Suzuki SX4 Specs, Engines & Dimensions (2006–2014)

Suzuki SX4 Engines and Transmissions

One Suzuki SX4 powertrain option is the 1.6 MT five-door hatchback, combining a gasoline engine, manual transmission and front-wheel drive. You control gear changes, with downshifts helping when climbing hills or overtaking, though frequent traffic means more clutch work. Available engine and drivetrain combinations vary by year and market.

Sedan — Suzuki SX4 Engines and Transmissions

Sedan Suzuki SX4 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 AT	Gasoline	1586 cm³	120 hp	87 kW	159 N⋅m	Automatic	FWD
1.6 AT	Gasoline	1586 cm³	107 hp	78 kW	147 N⋅m	Automatic	FWD

Hatchback 5-door — Suzuki SX4 Engines and Transmissions

Hatchback 5-door Suzuki SX4 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 MT	Gasoline	1586 cm³	120 hp	87 kW	159 N⋅m	Manual	FWD
1.6 AT	Gasoline	1586 cm³	120 hp	87 kW	159 N⋅m	Automatic	FWD
1.6 AT	Gasoline	1586 cm³	107 hp	78 kW	147 N⋅m	Automatic	FWD

Suzuki SX4 Dimensions

Sedan — Suzuki SX4 Dimensions

Sedan Suzuki SX4 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 AT	4490 mm	1730 mm	1545 mm	2500 mm	1200 kg	1650 kg	175 mm
1.6 AT	4490 mm	1730 mm	1545 mm	2500 mm	1200 kg	1650 kg	175 mm

Hatchback 5-door — Suzuki SX4 Dimensions

Hatchback 5-door Suzuki SX4 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 MT	4100 mm	1730 mm	1555 mm	2500 mm	1200 kg	1650 kg	175 mm
1.6 AT	4100 mm	1730 mm	1555 mm	2500 mm	1200 kg	1650 kg	175 mm
1.6 AT	4100 mm	1730 mm	1555 mm	2500 mm	1200 kg	1650 kg	175 mm

Suzuki SX4 Cargo Space

Sedan — Suzuki SX4 Cargo Space

Sedan Suzuki SX4 Cargo Space
Modification	Trunk volume min
1.6 AT	515 l
1.6 AT	515 l

Hatchback 5-door — Suzuki SX4 Cargo Space

Hatchback 5-door Suzuki SX4 Cargo Space
Modification	Trunk volume min	Trunk volume max
1.6 MT	270 l	625 l
1.6 AT	270 l	625 l
1.6 AT	270 l	625 l
