Pontiac Firebird Specs, Engines & Dimensions (1967–1969)

Pontiac Firebird Engines and Transmissions

Every Pontiac Firebird engine in this generation runs on gasoline and drives the rear wheels, so the real choice is character. A smaller unit like the 3.8 AT suits easy cruising, while bigger displacement such as the 5.3 AT pulls harder; the 4.1 MT adds manual shifting to the Coupe Hardtop.

Cabrio — Pontiac Firebird Engines and Transmissions

Cabrio Pontiac Firebird Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Transmission	Type of drive
3.8 AT	Gasoline	3800 cm³	165 hp	121 kW	Automatic	RWD
5.3 AT	Gasoline	5300 cm³	250 hp	184 kW	Automatic	RWD
5.7 AT	Gasoline	5665 cm³	325 hp	239 kW	Automatic	RWD
6.6 AT	Gasoline	6555 cm³	325 hp	239 kW	Automatic	RWD

Coupe Hardtop — Pontiac Firebird Engines and Transmissions

Coupe Hardtop Pontiac Firebird Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.8 AT	Gasoline	3800 cm³	165 hp	121 kW	Not provided	Automatic	RWD
4.1 MT	Gasoline	4118 cm³	215 hp	158 kW	325 N⋅m	Manual	RWD
5.3 AT	Gasoline	5300 cm³	250 hp	184 kW	Not provided	Automatic	RWD
5.7 AT	Gasoline	5665 cm³	320 hp	235 kW	515 N⋅m	Automatic	RWD
6.6 AT	Gasoline	6555 cm³	325 hp	239 kW	Not provided	Automatic	RWD

Pontiac Firebird Dimensions

Cabrio — Pontiac Firebird Dimensions

Cabrio Pontiac Firebird Dimensions
Modification	Length	Width	Height	Wheelbase	Ground clearance, minimum
3.8 AT	4796 mm	1844 mm	1308 mm	2746 mm	178 mm
5.3 AT	4796 mm	1844 mm	1308 mm	2746 mm	178 mm
5.7 AT	4796 mm	1844 mm	1308 mm	2746 mm	178 mm
6.6 AT	4796 mm	1844 mm	1308 mm	2746 mm	178 mm

Coupe Hardtop — Pontiac Firebird Dimensions

Coupe Hardtop Pontiac Firebird Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
3.8 AT	4796 mm	1844 mm	1308 mm	2746 mm	Not provided	178 mm
4.1 MT	4796 mm	1844 mm	1308 mm	2746 mm	1488 kg	178 mm
5.3 AT	4796 mm	1844 mm	1308 mm	2746 mm	Not provided	178 mm
5.7 AT	4796 mm	1844 mm	1308 mm	2746 mm	Not provided	178 mm
6.6 AT	4796 mm	1844 mm	1308 mm	2746 mm	Not provided	178 mm
