Catalog / Saab / 9-5 / 2 generation
Saab 9-5 Engines and Transmissions
Saab 9-5 engine options include the gasoline 1.6 MT Sedan with a manual transmission and front-wheel drive. Selected 2.0 AT Sedans combine gasoline or diesel power with an automatic and all-wheel drive, offering easier driving in traffic and added traction. Diesel generally suits regular longer journeys.
Sedan — Saab 9-5 Engines and Transmissions
Sedan Saab 9-5 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.6 MT Gasoline 1598 cm³ 180 hp 132 kW 230 N⋅m Manual FWD 2.0 AT Gasoline 1985 cm³ 150 hp 110 kW 240 N⋅m Automatic FWD 2.0 MT Gasoline 1985 cm³ 150 hp 110 kW 240 N⋅m Manual FWD 2.0 MT Gasoline 1998 cm³ 220 hp 162 kW 350 N⋅m Manual FWD 2.0 AT Gasoline 1998 cm³ 220 hp 162 kW 350 N⋅m Automatic AWD 2.0 MT Gasoline 1998 cm³ 220 hp 162 kW 350 N⋅m Manual AWD 2.0 AT Gasoline 1998 cm³ 220 hp 162 kW 350 N⋅m Automatic FWD 2.0 MT Gasoline 1998 cm³ 220 hp 162 kW 350 N⋅m Manual FWD 2.3 MT Gasoline 2290 cm³ 185 hp 136 kW 280 N⋅m Manual FWD 2.3 AT Gasoline 2290 cm³ 185 hp 136 kW 280 N⋅m Automatic FWD 2.3 AT Gasoline 2290 cm³ 260 hp 191 kW 350 N⋅m Automatic FWD 2.3 MT Gasoline 2290 cm³ 260 hp 191 kW 350 N⋅m Manual FWD 2.8 AT Gasoline 2792 cm³ 301 hp 221 kW 400 N⋅m Automatic AWD 2.0 MT Diesel 1956 cm³ 160 hp 118 kW 350 N⋅m Manual FWD 2.0 AT Diesel 1956 cm³ 160 hp 118 kW 350 N⋅m Automatic FWD 2.0 MT Diesel 1956 cm³ 190 hp 140 kW 400 N⋅m Manual FWD 2.0 MT Diesel 1956 cm³ 190 hp 140 kW 400 N⋅m Manual AWD 2.0 AT Diesel 1956 cm³ 190 hp 140 kW 400 N⋅m Automatic FWD 2.0 AT Diesel 1956 cm³ 190 hp 140 kW 400 N⋅m Automatic AWD
Estate 5-door — Saab 9-5 Engines and Transmissions
Estate 5-door Saab 9-5 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.6 MT Gasoline 1598 cm³ 180 hp 132 kW 230 N⋅m Manual FWD 2.0 MT Gasoline 1988 cm³ 220 hp 162 kW 350 N⋅m Manual FWD 2.0 AT Gasoline 1988 cm³ 220 hp 162 kW 350 N⋅m Automatic FWD 2.0 MT Gasoline 1988 cm³ 220 hp 162 kW 350 N⋅m Manual AWD 2.0 AT Gasoline 1988 cm³ 220 hp 162 kW 350 N⋅m Automatic AWD 2.8 AT Gasoline 2792 cm³ 300 hp 221 kW 400 N⋅m Automatic AWD 2.0 MT Diesel 1956 cm³ 160 hp 118 kW 350 N⋅m Manual FWD 2.0 AT Diesel 1956 cm³ 160 hp 118 kW 350 N⋅m Automatic FWD 2.0 MT Diesel 1956 cm³ 190 hp 140 kW 400 N⋅m Manual FWD 2.0 MT Diesel 1956 cm³ 190 hp 140 kW 400 N⋅m Manual AWD
Saab 9-5 Dimensions
Sedan — Saab 9-5 Dimensions
Sedan Saab 9-5 Dimensions Modification Length Width Height Wheelbase Ground clearance, minimum 1.6 MT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.0 AT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.0 MT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.0 MT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.0 AT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.0 MT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.0 AT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.0 MT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.3 MT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.3 AT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.3 AT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.3 MT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.8 AT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.0 MT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.0 AT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.0 MT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.0 MT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.0 AT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm 2.0 AT 5008 mm 1868 mm 1466 mm 2837 mm 145 mm
Estate 5-door — Saab 9-5 Dimensions
Estate 5-door Saab 9-5 Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 1.6 MT 4841 mm 2070 mm 1459 mm 2703 mm 1675 kg 145 mm 2.0 MT 4841 mm 2070 mm 1459 mm 2703 mm 1710 kg 145 mm 2.0 AT 4841 mm 2070 mm 1459 mm 2703 mm 1735 kg 145 mm 2.0 MT 4841 mm 2070 mm 1459 mm 2703 mm 1825 kg 145 mm 2.0 AT 4841 mm 2070 mm 1459 mm 2703 mm 1850 kg 145 mm 2.8 AT 4841 mm 2070 mm 1459 mm 2703 mm 1945 kg Not provided 2.0 MT 4841 mm 2070 mm 1459 mm 2703 mm 1750 kg Not provided 2.0 AT 4841 mm 2070 mm 1459 mm 2703 mm 1770 kg Not provided 2.0 MT 4841 mm 2070 mm 1459 mm 2703 mm 1775 kg Not provided 2.0 MT 4841 mm 2070 mm 1459 mm 2703 mm 1885 kg Not provided
Saab 9-5 Cargo Space
Sedan — Saab 9-5 Cargo Space
