Catalog / Subaru / Legacy / 5 generation, restyling 1
Subaru Legacy Engines and Transmissions
Powertrain choice for a Subaru Legacy engine includes diesel and gasoline, with an all-wheel-drive drivetrain. The 2.0 MT sedan uses a manual gearbox if you prefer to shift yourself. Estate 5-door examples add a 2.5 AT gasoline automatic and a 2.0 CVT variable transmission for easier daily driving.
Sedan — Subaru Legacy Engines and Transmissions
Sedan Subaru Legacy Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 MT Diesel 1998 cm³ 150 hp 110 kW 350 N⋅m Manual AWD 2.5 AT Gasoline 2457 cm³ 265 hp 194 kW 350 N⋅m Automatic AWD 2.5 AT Gasoline 2457 cm³ 167 hp 122 kW 229 N⋅m Automatic AWD
Estate 5-door — Subaru Legacy Engines and Transmissions
Estate 5-door Subaru Legacy Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 MT Diesel 1998 cm³ 150 hp 110 kW 350 N⋅m Manual AWD 2.5 AT Gasoline 2457 cm³ 167 hp 122 kW 229 N⋅m Automatic AWD 2.0 CVT Gasoline 1994 cm³ 150 hp 110 kW 196 N⋅m Variable AWD
Subaru Legacy Dimensions
Sedan — Subaru Legacy Dimensions
Sedan Subaru Legacy Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.0 MT 4790 mm 1780 mm 1535 mm 2750 mm 1542 kg 2030 kg 150 mm 2.5 AT 4790 mm 1780 mm 1535 mm 2750 mm 1542 kg 2030 kg 150 mm 2.5 AT 4790 mm 1780 mm 1535 mm 2750 mm 1486 kg 1800 kg 150 mm
Estate 5-door — Subaru Legacy Dimensions
Estate 5-door Subaru Legacy Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.0 MT 4790 mm 1780 mm 1535 mm 2750 mm 1575 kg 2075 kg 150 mm 2.5 AT 4790 mm 1780 mm 1535 mm 2750 mm 1519 kg 2030 kg 150 mm 2.0 CVT 4790 mm 1780 mm 1535 mm 2750 mm 1507 kg 2030 kg 150 mm
Subaru Legacy Cargo Space
Sedan — Subaru Legacy Cargo Space
Sedan Subaru Legacy Cargo Space Modification Trunk volume min 2.0 MT 476 l 2.5 AT 476 l 2.5 AT 476 l
Estate 5-door — Subaru Legacy Cargo Space
Estate 5-door Subaru Legacy Cargo Space Modification Trunk volume min Trunk volume max 2.0 MT 526 l 1726 l 2.5 AT 526 l 1726 l 2.0 CVT 526 l 1726 l
