 seats
