Toyota Avensis Specs, Engines & Dimensions (2003–2006) — Second Generation

The second-generation Toyota Avensis arrived as a roomy family car offered in Liftback, Estate 5-door and Sedan bodies, pairing practical everyday comfort with a broad choice of engines and gearboxes.

← All Toyota models

Toyota Avensis Engines and Transmissions

Choose a Toyota Avensis engine to suit your mileage: the 1.6 MT Liftback is a light, economical petrol manual for town use, while the 2.0 MT diesel Liftback rewards long motorway runs. The 2.0 AT Estate adds automatic ease, and its all-wheel-drive layout improves traction in poor weather.

Liftback — Toyota Avensis Engines and Transmissions

Liftback Toyota Avensis Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 MT	Gasoline	1598 cm³	110 hp	81 kW	150 N⋅m	Manual	FWD
1.8 MT	Gasoline	1794 cm³	129 hp	95 kW	170 N⋅m	Manual	FWD
1.8 AT	Gasoline	1794 cm³	129 hp	95 kW	170 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1998 cm³	147 hp	108 kW	196 N⋅m	Manual	FWD
2.4 AT	Gasoline	2362 cm³	163 hp	120 kW	230 N⋅m	Automatic	FWD
2.0 MT	Diesel	1995 cm³	116 hp	85 kW	280 N⋅m	Manual	FWD
2.2 MT	Diesel	2231 cm³	150 hp	110 kW	310 N⋅m	Manual	FWD
2.0 AT	Gasoline	1998 cm³	147 hp	108 kW	196 N⋅m	Automatic	FWD

Estate 5-door — Toyota Avensis Engines and Transmissions

Estate 5-door Toyota Avensis Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 MT	Gasoline	1598 cm³	110 hp	81 kW	150 N⋅m	Manual	FWD
1.8 MT	Gasoline	1794 cm³	129 hp	95 kW	170 N⋅m	Manual	FWD
1.8 AT	Gasoline	1794 cm³	129 hp	95 kW	170 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1998 cm³	147 hp	108 kW	196 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1998 cm³	147 hp	108 kW	196 N⋅m	Manual	FWD
2.0 AT	Gasoline	1998 cm³	155 hp	114 kW	192 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1998 cm³	155 hp	114 kW	192 N⋅m	Automatic	AWD
2.4 AT	Gasoline	2362 cm³	163 hp	120 kW	230 N⋅m	Automatic	FWD
2.0 MT	Diesel	1995 cm³	116 hp	85 kW	280 N⋅m	Manual	FWD
2.2 MT	Diesel	2231 cm³	148 hp	109 kW	310 N⋅m	Manual	FWD
2.2 MT	Diesel	2231 cm³	175 hp	129 kW	400 N⋅m	Manual	FWD

Sedan — Toyota Avensis Engines and Transmissions

Sedan Toyota Avensis Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 MT	Gasoline	1598 cm³	110 hp	81 kW	150 N⋅m	Manual	FWD
1.8 MT	Gasoline	1794 cm³	129 hp	95 kW	170 N⋅m	Manual	FWD
1.8 AT	Gasoline	1794 cm³	129 hp	95 kW	170 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1998 cm³	147 hp	108 kW	196 N⋅m	Manual	FWD
2.4 AT	Gasoline	2362 cm³	163 hp	120 kW	230 N⋅m	Automatic	FWD
2.0 MT	Diesel	1995 cm³	116 hp	85 kW	280 N⋅m	Manual	FWD
2.2 MT	Diesel	2231 cm³	150 hp	110 kW	310 N⋅m	Manual	FWD
2.0 AT	Gasoline	1998 cm³	155 hp	114 kW	192 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1998 cm³	155 hp	114 kW	192 N⋅m	Automatic	AWD
2.2 MT	Diesel	2231 cm³	148 hp	109 kW	310 N⋅m	Manual	FWD
2.2 MT	Diesel	2231 cm³	175 hp	129 kW	400 N⋅m	Manual	FWD
2.0 AT	Gasoline	1998 cm³	147 hp	108 kW	196 N⋅m	Automatic	FWD

Toyota Avensis Dimensions

Liftback — Toyota Avensis Dimensions

Liftback Toyota Avensis Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 MT	4630 mm	1760 mm	1480 mm	2700 mm	1265 kg	1820 kg	150 mm
1.8 MT	4630 mm	1760 mm	1480 mm	2700 mm	1275 kg	1820 kg	150 mm
1.8 AT	4630 mm	1760 mm	1480 mm	2700 mm	1290 kg	1820 kg	150 mm
2.0 MT	4630 mm	1760 mm	1480 mm	2700 mm	1335 kg	1895 kg	150 mm
2.4 AT	4630 mm	1760 mm	1480 mm	2700 mm	1380 kg	1905 kg	150 mm
2.0 MT	4630 mm	1760 mm	1480 mm	2700 mm	1400 kg	1970 kg	150 mm
2.2 MT	4630 mm	1760 mm	1480 mm	2700 mm	1530 kg	1970 kg	150 mm
2.0 AT	4630 mm	1760 mm	1480 mm	2700 mm	1365 kg	1895 kg	150 mm

Estate 5-door — Toyota Avensis Dimensions

Estate 5-door Toyota Avensis Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 MT	4715 mm	1760 mm	1525 mm	2700 mm	1295 kg	1820 kg	150 mm
1.8 MT	4715 mm	1760 mm	1525 mm	2700 mm	1345 kg	1820 kg	150 mm
1.8 AT	4715 mm	1760 mm	1525 mm	2700 mm	1300 kg	1820 kg	155 mm
2.0 AT	4715 mm	1760 mm	1525 mm	2700 mm	1420 kg	1895 kg	150 mm
2.0 MT	4715 mm	1760 mm	1525 mm	2700 mm	1355 kg	1895 kg	155 mm
2.0 AT	4715 mm	1760 mm	1525 mm	2700 mm	1420 kg	1895 kg	150 mm
2.0 AT	4715 mm	1760 mm	1525 mm	2700 mm	1480 kg	Not provided	150 mm
2.4 AT	4715 mm	1760 mm	1525 mm	2700 mm	1445 kg	1905 kg	150 mm
2.0 MT	4715 mm	1760 mm	1525 mm	2700 mm	1430 kg	1970 kg	150 mm
2.2 MT	4715 mm	1760 mm	1525 mm	2700 mm	1455 kg	1970 kg	155 mm
2.2 MT	4715 mm	1760 mm	1525 mm	2700 mm	1465 kg	1970 kg	155 mm

Sedan — Toyota Avensis Dimensions

Sedan Toyota Avensis Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 MT	4630 mm	1760 mm	1480 mm	2700 mm	1265 kg	1820 kg	150 mm
1.8 MT	4630 mm	1760 mm	1480 mm	2700 mm	1275 kg	1820 kg	150 mm
1.8 AT	4630 mm	1760 mm	1480 mm	2700 mm	1290 kg	1820 kg	150 mm
2.0 MT	4630 mm	1760 mm	1480 mm	2700 mm	1335 kg	1895 kg	150 mm
2.4 AT	4630 mm	1760 mm	1480 mm	2700 mm	1380 kg	1905 kg	150 mm
2.0 MT	4630 mm	1760 mm	1480 mm	2700 mm	1400 kg	1970 kg	150 mm
2.2 MT	4630 mm	1760 mm	1480 mm	2700 mm	1530 kg	1970 kg	150 mm
2.0 AT	4630 mm	1760 mm	1480 mm	2700 mm	1365 kg	1895 kg	150 mm
2.0 AT	4630 mm	1760 mm	1480 mm	2700 mm	1440 kg	Not provided	150 mm
2.2 MT	4630 mm	1760 mm	1480 mm	2700 mm	1430 kg	1970 kg	155 mm
2.2 MT	4630 mm	1760 mm	1480 mm	2700 mm	1430 kg	1970 kg	155 mm
2.0 AT	4630 mm	1760 mm	1480 mm	2700 mm	1365 kg	1895 kg	150 mm

Toyota Avensis Cargo Space

Liftback — Toyota Avensis Cargo Space

Liftback Toyota Avensis Cargo Space
Modification	Trunk volume min	Trunk volume max
1.6 MT	510 l	520 l
1.8 MT	510 l	520 l
1.8 AT	510 l	520 l
2.0 MT	510 l	520 l
2.4 AT	510 l	520 l
2.0 MT	510 l	520 l
2.2 MT	510 l	520 l
2.0 AT	510 l	520 l

Estate 5-door — Toyota Avensis Cargo Space

Estate 5-door Toyota Avensis Cargo Space
Modification	Trunk volume min	Trunk volume max
1.6 MT	520 l	1500 l
1.8 MT	520 l	1500 l
1.8 AT	520 l	1500 l
2.0 AT	520 l	1500 l
2.0 MT	520 l	1500 l
2.0 AT	520 l	1500 l
2.0 AT	520 l	1500 l
2.4 AT	520 l	1500 l
2.0 MT	520 l	1500 l
2.2 MT	520 l	1500 l
2.2 MT	520 l	1500 l

Sedan — Toyota Avensis Cargo Space

Sedan Toyota Avensis Cargo Space
Modification	Trunk volume min
1.6 MT	520 l
1.8 MT	520 l
1.8 AT	520 l
2.0 MT	520 l
2.4 AT	520 l
2.0 MT	520 l
2.2 MT	520 l
2.0 AT	520 l
2.0 AT	520 l
2.2 MT	520 l
2.2 MT	520 l
2.0 AT	520 l
